- Page 1 For the user User Manual Air Conditioner - climaVAIR Split Wall-Mounted type V 12-025 W V 12-035 W V 12-050 W V 12-060 W V 12-060 M2W...
-
Page 2: Table Of Contents
Contents Contents Your Safety ......3 Advice for saving Energy ....12 Symbols used . -
Page 3: Your Safety
Your Safety 1 Extreme operating conditions 2 Your Safety Note! This equipment contains R-410A refrigerant. Do Symbols used not vent R-410A into atmosphere: R-410A, is a fluorinated greenhouse gas, covered by Kyoto Danger! Protocol, with a Global Warming Potential (GWP) Direct danger for life and health. -
Page 4: Identification Of The Unit
3 Identification of the Unit 4 Declaration of Conformity 5 Description of the Unit Identification of the Unit Description of the Unit This manual is valid for the Split system series. In order This unit is comprised of the following elements: to know the specific model of your unit please refer to - Indoor unit. -
Page 5: Features And Benefits
Description of the Unit 5 Features and benefits FUNCTION DESCRIPTION Valve protection A cover used to protect the service valves from the effects of bad weather Anti-freeze All heat pump units will tend to freeze up during the colder winter months, the anti-freeze function automatically defrosts the outdoor coil as required Anti-corrosion casing Outdoor unit made of galvanized steel and anti-corrosion materials. -
Page 6: Getting Started
6 Getting started 7 Operating Instructions Getting started Operating Instructions Fitting the Remote Controller Batteries General Safety Considerations during Use Insert the batteries (2 No. size AA), as described below (see Figure 6.1).. Danger of injury and physical damage! - Do not let children play with the air conditioning unit. -
Page 7: Identification Of Functions
Operating Instructions 7 Identification of Functions 7.2.2 Display Indicators 7.2.1 Remote Controller Buttons Fig. 7.2 Overview of the indicators. Legend SLEEP indicator 2 Temperature indicator 3 SWING indicator 4 LIGHT indicator 5 LOCK indicator 6 TIMER indicator 7 TURBO indicator 8 FAN SPEED indicator 9 MODE indicators Fig. -
Page 8: Advice On How To Use The Remote Controller
7 Operating Instructions Advice on how to use the Remote Controller Selection of the Operation Mode Follow the recommendations below as to how to use the Press the ON/OFF button on the remote controller remote controller: pointing at the unit. press the MODE button to select the - When in use, direct the head of the signal transmitter needed mode: auto, cool, dry, heat or fan. -
Page 9: Heating Mode (Heat)
Operating Instructions 7 7.5.4 Heating Mode (HEAT) Setting the Direction of the Airflow In heating mode, the air conditioning only allows heating. The direction of the airflow can be set in vertical and horizontal directions. In order to activate: With the unit connected (see section 7.4): Danger of injury and physical damage! •... -
Page 10: Turbo
7 Operating Instructions TURBO Special Function Selection Press TURBO button during COOL or HEAT mode operation. The air rate can be set to HIGH and continue 7.9.1 SLEEP function to operate for 15 minutes. Press TURBO button again The COOL, DRY, HEAT, AUTO modes can be set during twice to release the TURBO mode operation. -
Page 11: Timer Function (Connection Using Timer)
Operating Instructions 7 7.9.2 TIMER Function (CONNECTION USING TIMER) 7.10 Indicators of the unit The unit can be automatically connected/disconnected using the timer. Note! Before starting, make sure that the clock is adjusted correctly. In order to set the unit to disconnect automatically: With the unit connected (see section 7.4): •... -
Page 12: Advice For Saving Energy
8 Advice on saving Energy Advice for saving Energy Uniform Heating Often in a house only the one room is heated. In addition Suitable room Temperature to the surfaces which form the perimeter of this area, Set the room temperature to an appropriate value to i.e. -
Page 13: Troubleshooting
The table below describes a selection of problems with their possible causes and solutions, see Table 9.1. If these solutions do not solve the problem contact your usual installer or call your nearest Vaillant office. SYMPTOMS POSSIBLE CAUSES POSSIBLE SOLUTION The system does not work at all (the The selector is set to "O"... -
Page 14: Maintenance
In order to do so: We advise you to contact a reliable air • Remove the air filters. conditioner specialist or the Vaillant Group • Remove the dust or the dirt in the filters using a Technical Service to contract a preventative vacuum cleaner or cleaning them with lukewarm water maintenance service. -
Page 15: Storage Over A Prolonged Period
Storage over a prolonged Period 11 Product Decommissioning 12 Storage over a prolonged Period 12 Product Decommissioning If you do not intend to use the unit over a period of Danger of injury and physical damage! time: When disposing of the product, ensure that is •... - Page 16 Vaillant Ltd Vaillant House Medway City Estate Trident Close Rochester Kent ME2 4EZ Telephone 0164 292300 Fax 0164 290166 www.vaillant.co.uk info@vaillant.co.uk...
