Summary of Contents for Subaru Forester EyeSight 2015

  • Page 1 2015 Forester EyeSight Owner’s Manual...
  • Page 3 EyeSight is never a substitute for active driver involvement and it may not operate optimally under all driving conditions. This booklet is a supplement to the Owner’s Manual for your SUBARU vehicle and contains a detailed description of EyeSight. It should be read in conjunction with your Owner’s Manual so that you will gain a thorough understanding of the proper...

  • Page 5: Table Of Contents

    EyeSight About EyeSight•••••••••••••••••••••••••••••••••••••••••••••••••••••2 Adaptive Cruise Control •••••••••••••••••••••••••••••••••••••••• 21 Pre-Collision Braking System ••••••••••••••••••••••••••••••••• 43 Pre-Collision Throttle Management •••••••••••••••••••••••••• 52 Lane Departure Warning ••••••••••••••••••••••••••••••••••••••• 58 Lane Sway Warning ••••••••••••••••••••••••••••••••••••••••••••• 61 Lead Vehicle Start Alert •••••••••••••••••••••••••••••••••••••••• 64 Conventional Cruise Control••••••••••••••••••••••••••••••••••• 65 List of buzzer sounds ••••••••••••••••••••••••••••••••••••••••••• 75 EyeSight malfunction and temporary stop ••••••••••••••••••...

  • Page 6: About Eyesight

    EyeSight makes use of original stereo cameras designed by SUBARU. Two CCD (Charge Coupled Device) cameras are used to process stereo images and identify the vehicle in front, obstacles, traffic lanes and other items.
  • Page 7 About EyeSight CAUTION The characteristics of the stereo cameras are similar to those of human eyes. For this reason, conditions that make it difficult for the driver to see in the forward direction have the same effect on the stereo cameras and make it difficult for the system to detect vehicles, obstacles and traffic lanes.
  • Page 8 When there is a malfunction in the EyeSight system, turn off the Pre-Colli- sion Braking System (refer to page 51) and the Lane Departure Warning (refer to page 60), and stop using the Adaptive Cruise Control. Contact a SUBARU dealer and have the system inspected.
  • Page 9 - Data related to ABS, Vehicle Dynamics Control and Traction Control Function SUBARU and third parties contracted by SUBARU may acquire and use the recorded data for the purpose of vehicle research and development. SUBARU and third parties contracted by SUBARU will not disclose or provide the acquired data to any other third party except under the fol- lowing conditions.
  • Page 10 - Never touch the stereo camera lenses, and do not attempt to wipe or clean the lenses. Doing so could cause lens damage or contamination and lead to improper system performance. If you ever touch a lens for any reason, be sure to contact a SUBARU dealer.
  • Page 11 Do not change the positions where the stereo cameras are installed or modify any of the surrounding structures. Do not install an interior rearview mirror other than a genuine SUBARU rearview mirror (such as a wide-type mirror). Also, use the rearview mirror so that it does not obstruct the stereo cameras.
  • Page 12 For details, contact a SUBARU dealer. Do not install any wiper blades other than genuine SUBARU wiper blades. Doing so may affect the stereo cameras’ field of vision and could prevent the EyeSight system from functioning properly.
  • Page 13 About EyeSight If there are scratches or cracks on the front windshield, contact a SUBARU dealer. To have the front windshield replaced or repaired, contact a SUBARU dealer. Do not install a front windshield other than a genuine SUBARU front windshield. The stereo cameras may not be able to detect objects...

  • Page 14: Adaptive Cruise Control

    About EyeSight EyeSight Functions EyeSight includes the following seven functions. ■ Adaptive Cruise Control This function maintains the set vehicle speed and when there is a vehicle in front in the same traffic lane, it tracks the speed of the vehicle in front up to the maximum of the set vehicle speed.

  • Page 15: Conventional Cruise Control

    About EyeSight ■ Conventional Cruise Control In this mode, the system maintains a constant vehicle speed. Tracking of the vehicle in front does not occur. This function can be used even when the stereo cameras have temporarily stopped operating. (Refer to page 77.) (This function is used by switching from Adaptive Cruise Control to Conventional Cruise Control.) * Refer to page 65.

  • Page 16: Combination Meter

    About EyeSight Instrument panel display layout ■ Combination meter <Meter display (U.S. models)> Lane indicator (Left) Following distance setting Lead vehicle indicator indicator Selector indicator / shift position indicator Lane indicator (Right) Conventional Steering wheel indicator Cruise Control indicator SET indicator Adaptive Cruise Control indicator READY indicator...
  • Page 17 About EyeSight <Meter display (Canada models)> Lane indicator (Left) Following distance setting Lead vehicle indicator indicator Selector indicator / shift position indicator Lane indicator (Right) Conventional Steering wheel indicator Cruise Control indicator SET indicator Adaptive Cruise Control indicator READY indicator Set vehicle speed display Customization display EyeSight temporary...
  • Page 18 * Refer to page 36. ● Set vehicle speed display Displays the set vehicle speed. * Refer to page 28. ● SI-DRIVE mode indicator Indicates the current SI-DRIVE mode. SI-DRIVE refers to SUBARU Intelligent Drive. * Refer to page 19.

  • Page 19: Lane Indicator

    About EyeSight ● Selector indicator/shift position indicator Displays the selector lever position or the selected gear position. For turbo models, when the Adaptive Cruise Control / Conventional Cruise Control is set while S# (Sports Sharp mode) of SI-DRIVE is selected, the display switches from the gear position to the D position.

  • Page 20: Multi Function Display

    About EyeSight ● Lane Departure Warning OFF indicator light This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are off. It also illuminates when the ignition switch is turned to the ON position, and then approxi- mately 7 seconds after the engine starts, it turns on or off depending on the current status (ON or OFF).
  • Page 21 About EyeSight ● Your own vehicle indicator When the brake pedal is depressed or the brake control function is active, the brake light on the indicator illuminates in red. ● Lead vehicle indicator While the Adaptive Cruise Control is set to on, this indicator is displayed when a vehicle is detected in front.

  • Page 22: Steering Wheel Switches

    About EyeSight Switch layout ■ Steering wheel switches CANCEL switch RES/+ switch SET/- switch (CRUISE) switch (Following distance setting) switch S#/I switch S/I switch Switch <Turbo> Switch S switch I switch (INFO)/SET switch <Except for turbo> S00812 ● (CRUISE) switch Switches cruise control on/off.
  • Page 23 SI-DRIVE switch Selects the tracking characteristics linked with the SI-DRIVE (only when adaptive cruise control is set). SI-DRIVE refers to SUBARU Intelligent Drive. ▼ Turbo model - S/I switch Switches between I (Intelligent mode) and S (Sports mode) every time it’s pressed.
  • Page 24 About EyeSight ● switch/ switch The screen displayed on the multi function display can be switched. ● (Info)/SET switch The pop up screen displayed on the multi function display can be displayed again. * Refer to page 81. ■ Pre-Collision Braking System OFF switch Press and hold this switch for approximately 2 seconds or longer to turn off the Pre-Collision Braking System and Pre-Collision Throttle...

  • Page 25: Adaptive Cruise Control

    Adaptive Cruise Control Adaptive Cruise Control Adaptive Cruise Control is a driving support system intended to allow more comfortable driving on expressways, freeways and interstate highways. The vehicle in front in the same traffic lane is detected by means of the stereo cameras, and your vehicle tracks the vehicle in front (up to the maximum speed of the set vehicle speed) while automatically maintaining a following distance that corresponds to the speed of the vehicle in front.
  • Page 26 Adaptive Cruise Control Continued from previous page - Traffic conditions when frequent acceleration and deceleration make it diffi- cult to maintain the following distance It may not be possible for the system to perform as the traffic conditions require. - Steep downhill grades The set vehicle speed may be exceeded.
  • Page 27 Adaptive Cruise Control The stereo cameras may have difficulty detecting the following objects or conditions. Operate the brake pedal and take other actions as necessary. - Vehicles at significantly different speeds (vehicles driving slowly, stopped or oncoming vehicles, etc.) - Vehicles cutting into your lane - Motorcycles, bicycles, pedestrians and animals, etc.
  • Page 28 Adaptive Cruise Control Continued from previous page Detection of the vehicle in front by the EyeSight stereo cameras Under the following road conditions or conditions of your vehicle, detection of the vehicle in front may not be possible. Vehicles in neighboring traffic lanes or roadside objects may also be incorrectly detected.
  • Page 29 Adaptive Cruise Control - When the vehicle in front is not directly ahead of your vehicle and is shifted to one side S00641 - When there is an obstacle at the side of the road S00642 - When the speed difference with the vehicle (or object) in front is more than 20 MPH (30 km/h) - When a vehicle cuts into your lane in front of you - When the distance between vehicles is extremely small...
  • Page 30 Adaptive Cruise Control Continued from previous page Even when the following distance is short, the “brake more” warning may not activate in the following cases. - When the speed difference compared to the vehicle in front is small (the two vehicles are travelling at almost the same speed) - When the vehicle in front is traveling faster than your vehicle (the follow- ing distance is gradually increasing) - When another vehicle cuts into your lane very close to your vehicle...
  • Page 31 (Adaptive Cruise Control) is not displayed when the (CRUISE) switch is pressed, there may be a malfunction in the system. Contact a SUBARU dealer and have the system inspected. Some noises may be audible during automatic braking. This is caused by...
  • Page 32 Adaptive Cruise Control How to use Adaptive Cruise Control The Adaptive Cruise Control can be used while the engine is running. ■ Setting the Adaptive Cruise Control (1) Setting Adaptive Cruise Control to standby status Press the (CRUISE) switch. The Adaptive Cruise Control will be turned on and (Adaptive Cruise Control) and (following distance setting) will be displayed on the EyeSight indicator section located in the meter.
  • Page 33 Adaptive Cruise Control NOTE When the main cruise control is turned on by pressing the (CRUISE) switch, the multi function display switches to the EyeSight screen. To return to the triple meter clock display, pull the switch on the steering wheel toward you.
  • Page 34 Adaptive Cruise Control NOTE The set vehicle speed can be adjusted within the range from 25 MPH (40 km/h) to 90 MPH (145 km/h). If cruise control is set while driving the vehicle at approximately 25 MPH (40 km/h) or less, the set vehicle speed is automatically set to 25 MPH (40 km/h).
  • Page 35 Adaptive Cruise Control When a vehicle in front is detected The vehicle tracks the lead vehicle in front, and will maintain the chosen following dis- tance, up to the set target vehicle speed - between 25 MPH (40 km/h) and 90 MPH (145 km/h).
  • Page 36 Adaptive Cruise Control ■ Increasing the set vehicle target speed ● Using the RES/+ switch While driving with Adaptive Cruise Control on, operate the RES/+ switch as follows. Push the RES/+ switch briefly. Every time the switch is pushed, the set vehicle target speed will increase in increments of 5 MPH (5 km/h).
  • Page 37 Adaptive Cruise Control ■ Decreasing the set vehicle target speed ● Using the SET/- switch While driving with Adaptive Cruise Control on, operate the SET/- switch as follows. Push the SET/- switch briefly. Every time the switch is pushed, the set vehicle target speed will decrease in incre- ments of 5 MPH (5 km/h).
  • Page 38 Adaptive Cruise Control ■ Accelerating the vehicle temporarily Depress the accelerator pedal to accelerate the vehicle temporarily. When the accelerator is released, the vehicle returns to the set vehicle target speed. NOTE For turbo models, if the S# (Sports Sharp mode) of SI-DRIVE is selected, the shift position indicator will change from the gear position to the position when the accelerator pedal is depressed.
  • Page 39 Adaptive Cruise Control CAUTION When Adaptive Cruise Control is operating, actual vehicle speed is con- trolled according to the lead vehicle. Therefore, if the RES/+ switch is pressed and set to a speed higher than the speed of the lead vehicle, the vehicle will not accelerate - it will maintain a safe following distance as first priority.
  • Page 40 Adaptive Cruise Control ■ Changing the following distance: The following distance from the vehicle in front can be set to three levels. Each time the (following distance setting) switch is pressed, the following distance from the vehicle in front switches in the following sequence: Medium Close Following distance...
  • Page 41 Adaptive Cruise Control ■ Canceling Adaptive Cruise Control ● Canceling by driver operation Either of the following operations will cancel Adaptive Cruise Control. Press the CANCEL switch Depress the brake pedal. The display screen will change as follows. Meter display: The SET indicator disappears with the set vehicle target speed shown.
  • Page 42 Adaptive Cruise Control NOTE When Adaptive Cruise Control is turned to OFF, the screen of the multi function display will switch to the triple meter screen. * For details, refer to the Owner’s Manual for your vehicle. miles miles S00896 ●...
  • Page 43 Adaptive Cruise Control - Cruise control can be resumed after the transmission select lever is returned to the position. A paddle shift switch is operated while driving when the transmission select lever is in the position. - Cruise control can be resumed after the paddle shift is not operated for a while. (The shift position will return to the position unless S# (Sports Sharp mode) of SI-DRIVE is selected on turbo models.)
  • Page 44 If the cruise control func- tion cannot be set even after the condition has been corrected, EyeSight may be malfunctioning. This will not interfere with ordinary driving; how- ever the system should be inspected by a SUBARU dealer as soon as possible.
  • Page 45 Adaptive Cruise Control ■ Resuming from temporal cancellation (returning to a vehicle speed that was previously set) When the vehicle speed which was previously set is stored in memory, press the RES/+ switch to return to set that vehicle speed. (The screens that indicate the set condition will appear again on the meter display and the multi function display.)
  • Page 46 Adaptive Cruise Control ■ “Brake more” warning The “brake more” warning is activated while Adaptive Cruise Control is tracking a lead vehicle. The “brake more” warning warns the driver when it determines that deceleration by current driver braking control is insufficient. When the ‘brake more’...

  • Page 47: Pre-Collision Braking System

    Pre-Collision Braking System Pre-Collision Braking System When there is the risk of a rear-end collision with a obstacle in front, the EyeSight system helps to minimize or prevent a collision by warning the driver. If the driver still does not take evasive action to avoid a collision, the brakes can be automatically applied just before the collision in order to reduce impact damage, or if possible, prevent the collision.
  • Page 48 Pre-Collision Braking System Continued from previous page - Even if the obstacle is a motorcycle, bicycle or pedestrian, depending on the brightness of the surroundings as well as the relative movement, and aspect or angle of the object, there may be cases when the system can- not detect it.
  • Page 49 Pre-Collision Braking System • When there is a wall, etc. in front of a stopped vehicle • When there is another object near the vehicle • When a vehicle, etc. is stopped in the lateral direction • With vehicles that are backing up or with oncoming vehicles, etc. •...
  • Page 50 Pre-Collision Braking System CAUTION In the following situations, turn off the Pre-Collision Braking System. Other- wise the Pre-Collision Braking System may activate unexpectedly. - When the vehicle is being towed - When loading the vehicle onto a carrier - When a chassis dynamometer, free-rollers or similar equipment is used - When a mechanic lifts up the vehicle, starts the engine and spins the wheels freely - When passing hanging banners, flags or branches, or when thick/tall...
  • Page 51 Pre-Collision Braking System S00652 - When there is an obstacle on a curve or intersection - When narrowly passing a vehicle or an object - When stopping very close to a wall or a vehicle in front If there is cargo or installed accessories, etc.
  • Page 52 Pre-Collision Braking System ■ Detection of pedestrians EyeSight system also detect pedestrians. The EyeSight system detects pedestrians from their size, shape and movement. The system detects a pedestrian Approx when the contour of the head and shoulders 3 1/3 ft - are clear and the left/right balance is 6 2/3 ft (1-2 m)
  • Page 53 Pre-Collision Braking System Pre-Collision Braking System operation When there is an obstacle in the forward direction during driving, the system activates in the following sequence in order to warn the driver, activate braking control, and active the brake lights. (1) Following Distance Warning: When the system determines that there is a risk of collision, a buzzer sounds repeated short beeps and the indicators on the meter display and the multi function display illuminate to warn the driver.
  • Page 54 Pre-Collision Braking System CAUTION The Pre-Collision Braking System will not activate when the EyeSight warn- ing light ( ) is illuminated or flashing, or when the EyeSight temporarily stops. NOTE Neither primary Pre-Collision Braking nor secondary Pre-Collision Braking will operate in the following conditions. When the vehicle speed is approximately 1 MPH (1 km/h) or lower, or approximately 100 MPH (160 km/h) or higher.
  • Page 55 Pre-Collision Braking System Turning off the Pre-Collision Braking System When pressing and holding the Pre-Collision Braking System OFF switch for approximately 2 seconds (or longer), a single short beep will sound and the Pre-Collision Braking System (including Pre-Collision Brake Assist) will turn off.

  • Page 56: Pre-Collision Throttle Management

    Pre-Collision Throttle Management When an obstacle is detected in front of the vehicle, and the vehicle is stopped or travel- ling very slowly, if the system determines that the accelerator pedal has been depressed by more than the necessary amount (due to driver error), it greatly restricts engine output and ensures that vehicle forward movement is slower than normal in order to give the driver...
  • Page 57 Pre-Collision Throttle Management Pre-Collision Throttle Management will not reduce acceleration under all conditions. It is also not designed to prevent collisions. Pre-Collision Throttle Management will operate when an obstacle is detected in front. However, this function will not reduce acceleration in cases where no obstacle is recognized (for example when approaching a cliff, etc.) Do not intentionally depress the accelerator pedal excessively when there...
  • Page 58 Pre-Collision Throttle Management Continued from previous page • When the rear aspect of the vehicle or object in front is small (for example a trailer, oncoming vehicle, etc.) or when your vehicle is too close to it (the system may recognize another part of the vehicle as its rear end, and may not operate prop-...
  • Page 59 Pre-Collision Throttle Management CAUTION In the following situations, turn off Pre-Collision Throttle Management. Other- wise Pre-Collision Throttle Management may activate unexpectedly. - When the vehicle is being towed - When loading the vehicle onto a carrier - When a chassis dynamometer, free-rollers or similar equipment is used - When a mechanic lifts up the vehicle, starts the engine and allows the wheels to spin freely - When passing hanging banners, flags or branches, or when thick/tall...
  • Page 60 Pre-Collision Throttle Management Continued from previous page - When there is an obstacle on a curve or intersection S00692 - When narrowly passing a vehicle or object - When stopping very close to a wall or a vehicle in front NOTE When the Pre-Collision Braking System is turned off, Pre-Collision Throttle Management is also turned off.
  • Page 61 Pre-Collision Throttle Management Turning off Pre-Collision Throttle Management When pressing and holding the Pre-Collision Braking System OFF switch for approximately 2 seconds or longer a single short beep will sound and the Pre-Collision Throttle Management System will turn off. When this function is turned off, the Pre-Collision Braking System OFF indicator light on the instrument panel illuminates.

  • Page 62: Lane Departure Warning

    Lane Departure Warning When vehicle speed is approximately 32 MPH (50 km/h) or more, this function warns the driver if the system detects that the vehicle is likely to depart the traffic lane. When Lane Departure Warning activates, a buzzer sounds 6 short beeps, and the steer- ing wheel indicator and right/left lane indica- tors on the meter display all flash at the same time.
  • Page 63 Lane Departure Warning CAUTION In the following situations, the Lane Departure Warning will or may not acti- vate: Vehicle speed is approximately 32 MPH (50 km/h) or less. For approximately 7 seconds after the Lane Departure Warning activates once When the steering wheel is turned significantly to either side When the brake pedal is depressed or immediately after it is depressed When the accelerator pedal is almost fully depressed and the vehicle is accelerating or immediately after accelerating...

  • Page 64: Lane Departure Warning Off Indicator Light

    Lane Departure Warning Turning off Lane Departure Warning When pressing holding Lane Departure Warning OFF switch for approxi- mately 2 seconds or longer, a single short beep will sound and the Lane Departure Warning will turn off. When this function is turned off, the Lane Departure Warning OFF indicator light on the instrument panel will illu- minate.

  • Page 65: Lane Sway Warning

    Lane Sway Warning Lane Sway Warning This function detects wandering or drifting within a lane, and warns the driver. When Lane Sway Warning activates, a buzzer sounds 6 short beeps, the steering wheel indi- cator flashes and the lane indicators flash alternately left/right on the meter display.
  • Page 66 Lane Sway Warning NOTE Wandering detection is based on several minutes of driving data. Wander- ing will not be detected immediately when it occurs. In addition, the warn- ing may continue for some time even after wandering stops. The Lane Sway Warning System may also issue a warning when the driver is tired, not concentrating on the road or otherwise not paying adequate attention to driving.
  • Page 67 Lane Sway Warning Turning off Lane Sway Warning Press and hold the Lane Departure Warning OFF switch for approximately 2 seconds or longer to turn off the Lane Sway Warning. When this function is turned off, a single short beep sounds and the Lane Departure Warning OFF indicator light on the instrument panel illuminates.

  • Page 68: Lead Vehicle Start Alert

    Lead Vehicle Start Alert This function notifies the driver by means of a buzzer and the lead vehicle indicator on the multi information display when the driver’s vehicle remains stopped after the vehicle in Lead front has started to move forward. When the vehicle vehicle in front remains stopped continuously Lead...

  • Page 69: Conventional Cruise Control

    Conventional Cruise Control Conventional Cruise Control About Conventional Cruise Control Conventional Cruise Control is a driving support system intended to allow more comfortable driving on expressways, freeways and interstate highways. It can be used to travel at a con- stant speed by maintaining the vehicle speed that was set by the driver (approximately 25 MPH (40 km/h) to 90 MPH (145 km/h)).
  • Page 70 Conventional Cruise Control NOTE When the (CRUISE) switch is first turned on, the Adaptive Cruise Control is set. To change the Cruise Control mode, press and hold the (following distance setting) switch for approximately 2 seconds or longer. (This is effective only when the main Cruise Control is on and neither Adaptive Cruise Control nor Conventional Cruise Control are set.) Even when the EyeSight function temporarily stops, the Conventional Cruise Control can be used.
  • Page 71 Conventional Cruise Control How to use the Conventional Cruise Control Conventional Cruise Control can be set when the following conditions are met. - The select lever is in the position. - The brake pedal is released. - The vehicle speed is between approximately 25 MPH (40 km/h) and 90 MPH (145 km/h).
  • Page 72 Conventional Cruise Control (2) Press and hold the (following dis- tance setting) switch for approximately 2 seconds or longer to switch from Adaptive Cruise Control to Conventional Cruise Control. A buzzer sounds 1 short beep. At this time, the following distance setting indicator will turn off and the (Conventional Cruise Control) will be dis- played on the meter display and at the...
  • Page 73 Conventional Cruise Control WARNING The “brake more” warning will not activate while Conventional Cruise Control is functioning. CAUTION During Conventional Cruise Control use, accelerator and brake control to track the vehicle in front is not performed. Operate the accelerator and brake pedals as necessary.
  • Page 74 Conventional Cruise Control ■ Increasing the set vehicle speed ● Using the RES/+ switch Pressing the RES/+ switch briefly Every time you press the RES/+ switch, the set vehicle speed will increase by 5 MPH (5 km/h). Pressing the RES/+ switch continuously While pressing the RES/+ switch, the set vehicle speed will increase by 1 MPH (1 km/h).
  • Page 75 Conventional Cruise Control ● Using the brake pedal Depress the brake pedal to decrease the vehicle speed. (This cancels Conventional Cruise Control.) When the desired speed is reached, press the SET/- switch. The vehicle speed is set at the speed when the switch is pressed, and the new set vehicle speed will be displayed on the meter display.
  • Page 76 Conventional Cruise Control Press the (CRUISE) switch. The EyeSight display in the meter will disappear and the Conventional Cruise Control will turn off. S00815 ● Automatic cancellation by the system In the following cases, a buzzer sounds a single long beep and the Cruise control function is automatically canceled.
  • Page 77 Conventional Cruise Control cannot be used. This will not interfere with ordinary driving; however the system should be inspected by a SUBARU dealer as soon as possible. * Refer to page 76. When operation of Conventional Cruise Control has been automatically canceled, perform the set operation again after the condition that caused the cancellation has been eliminated.
  • Page 78 Conventional Cruise Control ■ Resuming from temporary cancellation (resetting the set vehi- cle speed) To recall and set a vehicle speed that has been previously set, press the RES/+ switch. (The meter display shows the set condition again.) Resume is possible when a vehicle speed was previously set, and the current vehicle speed is approximately 20 MPH (30 km/h) or more.

  • Page 79: List Of Buzzer Sounds

    List of buzzer sounds List of buzzer sounds Buzzer sound Status Reference page Refer to page 49. Single continuous Pre-Collision Braking System: beep Second Braking and alarm are active. Pre-Collision Braking System: Automatic brake is cancelled after the vehicle Refer to page 49. has been stopped with the operation of Second Braking and alarm.

  • Page 80: Eyesight Malfunction And Temporary Stop

    The components related to the EyeSight system are malfunctioning (for example, the engine warning light illuminates). Immediately stop the vehicle in a safe location, and contact your SUBARU dealer for an inspection. NOTE If the EyeSight warning light illuminated or flashed, stop the vehicle in a safe location, and after stopping the engine once, restart the engine.
  • Page 81 In either case, it may take some time for the system to restart. If the system does not restart, even after the conditions have improved and a period of time has elapsed, contact your SUBARU dealer for an inspection.
  • Page 82 If the system does not S00863 restart, even when the <Multi function display> temperature inside the vehicle is normal, contact EyeSight Disabled your SUBARU dealer for an Temp Range inspection. S00864 When the EyeSight The system will restart once <Meter display>...

  • Page 83: Customizing Functions

    Customizing functions Customizing functions ■ How to customize The customizing function can be operated when the engine is running, the main cruise control is off (the indicator is not displayed on the meter) and the select lever is in the position.
  • Page 84 Customizing functions ● Warning volume setting Setting Display warning volume Max/Mid/Min. When the RES/+ or SET/- switch is pressed, the setting will change to the next and 3 short beeps will sound in the volume corresponding to the setting. S00869 ●...

  • Page 85: List Of The Pop-Up Screens On The Multi Function Display

    List of the pop-up screens on the multi function display List of the pop-up screens on the multi function display If an EyeSight warning or malfunction is detected, a pop-up screen will be displayed on the multi function display. Depending on the message, a buzzer will sound at the same time. Mark Normal screen Pop-up screen...
  • Page 86 List of the pop-up screens on the multi function display Item Displayed screen mark Action (Reference page) For Canada: MFD For USA: on the meter display Lane Sway Warning None Refer to page 61. Stay Alert S00876 Lead Vehicle Start Alert None Refer to page 64.
  • Page 87 List of the pop-up screens on the multi function display ■ Screen list (Malfunction, temporary stop, etc.) Item Displayed screen mark Action (Reference page) EyeSight System EyeSight off Refer to page 76. Malfunction* (yellow) Check Manual S00859 EyeSight Disabled None Refer to page 77.

  • Page 88: Troubleshooting

    Troubleshooting Cruise control cannot be set. Did you remember to press the (CRUISE) switch? If you have not pressed the (CRUISE) switch, the (Adaptive Cruise Control) indicator will not be shown. Is EyeSight operation temporarily stopped? When EyeSight is temporarily stopped, one of the EyeSight temporary stop indi- cators (“E1”, “E2”...
  • Page 89 Troubleshooting A vehicle (in front of your vehicle) is not detected, is detected later or detection is lost quickly. Is the vehicle in front stopped, moving slowly relative to your vehicle or moving extremely slowly? Detection of stopped vehicles, vehicle moving slowly relative to your vehicle, and vehicles moving extremely slowly may be difficult.
  • Page 90 Troubleshooting EyeSight does not restart after a temporary stop. Is Vehicle Dynamics Control turned off? EyeSight cannot be activated when Vehicle Dynamics Control is off. Is the X-mode turned on? EyeSight cannot be activated when the X-mode is turned on. Are you driving in the rain with old wipers or is there an oily film on the windshield? Replace the wipers with new ones, or clean the oily film off the windshield.
  • Page 91 Troubleshooting A noise occurs when automatic braking control activates. This is the sound of the automatic braking control operating. Braking control activates frequently when driving in heavy traffic. Unlike a human driving, the EyeSight system performs control based only on the actions of vehicles or objects in front.
  • Page 92 MEMO...
  • Page 100 MSA5M1519A B8192BE-B Issued December 2013 Printed in USA 1/14 2015A FUJI HEAVY INDUSTRIES LTD. TOKYO, JAPAN...
