Heat & Glo VRTIKL-AU Installation & Operation Instructions

Hide thumbs Also See for VRTIKL-AU:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Install and Operation Instructions
Model:
VRTIKL-AU
FREESTANDING STOVE
This appliance has been retired.
Service parts pages within have been removed.
For replacement parts, please refer to the individual
service parts list located on the brand websites.
AUSTRALIAN GAS ASSOCIATION CERTIFIED
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance.
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
Certifi cate Number: 7153
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10
Installation & Operation
Instructions
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
Installation and service of this gas stove should be per-
formed by qualifi ed personnel.
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo VRTIKL-AU

Summary of Contents for Heat & Glo VRTIKL-AU

  • Page 1 - If you cannot reach your gas supplier, call the fi re department. • Installation and service must be performed by a qualifi ed installer, service agency, or the gas supplier. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 2 fi re hazard and will void the warranty. Save this manual for future reference. Heat & Glo, a brand of Hearth & Home Technologies, Inc. 7571 215 Street West, Lakeville, MN 55044 Copyright 2009 • Printed in U.S.A. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 3: Table Of Contents

    A. Ignition System Wiring ......22  = Contains updated information. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 4: Listing And Code Approvals

    Immediately call a qualifi ed service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 5: Framing And Clearances

    Section 11. B. Clearances to Combustibles “A” measurement is from gas stove top, not side. Note: Mantel must Alcove maintain 25mm clearance from vertical fl ue. Millimeters 1372 Figure 2.1 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 6: Optional Stone Surround Installed

    fl oor strong enough to support gas stove without tipping. • USE wood fl ooring, ceramic tile, brick hearth or high pressure laminate fl ooring applied directly over the sub-fl ooring material. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 7: Termination Locations

    (GAS ONLY) pitched roofs. Balanced Flue Natural Draft Gas, Wood & Gas Termination Fuel Oil Termination 1000 mm 510 mm 0 mm 460 mm Figure 3.2 Multiple Vertical Termination Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 8 A fl ue terminal is considered to be a source of ignition. MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS OR THE FLUE TERMINALS OF OUTDOOR APPLIANCES Figure 3.4 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 9: Flue Information

    • Pipe measurements are from center line to center line. • Horizontal terminations are measured to the outside edge of termination cap. See Figure 3.1. • Horizontal pipe installed level with no rise. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 10: Flue Diagrams

    Note: For this type of installation, the vertical fl ue restrictor must be added. See section H for instructions. Figure 4.1 STRAIGHT OUT HORIZONTAL FLUE 610 mm Maximum For Natural and Propane Gases. Figure 4.2 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 11 H Maximum 460 mm 920 mm 920 mm 1.8 M 1.4 M 2.8 M 1.8 M 3.6 M V+H = Max 11 M H Max = 3.6 M Figure 4.4 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 12 1.5 M 2.7 M V+H1+H2 = Max 10M H1 Max = 2.2M H1+H2 = Max 4.5M V+H1+H2 = Max 10M H1 Max = 1.5M H1+H2 = Max 2.7M Figure 4.6 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 13 V Min. H1+H2 Max. 61 cm 1.0 M 91 cm 1.5 M 1.2 M 2.0 M 1.5 M 2.6 M V+H1+H2 = Max 11.4M H1+H2 = Max 2.6M Figure 4.8 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 14 340 mm 550 mm 920 mm 650 mm 1.1 M 1.4 M 1.0 M 1.6 M 1.8 M 1.8 M 2.1 M V1+V2+H1+H2=Max 10M H1 Max=1.8M H1+H2=Max 2.1M Figure 4.10 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 15: Horizontal Termination

    • Continue adding flue components, locking each succeeding component into place. • Ensure that each succeeding fl ue component is securely fi tted and locked into the preceding component. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 16: Slim Line Heat Shield

    • Wear protective gloves and safety crete, or other types of sidings. The trim ring may be glasses during installation. sealed with high temperature caulk or high temperature adhesive. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 17 MINIMUM OF 152 mm OF PIPE THROUGH THE WALL INTERIOR WALL 76mm CLEARANCE FROM REAR OF STOVE CENTER LINE HEAT SHIELD OVER TOP HALF OF PIPE TRIM RING Figure 4.17 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 18: Vertical Termination

    • Do not pack air space with insulation or other materials. Failure to keep insulation or other materials away from fl ue pipe may cause fi re. Figure 4.20 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 19 Ensure the roofing material overlaps the top edge of the flashing as shown in Figure 4.22. Verify that the chimney is the required height above the roof. See roof pitch table, Figure 3.3. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 20: Vertical Flue Restrictor

    Do not fill any of the required air space with insulation. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 21: Gas Information

    .80 kPa 2.40 kPa Max. Gas Consumption 26.7 mJ 24.5 mJ Burner Injector 2.53 mm 1.45 mm Burner Air Shutter (2 Openings) 13mm x 18mm 11.5 x 18 mm Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 22: Electrical Information

    BATTERY PORT (4 AA BATTERIES) THERMOCOUPLE BLOCK (CONNECTED TO ON/OFF BACK OF VALVE) SWITCH VALVE PILOT GAS LINE CONNECTED TO BACK OF VALVE Figure 6.1 Electronic Ignition Wiring Diagram Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 23: Appliance Setup

    After unbolting the gas stove from the pallet, insert two Figure 7.2 1/4 20 x 1-1/2 (or equivalent) counterscrews. Using pliers, adjust the counterscrews to level the gas stove. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 24: Accessories

    • Only Hearth & Home Technologies approved accessories may be used safely. 5. Remove the four screws from the DV adapter collar (Figure 7.8). Set aside DV adapter collar and screws. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 25 I NNER EXTENSION COLLAR NNER EXTENSION COLLAR Figure 7.11 Figure 7.9 7. Install the cover plate with gasket to the top of gas stove with screws previously removed (Figure 7.10). Figure 7.10 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 26: Positioning The Logs

    Apply 15 mm size pieces sparingly along ports as shown. Place log #1 into the cradle in the burner. Lean the log Do not block ports. back towards right corner of firebox. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 27: Operating Instructions

    For protection of young children or the infi rm, a secondary • Do not spray aerosols in the vicinity of this guard is required. appliance while it is in operation. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 28: Lighting The Appliance

    For use with natural or propane gases. 1. Push the ‘OFF’ button on remote. Keep burner and control compart- ment clean. See installation and 2. Remove batteries from receiver. operating instructions accompany- ing heater. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 29: After Appliance Is Lit

    Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the gas stove. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 30: Maintaining And Servicing Appliance

    Figure 8.18 WARNING Inspect external vent cap regularly. • Ensure no debris blocks cap. • Combustible materials blocking cap may ignite. • Restricted air fl ow affects burner operation. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 31: Maintenance Tasks

    4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and fl ashing remains intact. Remote Control 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 32: Troubleshooting

    Ignitor gap is too Verify that spark gap from ignitor to pilot hood is .43 cm. large. Module is not Verify module is securely grounded to metal chassis of stove. grounded. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 33: Reference Materials

    Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. Height includes 9.53 mm hearth pad. Hearth Pad Millimeters 1035 1025 Figure 11.1 Appliance Dimensions Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 34: Appliance Dimension With Stone Surround Diagram

    B. Appliance Dimension with Stone Surround Diagram Hearth Pad Height includes 9.53 mm hearth pad. Height includes 9.53 mm hearth pad. Millimeters 1126 Figure 11.2 Appliance Dimensions with Stone Surround Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 35: Flue Components List

    7/12 - 12/12 Roof Flashing SL-SCD Storm Collar SLP-FS Ceiling Firestop SLP-WS Wall Firestop SLP-HVS Pipe Support Hanger Vinyl Protector Kit - SLP Pipe DRC-RADIUS Decorative Radius Cover HTI-DV-WT Wall Thimble Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 36: Service Parts

    E. Limited Lifetime Warranty Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
  • Page 37 Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...

  • Page 38: Contact Information

    6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408; (Australia) 543790;586383; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending. Heat & Glo • VRTIKL-AU • 2123-900 Rev. H • 10/10...
