www.fetco.com
Model:
Hot Water Dispenser HWD_2102
--With Portion Control
HW
B-2102 series commercial hot water dispensers
NOTICE TO INSTALLER: Please leave this book with the machine.
Operator and User Section
FETCO Hot Water Dispenser HWD_2102 .....................2
Contact Information ........................................................2
Description & Features ...................................................2
Operating Instructions ....................................................2
© 2014 Food Equipment Technologies Company
USERS GUIDE
Table of Contents
FETCO®, XTS are trademarks or trade names of Food Equipment Technologies Company.
User's Guide
Technical and Professional Section
Specifications .................................................................5
Weights and Capacities..................................................5
Water Requirements.......................................................5
Installation.......................................................................6
Installation Safety and Hygiene Directions...................11
Parts and Service drawings..........................................13
P134
- CE Edition November
2014
Advertisement
Table of Contents
Related Manuals for Fetco HWB-2102 series
Summary of Contents for Fetco HWB-2102 series
-
Page 1: Table Of Contents
Description & Features ...........2 Water Requirements............5 Operating Instructions ............2 Installation...............6 Installation Safety and Hygiene Directions....11 Parts and Service drawings..........13 FETCO®, XTS are trademarks or trade names of Food Equipment Technologies Company. © 2014 Food Equipment Technologies Company P134 - CE Edition November 2014... -
Page 2: Fetco Hot Water Dispenser Hwd_2102
FETCO Hot Water Dispenser HWD_2102 Contact Information FETCO Phone: (800) 338-2699 (US & Canada) ® Food Equipment Technologies Company (847) 719-3000 600 Rose Road Fax: (847) 719-3001 Lake Zurich • IL • 60047-0429 • USA Email: sales@fetco.com techsupport@fetco.com Internet: www.fetco.com Description &... - Page 3 CONTROL PANEL LAYOUT DIAGRAM FOR HWD_2102 HOT WATER DISPENSER Power Lamp (Lit when unit is energized) Ready Lamp -Dispense will operate when lit, -Temperature is low when not lit Heating Lamp For hot water tank (is “ON” when heater is activated) Sensor for Function Selector selects and activates selected option Border of UNLOCK/DISPENSE pad will:...
- Page 4 User Cleaning & Maintenance Daily: 1. Check the drip tray and empty if necessary. Quarterly: 2. Inspect all fittings and hoses for leaks. Notice: 3. Turn off power before any cleaning procedure, including wiping the exterior for appearance reasons. Dry the exterior, especially the face panel, before turning on power. WARNING: 1.
-
Page 5: Specifications
All commercial hot water dispensers to be supplied with filtered water Water connection inlet: 3/8 inch male flare fitting. Dimensions & Utility Connections Designs, materials, specifications, physical dimensions, firmware and software protocol for equipment or replacement parts are subject to review and change by FETCO without notice... -
Page 6: Installation
The installation must comply with applicable federal, state, and local codes having jurisdiction at your location. Utilize only qualified beverage equipment service technicians for installation. A Service Company Directory may be found on our website, http://www.fetco.com. Warning: Legs are to be adjusted only to level the unit. - Page 7 Higher pressure will increase flow rate. Unit is factory set at 96°C/205°F Unit is factory set at 5 seconds=200ml/6.8oz. Designs, materials, specifications, physical dimensions, firmware and software protocol for equipment or replacement parts are subject to review and change by FETCO without notice...
- Page 8 ERROR Messages The UNLOCK/DISPENSE pad rapidly flashes red if finger remains Ready [Green] on it after dispensing and no water is dispensed. Heater [White] If finger remains on the UNLOCK/DISPENSE pad more than 35 seconds while rapidly flashing red-the controls “lock out” and Touch [Red] READY LIGHT &...
- Page 9 TABLE OF TECHNICAL DATA SW3=temperature set SW1 = time * 10 SW2 = time * 1 0 = 87 C 1 = 88 C 2 = 89 C Portion time = 3 = 90 C SW1 * 10 + SW2 4 = 91 C 5 = 92 C Min Time = 1 second even if SW1 and SW2 are set to 0...
- Page 10 Operating Principles The dispense valve assembly delivers precision temperature water at selected temperatures. When hot water is drawn from the faucet, the fill valve pulses on and off every few seconds to replenish the tank. By controlling the flow of incoming water, the amount of cold water entering the tank is synchronized with the rate at which the water can be heated.
-
Page 11: Installation Safety And Hygiene Directions
Installation Safety and Hygiene Directions 1. Access to the service area is restricted to persons having safety/hygiene knowledge and practical experience of the coffee brewer. This appliance must be installed in locations where it can be overseen by trained personnel 2. - Page 12 For BACK PANEL of equipment WARNING To reduce risk of electric shock or fire FETCO® Hot Beverage Equipment is for commercial use only. Do not remove or open cover. No user serviceable parts inside. Refer installation and service to qualified personnel.
