Oregon Scientific ES062 User Manual

Solar Charger
Model: ES062
User Manual
EN
INTRODUCTION
Thank you for purchasing the new Oregon Scientific™ solar charger
(ES062). The ES062 is a portable back-up battery can be used
on-the-go. Its innovative and versatile design allows you to charge
Smartphones or tablets simultaneously utilizing the dual USB
charging ports. With front solar panel and USB charging options,
it gives you the freedom to re-charge wherever you are. Providing
power at your fingertips, Solar Charger is the perfect green charging
solution for all your on-the-go charging needs.
Features:
• Portable power bank with dual charging option – Solar powered
or via Standard USB
• Compatible with most Smartphones and tablet devices
• Smart LED charging and discharging status indicator
• Automatic device charging detection
• Input USB cable and Output Micro-USB charging cables included
• Made with crystal silicon solar panel
NOTE This manual contains important safety and product care
information, and provides step-by-step instructions for using this
product. To get the greatest benefit from your purchase, read the
manual thoroughly, and keep it in a safe place in case you need
to later refer to it.
IMPORTaNT Do not immerse the Solar Charger in water.
OVERVIEW
5V/1A
Micro USB input
LED
Power
button
High efficiency
5V/2.1A
Solar Panel
USB output
5V/1A Micro USB output
CHaRGE THE SOLaR CHaRGER
The Solar Charger can be charged from three different interfaces:
1. Charge via standard USB port Suggested charging time : 10-12
hours
2. Charge via USB AC adapter (5V/1A adapter, not included).
Suggested charging time: 6-8 hours
(referred to as this "Guarantee" or as a "Warranty") issued by Oregon
Scientific (UK) Limited ("Oregon Scientific") a Company registered
in England under Number-03506768 having its registered Office
at Suites 3/5 Old Bank House 39 High Street, High Wycombe
Buckinghamshire, HP11 2AG, UK
Help Line Telephone Number: 0871 222 1966 (09:00 a.m.-18:00 p.m.)
E-Mail: Technical@oregonuk.com
Product Model: Date of Purchase:
Buyer / Customer:
Name in Full:
Address:
Telephone Number: Fax Number:
Product Defect:
By this consumer Guarantee, Oregon Scientific guarantees the
Product to be free from defeets in materials and workmanship for a
period of 1 (one) YEARS from the date of its original purchase.
If during this period of guarantee the Product proves defective due
to improper materials or workmanship, the Product should be taken
to the place of purchase, accompanied by the original sales receipt,
whereupon you will be entitled to either a replacement (if available) or,
at the discretion of the dealer a refund in full.
NOTE If the battery is fully charged, all four LED indicators are
on and the forth LED does not flash.
Green
3. Charge via solar power
Expose the face of the solar panel to full sunlight condition.
The first LED red indicator light will go on indicating that the
charging is beginning. The charging current depends on the
quality of the sunshine. The stronger the light is, the faster the
battery will be charged.
Suggested charging time: 15-17 hours
NOTE Charging through the solar panel is an auxiliary method of
a normal USB charging. The solar charging time depends on the
intensity of particular sunlight, which takes longer time. We highly
recommend the USB charging as the first priority.
POWER bUTTON
After cable connection with your device,
press the power button to start charging.
LED INDICaTOR
The front panel of your Solar Charger has four LED lights to show the
charging status, working status and the remaining power as follows:
1 LED on
2 LED on
3 LED on
4 LED on
CHaRGE ELECTRONIC HaNDHELD DEVICES
1. Universal USb output
Press the button and connect the product into your devices.
Meanwhile, the power indication lights will go gradually.
2. Micro USb output
Take out the built-in Micro USB cable and connect to the device
with Micro USB input dock, press the button, then charging
begins. LED indicators will go down one by one, all LED lights
go off without power.
5V/1A
USB input
IMPORTaNT
1. The surface of your device will get hot if it is charged for a long time.
Do not place the charger in any textile item.
2. For safety precaution in case of consumption of current higher
than 2.1A, the output charging will be automatically turned off.
SPECIFICaTIONS
TYPE
Dimension (L x W x H) 71.5mm x 124mm x 16mm
Weight 145g
Power display 4 LED indicators shows power level
Battery type Lithium polymer
CERTIFICaTE OF GUaRaNTEE
Oregon Scientific accepts no responsibility for Products returned to
its own premises.
Conditions.
1. This Guarantee will be honoured only when the original invoice
or sales receipt(indicating the date of purchase, product type and
dealer's name) is presented together with the defective Product.
Oregon Scientific reserves the right to refuse the free-of-charge
guarantee service if the above document cannot be presented or
the information contained in it is incomplete or illegible.
2. This Guarantee will not reimburse nor cover damage resulting from
adaptation or adjustments which may be made to the Product,
without the prior written consent of Oregon Scientific, in order to
conform to the national or local technical or safety standards in
force in any country other than the ones for which the Product was
originally designed and manufactured.
3. This Guarantee will not apply if the serial number on the Product
has been altered, deleted, remnved or made illegible.
4. This Guarantee covers none of the following:
a) Periodic maintenance and repair or replacement of parts due to
normal wear and tear:
b) Any adaptation or changes to upgrade the Product :from its
normal purpose as described in the instrnction manual, without
the prior written consent of Oregon Scientific:
10%-40% charge
40%-65% charge
65-85% charge
85-100% charge
DESCRIPTION
Solar Panel 5.5V / 220mA
Rechargeable battery
3.7V / 4,000mAh
capacity
Micro USB 5V/1A
Input
USB cable 5V/1A
5V/2.1A USB port
Ouput
5V/1A Micro USB cable
INFORMaTION FOR USERS
Pursuant to and in accordance with Article 14 of the
Directive 2012/19/EU of the European Parliament on
waste electrical and electronic equipment (WEEE), and
pursuant to and in accordance with Article 20 of the
Directive 2006/66/EC of the European Parliament on
batteries and accumulators and waste batteries.
The barred symbol of the rubbish bin shown on the
equipment indicates that, at the end of its useful life, the product
must be collected separately from other waste.
Please note that the batteries / rechargeable batteries must be
removed from the equipment before it is given as waste. To remove
the batteries / accumulators refer to the specifications in the user
manual. Therefore, any products that have reached the end of their
useful life must be given to waste disposal centres specialis-ing in
separate collection of waste electrical and electronic equipment, or
given back to the dealer when purchasing a new WEEE, pursuant
to and in accordance with Article 14 as implemented in the country.
The adequate separate collection for the subsequent start-up of
the equipment sent to be recycled, treated and disposal of in an
environmentally compatible way contributes to preventi-ng possible
negative effects on the environment and health and optimises the
recycling and reuse of components making up the apparatus.
Abusive disposal of the product by the user involves application of
the administrative sanctions according to the laws in force.
PRECaUTIONS
• Do not puncture, throw, drop, bend or modify your ES062.
• Do not expose the battery to fire or excessive heat
• Do not short-circuit the battery with lead or any metal objects.
• Do not transport or store the battery with metal objects such as
nail clippers.
• Avoid static electricity, strong magnetic fields and radiation.
• Do not disassemble the battery pack or change its structure.
• Stop using the battery when it generates unusual smell, heating,
distortion or any other abnormalities.
• Do not allow children to play with ES062.
• Use the battery in dry locations only
• Do not clean with abrasive and corrosive substances and
materials or alcohol, but with a damp cloth.
abOUT OREGON SCIENTIFIC
Visit our website www.oregonscientific.com to learn more about
Oregon Scientific products.
For any enquiry, please contact our Customer Services at
info@oregonscientific.com.
Oregon Scientific Global Distribution Limited reserves the right to
interpret and construe any contents, terms and provisions in this
user manual and to amend it, at its sole discretion, at any time
without prior notice. To the extent that there is any inconsistency
between the English version and any other language versions, the
English version shall prevail.
EU-DECLaRaTION OF CONFORMITY
Hereby, Oregon Scientific, declares that Solar Charger (model:
ES062) is in compliance with the essential requirements and other
relevant provisions of Directive 2004/108/EC. A copy of the signed
and dated Declaration of Conformity is available on request via our
Oregon Scientific Customer Service.
c) Accessories
d) Damage resulting from:
i. Misuse, including but not limited to (a) failure to use the Product
for its normal purpose or in accordance with Oregon Scientifics'
instructions on the proper use and maintenance; and (b)
installation or use of the Product in a manner inconsistent with
the technical or safety standards in force in the country where
it is used; and (c) improper or incorrect installation of software;
ii. Impact of any kind;
iii.Repair done by non authorized Service Dealers, or the
customer themselves;
iv.Accidents, lightning, water, fire, improper ventilation or any
cause beyond the control of Oregon Scientific;
v. Defects of the system into which the Product is incorporated:
5. The Warranty given will be immediately void in all the cases where
the failure is due to misuse. bad power supply or connection, use of
non-original accessories or failure caused by impact or low batteries.
This Guarantee does not affect the consumer's statutory rights under
applicable national laws in force, nor the consumer's right against the
dealer arising from their sales/purchase contract.
