Land Pride RCM5020 Series Specifications & Capacities

Specifications & Capacities
Rotary Cutters, Folding Deck
Min. PTO Horse Power
Gear Box Horsepower
Gear Box
Lubrication & Capacity
Cutting Capacity
Machine Weight
Blade Tip Speed @ 540 RPM
@ 1000 RPM
Hitch Weight
Hitch Types
Hitch Jack
Cutting Width
Overall Width
Minimum Transport Width
Overall Length
Deck Height
Cutting Height
Lift Hydraulics
Wing Hydraulics
Wing Transport Protection
Deck Thickness
Side Skirt Thickness
Skid Shoes Wing Deck
Center Deck
Blades - 6 (2 per Carrier)
Blade Overlap
Blade Bolt
Stump Jumper / Blade Holder
Deck Ring
Front & Rear Guards
Heavy Duty
Input Driveline Options
Heavy Duty
Intermediate & Wing
Drivelines
Wheel Options
Number of Wheel
Transport Axle
Hubs
Shredder Blades (optional)
Colors
Designs, specifications, features and information are subject to change without notice.
117
RC5020 and RCM5020 Series
70
250 HP Splitter
210 HP Center & wing
Center deck & wings: 10 pints of Gear Lube 80-90W EP
Divider Gearbox: 5.5 pints of Gear Lube 80-90W EP
Up To 3" Material
6,528 lbs. Approx.
(With single row chain guards, 6 laminated tires, dual axle, 540 CV main driveline)
Center blade: 17,377 FPM & Wing blade: 17,329 FPM
Center blade: 18,165 FPM & Wing blade:18,317 FPM
2300 lbs.
Pull-Type, Self-Leveling Hitch & Clevis
Standard hand crank
20'-0"
20'-9 1/2"
8'-9"
19'-3"
10 1/2"
2" to 14" High with hydraulic cylinder and stroke control spacers
4" x 8" hydraulic cylinder, hoses, fittings & stroke control spacers
3" x 12" hydraulic cylinders, hoses & fittings
Wing Transport Locks
3/16"
1/4"
Reversible & replaceable
2 - Replaceable
1/2" x 4" Thru-harden free swinging alloy steel with uplift
6"
Keyed with hardened flat washer & lock nut
3/16" Round dish shaped bolt-on stump-jumper with 1" diamond shaped blade bar
Optional 1/2" x 3" fully welded
Optional rubber, single chain or double chain
Conventional u-joint ASAE Category 5 with 1 3/8"-21 spline
Constant velocity u-joint ASAE Category 5 with 1 3/8"-21 spline or 1 3/4"-20 spline
ASAE Cat. 5 with slip-clutch protection
6" x 21" Laminated tires
or 27" x 7.75" x 15" Used aircraft tires w/wo foam filling
or 15" Rims
6 - Wheel option: 4 on transport axle and one on each wing axle
8 - Wheel option: 4 on transport axle and two on each wing axle.
Spring-cushioned on center transport axle
Cast iron 5-bolt hubs with tapered roller bearings and with 1 3/4" shafts
material into smaller pieces
Cuts
Standard color: Beige
Optional colors: Green or Red
318-474S continue on next page
5/10/11
