Ultra Speed
Operator's Manual
Burnisher
Manuel d'utilisation
120V & 230V
Libro de Instrucciones
with NEMA Plug
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your ALTO
machine could result in injury to you or to other personnel; damage to the machine or to other property
could occur as well. You must have training in the operation of this machine before using it. If your
operator(s) cannot read this manual, have it explained fully before attempting to operate this
machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to:
., 2100 Highway 265, Springdale, Arkansas 72764.
ALTO U.S. INC
Form No. 70243A
5/03
CLARKE TECHNOLOGY
Printed in the U.S.A.
