Yamaha DP-U50 Service Manual

Personal sound processer
Hide thumbs Also See for DP-U50:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual , Setup Manual
PERSONAL SOUND PROCESSER
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore,
inevitable and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist,
please contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
TO SERVICE PERSONNEL ........................................... 1
INTERNAL VIEW ............................................................ 4
DISASSEMBLY PROCEDURES .................................... 4
SELF DIAGNOSIS FUNCTION ............................... 5 - 13
STANDARD OPERATION CHART .............................. 14
IC DATA ................................................................ 15 - 24
1 0 0 7 3 6
DP-U50
SERVICE MANUAL

IMPORTANT NOTICE

Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these
reasons, we advise all YAMAHA product owners that any service required should be performed by an
authorized YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification
or recognition of any applicable technical capabilities, or establish a principle-agent relationship of any
form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this
buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the
unit.
DISPLAY DATA ............................................................ 25
BLOCK DIAGRAM ................................................ 26 - 27
PRINTED CIRCUIT BOARD ................................. 28 - 35
IC BLOCK ............................................................. 36 - 37
SCHEMATIC DIAGRAM ....................................... 38 - 39
PARTS LIST .......................................................... 40 - 49
REMOTE CONTROL TRANSMITTER .......................... 50
PARTS LIST FOR CARBON RESISTORS .................. 51
DP-U50
