Coomber 2241 Operating Instructions

Operating Instructions: 2241
2241 Stereo CD Cassette Recorder
REC PLAY
Coomber
PLEASE NOTE: ALWAYS CLOSE THE CD TRAY (1)
WITH THE UNIT SWITCHED ON. PUSHING THE TRAY
CLOSED WITH THE POWER OFF MAY LEAD TO
DAMAGE DURING SUBSEQUENT TRANSPORTATION.
Power from Mains
The Mains ON/OFF switch is located on the side panel. When ON, the
power indicator (1) on the front panel will illuminate.
Amplifier Controls
● Volume control (7)
To protect listeners, always adjust the volume control (7) to
minimum before use - particularly if headphones are being used.
Turn the volume level up once the CD or cassette is playing.
If necessary restart the CD or cassette once the volume level is set.
● Balance Control (8)
The balance control (8) allows fading between the speakers.
Maximum output of both speakers is achieved when the dial is set
to the centre point.
When turned fully left, the right hand speaker cuts out completely
and vice versa - ideal where music is recorded on one track and
voices on the other.
● Treble (9) and Bass (10) Controls
The treble and bass controls allow listeners to adjust the sound
output to suit, enhancing sound quality as required.
● Recording
The position of the amplifier controls will not affect recordings,
regardless of their position.
FULL AUTO STOP
REW/REV FF/CUE STOP/EJECT PAUSE
CD Cassette Player
1 2 3
MIC RECORD
RESET
POWER
EXT
CD MIC
RECORDING
VOLUME
LEFT RIGHT
MASTER
SPEAKERS
EXT EXT & INT
13 12
Headphone Sockets (11 & 12)
Connecting Mono or Stereo headphones to the MASTER headphone
socket (12) automatically disconnects the internal loudspeakers.
Up to five more pairs of headphones may be connected to Sockets (11).
Note: If the MASTER socket is not used, then the internal loudspeakers
are not disconnected and sound will be reproduced through the
internal loudspeakers and any headphones connected.
SAFETY: For safety you are advised to use only 600 ohm headphones
such as Coomber 1929 headphones.
Prior to using headphones, always turn the volume down,
fit the headphones and then adjust the sound to a
comfortable level.
Tape / CD Selector (5)
The SELECT button (5), should be pushed IN to play CDs or OUT to play
cassette tapes.
External Amplifier Outputs (6)
Use EXT AMP L & R (6) outputs to connect to an external amplifier,
Coomber Booster Speakers or a mixing desk.
The output level is not fixed and may be adjusted by using the
VOLUME and BALANCE controls.
Coomber
4 5 6
OUTPUTS
INTERNAL
TAPE L EXT AMP
CD
- + - +
L R
BASS TREBLE BALANCE
STEREO HEADPHONES
11
R
7
8
9
10
