OWNER'S MANUAL
Congratulations on the purchase of your new Kustom Profile System Two; a portable
and powerful stereo P.A. System. Your new system offers unsurpassed sound quality
as well as outstanding performance characteristics. Inside this manual you'll find
detailed information regarding the system's many features. We wish you many years
of enjoyment with your Kustom Profile System Two.
Advertisement
Table of Contents
Related Manuals for Kustom Profile System Two
Summary of Contents for Kustom Profile System Two
- Page 1 OWNER’S MANUAL Congratulations on the purchase of your new Kustom Profile System Two; a portable and powerful stereo P.A. System. Your new system offers unsurpassed sound quality as well as outstanding performance characteristics. Inside this manual you’ll find detailed information regarding the system’s many features. We wish you many years...
-
Page 2: Important Safety Instructions
ENGLISH Danger Exposure to extremely high noise levels may cause a permanent hearing loss. Individuals vary considerably to noise induced hearing loss but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient time. The U.S. Government's Occupational Safety and Health Administration (OSHA) has specified the following permissible noise level exposures: DURATION PER DAY (HOURS) - Page 3 FRENCH Danger L‘exposition a des niveaux eleves de bruit peut provoquer une perte permanente de l’audition, Chaque organisme humain reagit differemment quant a la perte de l’audition, mais quasiment tout le monde subit une diminution de I’acuite auditive lors d’une exposition suffisamment longue au bruit intense.
-
Page 4: Table Of Contents
Table of Contents Profile System Two Contents Optional Accessories Profile System Two Features Setup Diagram A - Mixer Front Setup Diagram B - Mixer Back Setup Diagram C - Speaker Cabinet Back Setup Instructions About the Master Section About the Input Section... -
Page 5: Profile System Two Contents
Profile System Two Contents These items are included with your Profile System Two: • (1) 300-Watt Stereo Powered Mixer • (2) Line Array Speaker Cabinets • (2) 25-Foot Speaker Cables • Owner’s Manual • Warranty Card Optional Accessories: • Convenient Roller Bag for Easy Transport (KPSRB220) •... -
Page 6: Setup Diagram Amixer Front
SETUP DIAGRAM A MIXER FRONT... -
Page 7: Setup Diagram Bmixer Back
SETUP DIAGRAM B MIXER BACK... -
Page 8: Setup Diagram Cspeaker Cabinet Back
SETUP DIAGRAM C SPEAKER CABINET BACK Speaker Input Jack ( ) This jack is used to connect the Speaker Output Jack ( or ) to the speaker. This should be connected with a good quality speaker cable. -
Page 9: Setup Instructions
Setup Instructions: Making Connections: • Using the Profile speaker cables, or a set of your own, connect an end of each cable into the speaker outputs of the mixer ( & ). Then connect the opposite end of each cable to the appropriate speaker cabinet input ( ). -
Page 10: About The Master Section
The master section gives you final control over the sum of what is happening in the input section. In other words, the adjustments you make in this section will affect all channels evenly. Sub Volume Control ( ) When using a powered subwoofer that is connected into the sub output jack ( ), this control becomes a volume control for the subwoofer. -
Page 11: About The Input Section
The input section is where you connect microphones, guitars, drum machines, keyboards, and other audio sources. Effects Control ( ) This control is used to send the signal from the individual channel to the digital effects. The effects volume control ( ) adjusts the overall volume for this control. Monitor Control ( ) This control is used to send the signal from the individual channel to the monitor output jack ( ). - Page 12 Methods for connecting inputs to channels Method 1: Microphone using XLR balanced inputs - This is the most popular method for connecting microphones. It works with both dynamic and condenser low impedance microphones. Acoustic guitars that have XLR balanced outputs can also use this input. Because of the phantom power on these inputs, a battery may not be needed.
- Page 13 Combination Input Jack ( ) This jack functions the same as the other combination jacks ( ) except the 1/4” input can be stereo, mono, or hi-Z mono. String instruments, such as acoustic guitar that have a passive pickup (non- battery powered) are typically hi-z mono and will work best in this channel.
-
Page 14: About The Output Section
The left on the Pan Control ( ) will then correspond to the left speaker. AC Input Jack ( ) This jack is used to connect AC power to the Profile System Two. About the Output Section... -
Page 15: Faq Frequently Asked Questions
FAQ Frequently Asked Questions: 1. How many speakers can I use with the Profile Two? ANSWER: Most speaker cabinets today are 8-ohms. For the sake of this question we will assume this is the case. You can use a total of four 8-ohm speakers with the Profile Two: Two for the Left power-amp and two for the Right power-amp. -
Page 16: Amplifier Loading Chart
The Profile System Two mixer and speakers have been specifically designed and optimized for use together as a package. The mixer has been designed to deliver maximum power with a 4-ohm load on each channel. If you choose to use different speakers with the mixer, refer to the chart below for loading information. -
Page 17: Block Diagram
LEFT EFFECTS RIGHT EFFECTS LEFT MAIN RIGHT MAIN MONITOR signal sensor LEFT EFFECTS RIGHT EFFECTS LEFT MAIN RIGHT MAIN MONITOR... -
Page 18: Specifications
240VAC/50Hz, 200W nominal 100VAC/50-60Hz, 200W nominal 345 (Height) x 252 (Width) x 290 (Depth), 11 kg 13.6 (Height) x 10 (Width) x 11.5 (Depth), 24.2 lbs Profile System Two Loudspeaker System EIA RS-426 Program Power (music power) +/- 3dB Per Cabinet, Accurate acoustical response 542 (Height) x 272.2 (Width) x 290 (Depth), 11.6 kg... -
Page 19: Ec Declaration Of Conformity
Following the provisions of EU Council Directive(s): 72/73 EEC and 89/336/EEC. We the undersigned, hereby declare that the equipment specified above conforms to the aforementioned directive(s). Name of authorized person: James Brown, Chief Engineer Signature:______________________ Kustom Musical Amplification Inc. 4940 Delhi Pike Cincinnati, OH 45238 Tel: 1-513-451-5000 Fax: 1-513-347-2192... -
Page 20: Kustom Contact Information
Kustom Amplification Inc., 4940 Delhi Pike, Cincinnati, OH • USA ® (800) 999-5558 Web: www.kustom.com...
