SERVICE MANUAL
Terminals:
Video In/Out (1)
S-Video Out (1 )
Audio (R/L) In/Out (1)
Tel Line (1)
Printer Port (DB25) (1)
WEBTV port (96 pin) (1)
IR Blaster Out (1)
CH3-CH4 Switch (1)
VHF/UHF In/Out (1)
AC In (1)
Mic Input
Dimensions:
355 mm x 73.5 mm x 226mm (w/h/d)
(w/h/d)
14 x 2
Weight:
3 kg (6 lbs. 10 oz.) (U.S.)
2.9kg (6 lbs. 6 oz.) (JAPAN)
MICROFILM
SPECIFICATIONS
(U.S.)
(U.S.)
(U.S.)
(JAPAN)
7
/
" x 8
57
"
/
8
64
— 1 —
INT-W200
INT-WJ200
Power Requirements:
120V AC 60Hz
100V AC 50/60Hz
Power Consumption:
38 W max
8 W stand by
Supplied Accessories:
Remote Control:
Size AA Batteries (2)
AC Power Cord (1) 1.9m
A/V (Audio/Video) Cable (1) 1.5m
Telephone Cable (1) 7.5m
T- Splitter (1)
IR Blaster (1) (U.S.)
S-Video Cable 1.5m (1)
Coaxial Cable (1) 1.5m
Optional Accessories:
Wireless Keyboard
INTERNET TERMINAL
INT-W200 / INT-WJ200
RM-Y801
RM-J313
U.S. Model
Japan Model
(U.S.)
(JAPAN)
RM-Y801(1)
(U.S.)
RM-J313 (1)
(JAPAN)
(U.S.)
RM-KW100, KI-W200 (U.S.)
KI-WJ200 (JAPAN)
Advertisement
Related Manuals for Sony INT-W200
Summary of Contents for Sony INT-W200
- Page 1 INT-W200 / INT-WJ200 INT-W200 RM-Y801 INT-WJ200 RM-J313 SERVICE MANUAL U.S. Model Japan Model SPECIFICATIONS Terminals: Video In/Out (1) Power Requirements: 120V AC 60Hz (U.S.) S-Video Out (1 ) 100V AC 50/60Hz (JAPAN) Audio (R/L) In/Out (1) Tel Line (1) Power Consumption:...
- Page 2 INT-W200 / INT-WJ200 SAFETY CHECK-OUT (U.S. Model only) After correcting the original service problem, perform the following safety checks before releasing the unit to the customer: 1. Check the area of your repair for unsoldered or 5. Look for parts which, though functioning, show obvious poorly-soldered connections.
-
Page 3: Table Of Contents
INT-W200 / INT-WJ200 TABLE OF CONTENTS Section Title Page 1. GENERAL ................... 4 2. DISASSEMBLY 2-1. Upper Case and Front Cover Removal....... 8 2-2. Power Supply Board, Hard Disk and Main PC Board Removal ..........8 3. SYSTEM DIAGNOSTIC TEST ..........9 4. -
Page 4: Disassembly
INT-W200 / INT-WJ200 SECTION 2 DISASSEMBLY 2-1. UPPER CASE AND FRONT COVER REMOVAL FOUR (4) SIDE OF COVER SCREWS (S) TIGHT +PTTWH 3X6 FOUR (4) BACK OF COVER SCREWS +BVTT 3X6 ONE (1) REAR PANEL SCREW 3X12 ONE (1) REAR PANEL SCREW... -
Page 5: System Diagnostic Test
INT-W200 / INT-WJ200 SECTION 3 SYSTEM DIAGNOSTIC TEST 3-1. INTRODUCTION: The following procedure is to test the WebTV (INT-W200/WJ200). 3-2. TEST EQUIPMENT REQUIRED: 1. PC (use Windows '95) 2. Oscilloscope (HP) or equivalent. 3. Digital Meter (FLUKE 87) or equivalent. -
Page 6: Power Supply Part List
INT-W200 / INT-WJ200 4.3 POWER SUPPLY PART LIST REF No. REF No. REF No. C601 0.1 250V D651 MA6D49 R603 15K 0.25W C602 220 200V D652 FCQ10A3L R604 220 1W C603 470p 1KV D653 FCQ6A4 R605 15.8K 0.25W C604 2200p 50V... - Page 7 INT-W200 / INT-WJ200 SECTION 5 EXPLODED VIEWS Note: • Items with no part number and no description are not stocked because they are seldom required for routine service. The components identified by shading and mark ¡ ¡ ¡ ¡ ¡ a re critical for safety.
-
Page 8: Main Pc Board Schematic
INT-W200 / INT-WJ200 SECTION 6 ELECTRICAL PARTS LIST Note: Note: Les composants identifies per un trame • Items marked " " are not stocked since they The components Identified by shading et une marque ¡ ¡ ¡ ¡ ¡ sont critiques pout la are seldom required for routine service. - Page 9 INT-W200 / INT-WJ200 REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK PACKING GROUP U0401 9-880-285-01 IC TC59S1616AFT-10 U0402 9-880-285-01 IC TC59S1616AFT-10 1-475-451-11 REMOTE COMMANDER (RM-Y801) (U.S.) U0403 9-880-285-01 IC TC59S1616AFT-10 1-475-452-11 REMOTE COMMANDER (RM-J313) (JAPAN) U0404...
- Page 10 INT-W200 / INT-WJ200 NOTES: — 50 —...
- Page 11 INT-W200 / INT-WJ200 NOTES: — 51 —...
- Page 12 INT-W200 / INT-WJ200 Sony Corporation English Sony Technology Center - San Diego 97LJ740005-1 Product Quality Division Printed in U.S.A. 9-978-839-01 Service Promotion Department © 1997.12 — 52 —...
