TV / DVD Combination
CHASSIS : CN-091
Model : DDQ-20L6SCN
MODEL
TV STANDARD
POWER INPUT
POWER CONSUMPTION
TUNING RANGES
SOUND OUTPUT
SPEAKER
ANTENNA INPUT IMPEDANCE
AUXILIARY INPUT TERMINAL
AUXILIARY OUTPUT TERMINAL
INTERMEDIATE FREQUENCIES
REMOTE CONTROL
SPECIAL FUNCTION
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
TCN091BEFO
DDQ-20L6SCN
NTSC-M
AC 120V 60Hz
100W
Frequency Synthesizer(FS) Tuning System
TV
VHF(L) : CH2-CH6
UHF(H) : CH7-CH13
UHF
: CH14-CH69
CATV
VHF(L) : 5A, A, B, A-5-A-1
CH2-CH6
VHF(H) : C-W+11
CH7-CH13
UHF
: W+12-W+84
3W + 3W
8ohm 3W(NORNAL 3W, MAX 5W) x 2EA
75ohm Unbalanced
REAR PART : S-VHS
VIDEO, AUDIO(L,R)
SIDE PART : VIDEO, AUDIO(L,R)
REAR PART : VIDEO, AUDIO(L,R)
COAXIAL DIGITAL AUDIO
SIDE PART : EARPHONE
PICTURE IF CARRIER FREQUENCY : 45.75MHz
SOUND IF CARRIER FREQUENCY : 51.25MHz
COLOR SUB-CARRIER FREQUENCY : 3.58MHz
R-52E05
1) 3-LANGUAGE
2) WITH CAPTION
3) CH LABEL
4) V-CHIP
5) DYNAMIC SOUND
6) SURROUND
7) WAKE-UP/OFF TIMER
8) SLEEP TIMER
9) POWER RESTORE
10) COAXIAL DIGITAL AUDIO OUT
11) EARPHONE
Jan. 2004
Advertisement
Table of Contents
Related Manuals for Daewoo DDQ-20L6SCN
Summary of Contents for Daewoo DDQ-20L6SCN
- Page 1 TCN091BEFO TV / DVD Combination CHASSIS : CN-091 Model : DDQ-20L6SCN MODEL DDQ-20L6SCN TV STANDARD NTSC-M POWER INPUT AC 120V 60Hz POWER CONSUMPTION 100W TUNING RANGES Frequency Synthesizer(FS) Tuning System VHF(L) : CH2-CH6 UHF(H) : CH7-CH13 : CH14-CH69 CATV VHF(L) : 5A, A, B, A-5-A-1...
-
