NEC Express5800/T110f-S
System Configuration Guide
Air cooling model
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC Express5800 server.
January 16, 2014
Revision 3.0
NEC Corporation
Advertisement
Table of Contents
Related Manuals for NEC Express 5800 T110F-S
Summary of Contents for NEC Express 5800 T110F-S
- Page 1 System Configuration Guide Air cooling model Introduction This document contains product and configuration information that will enable you to configure your system. The guide will ensure fast and proper configuration of your NEC Express5800 server. January 16, 2014 Revision 3.0 NEC Corporation...
-
Page 2: Table Of Contents
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Contents TECHNICAL SPECIFICATION ..................3 Key Features ............................3 Specification ............................3 EXTERNAL VIEWS ......................7 Front View .............................. 7 Rear Views ............................. 7 Dimensions (mm) ..........................8 CONFIGURATION DIAGRAM ..................10 Expansion Slots .......................... -
Page 3: Technical Specification
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Technical Specification Key Features Ultra compact form of 98 mm in width, 13 liters in volume Up to 32 GB of high speed DDR3-1600 memory Full manageability by integrated EXPRESSSCOPE Engine 3 ... - Page 4 For Windows Server 2012 R2 installation, download the driver kit from the following website and install it after OS installation http://www.nec.com/en/global/prod/express/download/ For Linux support, contact your sales representative or go to the NEC website at: http://www.nec.com/global/prod/express/linux/index.html Support on Xeon and Core processor systems only.
- Page 5 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Internal Storage Standard Capacity 0 GB Maximum Capacity 10.4 TB (2 x 4 TB plus 2 x 1.2 TB) Disk Controller SATA : 6Gb/s (Integrated) RAID SATA : RAID 0/1/10 (Standard), RAID 5/6/50 (Optional)
- Page 6 For Windows Server 2012 R2 installation, download the driver kit from the following website and install it after OS installation http://www.nec.com/en/global/prod/express/download/ For Linux support, contact your sales representative or go to the NEC website at: http://www.nec.com/global/prod/express/linux/index.html Revision 3.0 – January 16, 2014...
-
Page 7: External Views
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model External Views Front View Legend Power Button Optical Disk Drive Power LED 3.5-inch Media Bay 1 Drive Activity LED 3.5-inch Media Bay 2 System Status LED Drive Bay Cover Key USB 2.0 Connector... -
Page 8: Dimensions (Mm)
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Dimensions (mm) Standard Bezel Tower Orientation Desktop Orientation Revision 3.0 – January 16, 2014 NEC Corporation... - Page 9 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Dust Proof Bezel Tower Orientation Desktop Orientation Revision 3.0 – January 16, 2014 NEC Corporation...
-
Page 10: Configuration Diagram
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Configuration Diagram Legend: Standard Components Mandatory Components Revision 3.0 – January 16, 2014 NEC Corporation... -
Page 11: Expansion Slots
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Expansion Slots Legend PCIe 2.0 x1, x8 connector, Low Profile, up to 168mm length PCIe 2.0 x1, x8 connector, Low Profile, up to 168mm length PCIe 3.0 x16, x16 connector, Low Profile, up to 168mm length PCIe 2.0 x4, x8 connector, Low Profile, up to 168mm length... -
Page 12: Server Configuration
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Server Configuration 1 Base Models Product Name / Description Part Number NEC Express5800/T110f-S N8100-1983F no CPU, no RAM, no Drive Cage, no HDD, no Optiocal Drive Including: 250 Watt non-hot plug power supply, EXPRESSBUILDER DVD... -
Page 13: Maximum Available Memory
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Maximum Available Memory See the table below for the maximum memory size that you can actually use on your system. The maximum available memory is less than the maximum physical memory supported by your system because some chipsets require PCI resource space of about 750MB. -
Page 14: Internal Hard Disk Drives
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4 Internal Hard Disk Drives RAID Configuration Refer to the section in accordance with your disk form factor and RAID configuration 4.1.1 2.5-inch Drive Up to four Drives Available Interface... -
Page 15: Inch Drive
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.1.2 3.5-inch Drive Up to two 3.5-inch Drives Available Interface SATA Non-RAID Refer to 4.3.1 Embedded SATA SATA Refer to 4.3.2 RAID Controller RAID 0/1 SATA Optional RAID 0 MB Cache Refer to 4.3.3... -
Page 16: Inch Drive Configuration
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 2.5-inch Drive Configuration 4.2.1 Up to four Drives with Embedded SATA non-RAID Controller Category Product Name / Description Part Number Storage Controller Embedded SATA Controller (Standard) 4x 6Gb/s SATA Cable... - Page 17 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.3 Up to four Drives with RAID 0/1 Controller without Cache Category Product Name / Description Part Number Storage Controller RAID Controller (0MB, RAID 0/1) N8103-171 Required LSI MegaRAID SAS 9240-8i RAID0/1/10, 0MB, Int.
- Page 18 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.4 Up to four Drives with RAID 0/1 Controller with 512 MB Cache Category Product Name / Description Part Number Storage Controller RAID Controller (512MB, RAID 0/1) N8103-149 Required LSI MegaRAID SAS 9267-8i RAID0/1/10, 512 MB, Int.
- Page 19 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.5 Up to four Drives with RAID 5/6 Controller with 512 MB Cache Category Product Name / Description Part Number Storage Controller RAID Controller (512MB, RAID 0/1/5/6) N8103-150 Required LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 512 MB, Int.
- Page 20 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.6 Up to four Drives with RAID 5 Controller with 1 GB Cache/Battery Category Product Name / Description Part Number Storage Controller RAID Controller (1GB, RAID0/1/5/6) N8103-151 Required LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 1 GB, Int.
- Page 21 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.7 Up to four Drives with RAID 5 Controller with 1 GB Cache/CacheVault Category Product Name / Description Part Number Storage Controller RAID Controller (1GB, RAID 0/1/5/6) N8103-167 Required LSI MegaRAID SAS 9270CV-8i (with CV) RAID0/1/5/6/10/50/60, 1GB Cache, Int.
- Page 22 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.8 Up to six Drives with RAID 0/1 Controller without Cache Category Product Name / Description Part Number Storage Controller RAID Controller (0MB, RAID 0/1) N8103-171 Required LSI MegaRAID SAS 9240-8i RAID0/1/10, 0 MB, Int.
- Page 23 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.9 Up to six Drives with RAID 0/1 Controller with 512 MB Cache Category Product Name / Description Part Number Storage Controller RAID Controller (512MB, RAID 0/1) N8103-149 Required LSI MegaRAID SAS 9267-8i RAID0/1/10, 512 MB, Int.
- Page 24 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.10 Up to six Drives with RAID 5/6 Controller with 512 MB Cache Category Product Name / Description Part Number Storage Controller RAID Controller (512MB, RAID 0/1) N8103-150 Required LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 512 MB, Int.
- Page 25 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.11 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/Battery Category Product Name / Description Part Number Storage Controller RAID Controller (1GB, RAID0/1/5/6) N8103-151 Required LSI MegaRAID SAS 9267-8i RAID0/1/5/6/10/50/60, 1 GB, Int.
- Page 26 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.2.12 Up to six Drives with RAID 5/6 Controller with 1 GB Cache/CacheVault Category Product Name / Description Part Number Storage Controller RAID Controller (1GB, RAID 0/1/5/6) N8103-167 Required LSI MegaRAID SAS 9270CV-8i (with CV) RAID0/1/5/6/10/50/60, 1GB Cache, Int.
-
Page 27: Inch Drive Configuration
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 3.5-inch Drive Configuration 4.3.1 Embedded SATA non-RAID Controller Category Product Name / Description Part Number Storage Controller Embedded SATA Controller (Standard) 4x 6Gb/s SATA Cable Internal SAS/SATA Cable K410-278(00) Required... - Page 28 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.3.3 Up to two Drives with RAID 0/1 Controller without Cache Category Product Name / Description Part Number Storage Controller RAID Controller (0MB, RAID 0/1) N8103-171 Required LSI MegaRAID SAS 9240-8i RAID0/1/10, 0MB, Int.
- Page 29 – SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 4.3.5 3.5-inch and 2.5-inch Drives with RAID 0/1 Controller with 512 MB Cache Category Product Name / Description Part Number Storage Controller RAID Controller (512MB, RAID 0/1) N8103-149 Required LSI MegaRAID SAS 9267-8i RAID0/1/10, 512 MB, Int.
-
Page 30: Internal Optical Drive
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 5 Internal Optical Drive Category Product Name / Description Part Number Internal Internal Slim DVD-ROM drive N8151-119 1 slot available Slim DVD-ROM drive Required Internal DVD Super Multi Drive N8151-107F... -
Page 31: Pci Card
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 6.2.2 RDX Drive Category Product Name / Description Part Number Controller Internal USB Controller (Standard) 1 x USB port Cable Internal USB cable K410-276(00) Required 1x Internal USB to 1x USB device... -
Page 32: Sas Controller
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Using iSCSI See the table below for supported network interfaces and OS combinations. Category Network Interface Operating Systems Embedded 1GbE NIC Windows Server 2008 R2, Windows Serer 2012, RHEL*, VMware... -
Page 33: Other Add-In Components
- The following operations can be performed with the flash memory: - Installation of Windows server with express setup - Installation of Starter Pack—the package of NEC qualified drivers and system setting tools - Installation of NEC ESMPRO Agent and Universal RAID Utility... -
Page 34: Add-On Components
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model 9 Add-on Components Server Management License The server integrates the EXPRESSSCOPE Engine 3 as standard. Refer to Server Management for the standard management features. For more extensive remote KVM and remote media features, choose the following kit. -
Page 35: Medium And Cartridge
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Medium and Cartridge Category Product Name Drive supported Part Number RDX Cartridge (320GB) N8151-105 N8153-01 RDX Cartridge (500GB) N8151-105 N8153-02 RDX Cartridge (1TB) N8151-105 N8153-03 RDX Cartridge (1.5TB) N8151-105 N8153-04... -
Page 36: References
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model References Server Management The EXPRESSSCOPE Engine 3, integrated into the server, provides superior remote control and system management features listed in the table below. Standard With Remote KVM and Media License ... -
Page 37: Os Support Matrix For Pci Cards And Embedded Controllers
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model OS Support Matrix for PCI Cards and Embedded Controllers Part Number Product Name Embedded SATA non-RAID Controller Embedded SATA RAID Controller Embedded 1GbE NIC - ... -
Page 38: Copyright Notice And Liability Disclaimer
All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders. NEC shall not be liable for technical or editorial errors or omissions contained herein. For hard drive capacity measurements, 1 GB = 1 billion bytes. Actual formatted capacity is less. -
Page 39: Revision History
– SYSTEM CONFIGRATION GUIDE NEC Express5800/T110f-S / Air cooling model Revision History Revision Date Description New products added: January 16, 2014 RDX Cartridge (SSD/128G) / N8153-06 RDX Cartridge (SSD/256GB) / N8153-07 Others: Add Windows Server 2012 R2 to the list of operating system supported...
