Features and Benefits
Rotary Cutters, Folding Deck
Features
Surpassed rugged
industry standards
Factory assembled
Fully welded deck
7 Year gearbox warranty*
250 HP Divider gearbox
210 HP center & wing gearboxes
Gearbox seal protection
2 3/8" Output gearbox shaft
Cat. 5 Input driveline
Star profile drivelines
Easy greasable drivelines
4 Plate slip-clutch
High blade tip speed
(See specifications for actual FPM)
6" Blade overlap
High cutting capacity
10 1/2" Deck height
3/16" Stump jumper backed
with a 1" thick mounting bar
3/16" Deck thickness
Self-leveling pull-type hitch
Hinged wing section
1" Solid hinge rods
Wing transport lock
Enclosed front to rear dual leveling
rods
Drain holes in wheel rims
5" Square rear axle tubing
Spring-cushioned center-axle
Replaceable wheel spindles
Double swivel hitch
Bar-tite hitch
5 or 6 Wheel option
Wheel options
Deck rings (optional)
* Years 6 & 7 Parts Only
Designs, specifications, features and information are subject to change without notice.
3/13/12
RC5014 & RCM5014 Models
All Land Pride Cutters have been designed and tested and meet rigorous voluntary testing
procedures specified by ANSI.
Saves customer set-up time and money.
Fully welded deck adds strength.
Shows confidence in gearbox.
A rugged heavy built gearboxes capable of handling heavy cutting applications.
Gearbox bottom seal protection for longer bearing life.
Large output shaft handles shock loads better.
Holds up to shock loads and harsh mowing conditions.
Star profile spreads load out to many points on the shaft. More apt to resist bending and
twisting under shock loads and harsh mowing conditions.
Drivelines have access holes for greasing the U-joints and to grease the inner profiles.
Protects drivelines and gearboxes by slipping clutches rather than twisting the driveline
when impacts are encountered.
Allows for a clean cut of material and even distribution.
Generous blade overlap eliminates skipping, especially in turns.
Can cut brushy areas with saplings up to 3".
Handles heavy cutting, which reduces balling-up of cut material under the deck.
Heavy round stump jumper with bottom gearbox seal protector. Can hold up to tough
conditions.
Heavy enough to handle conditions but not weigh unit down.
Reduces drawbar wear by keeping hitch level while going through ditches.
cutter
Allow
to follow terrain. Ideal for rough ground where hillsides, ditches and hollows
can cause uneven cutting.
Larger diameter hinge rod gives greater strength to the
hinge area itself.
Safety feature. Holds wing section up in case of hydraulic pressure loss.
Dual leveling rods enable the
rough terrain. Many competitors only use one leveling rod.
Allows water to drain from wheels mounted on the folded-up wing.
Helps prevent paint deterioration and rusting to the wheel rims.
Heavy axle to handle harsh conditions.
Protects unit from bumps and ground shock.
Wheel spindles can be replaced when damaged without replacing the entire axle. Simply
remove two bolts to replace damaged spindle.
Great for uneven terrain, reduces drawbar wear.
Ideal for extreme conditions. Clamps tight to drawbar eliminating drawbar wear.
Dual wheels on the outer wing are ideal when mowing in areas where the wing needs to
flex up hill. The outer wheel rides farther up the embankment and keeps the deck from
gouging.
The extra wheel on the outer wing deck provides better load distribution.
Laminated tires: Eliminates flats.
Airplane tires without foam filling: Give better cushion while transporting.
Airplane tires with foam filling: Give better cushion while transporting and can't go flat.
1/2" x 3" full welded deck ring keeps blades from damaging the deck.
Benefits
cutter
cutter
to pull equally on the rear axle during travel over
from front to rear, and in the
87
330-117F
