Parts List - Kenmore 122.16648900 User Manual

KEY# PARTS
1 650A-001 Temperature Gauge
2 650A-002 Main Lid Screw
3 650A-003 Main Lid
4 650A-004 Logo
5 650A-005 Main Lid Handle Heat Insulating Spacer
6 650A-006 Hood Buffer
7 650A-007 Main Lid Handle
8 650A-008 Side Shelf Handle, Left
9 650A-009 Side Shelf Front Panel, Left
10 650A-010 Hooks
11 650A-011 Bottle Opener
12 650A-012 Side Shelf, Left
13 650A-013 Main Burner Bow l Assembly
14 650A-014 Front Baffle
15 650A-015 Main Gas Valve
16 650A-016 Main Manifold
17 650A-017 Regulator, LP
18 650A-018 Side Burner Hose
19 650A-019 Rotisserie Gas Valve
20 650A-020 Main Control Panel
21 650A-021 Control Knob
22 650A-022 Ligh Sw itch
23 650A-023 Side Panel, Left
24 650A-024 Sw ivel Caster w ith Brake
25 650A-025 Door Hinge
26 650A-026 Door Clapboard
27 650A-027 Draw er Slide Bracket, Left
28 650A-028 Draw er Slide
29 650A-029 Draw er, Door Handle Seat
30 650A-030 Draw er, Door Handel Tube
31 650A-031 Draw er
32 650A-032 Door Magnet
33 650A-033 Cart Frame
34 650A-034 Door hinge bracket, Left
35 650A-035 Door hinge bracket, Right
36 650A-036 Left Door, Front
37 650A-037 Left Door, Right
38 650A-038 Lighting Rod
39 650A-039 Tow el Rack
40 650A-040 Tow el Rack Bracket
41 650A-041 Tank Tray Lock Slip
42 650A-042 Tank Tray Slide Bracket, Left
43 650A-043 Tank TraySlide Bracket, Right
44 650A-044 Tank Tray Slide
45 650A-045 Tank Bolt
46 650A-046 Tank Tray
47 650A-047 Sw ivel Caster
48 650A-048 Bottom Panel
49 650A-049 Cart Clapboard
For assembly questions, call:
1-800-913-8999
For parts ordering, please call:
1-800-4-MY-HOME
®
To make sure you obtain the correct replacement
parts for your Kenmore gas grill, please refer to
the part numbers on this page.
Model122.16648900 Parts List
DESCRIPTION QUANTITY KEY#
1
2
1
1
2
2
1
1
1
2
1
1
1
1
5
1
1
1
1
1
6
1
1
1
1
1
1
2
6
3
1
2
1
1
1
1
1
1
1
2
1
1
1
2
1
2
1
1
1
PARTS DESCRIPTION
50 650A-050 Caster
51 650A-051 Side Panel, Right
52 650A-052 Back Panel
53 650A-053 Rubber Grommet
54 650A-054 Pow er cord fix bracket
55 650A-055 Transformer
56 650A-056 Assembled Pow er Cord
57 650A-057 Cable Strainer
58 650A-058 Pow er Cord Fix Bracket
59 650A-059 Transformer Supporting Box
60 650A-060 Electronic Igniter Module
61 650A-061 Sear Gas Valve
62 650A-062 Side Manifold
63 650A-063 Sear Burner Igniter Wire
64 650A-064 Sear Burner
65 650A-065 Side Burner Control Panel
66 650A-066 Sear Burner Bow l Assembly Frame
67 650A-067 Side Burne Grease Tray
68 650A-068 Side Burner Cooking Grid
69 650A-069 Side Burner Lid
70 650A-070 Grease Slide Panel, Bottom
71 650A-071 Grease Tray
72 650A-072 Firebox Heat Shield
73 650A-073 Lamp Fix Cover, Right
74 650A-074 Lamp Fix Cover, Left
75 650A-075 Lamp
76 650A-076 Back Panel, Top
77 650A-077 Rotisserie Burner Flex Gas Line
78 650A-078 Rotisserie Orifice w / brass elbow
79 650A-079 Rotisserie Burner Igniter Wire
80 650A-080 Rotisserie Burner Gas Collector
81 650A-081 Rotisserie Burner
82 650A-082 Rotisserie Heat Shield
83 650A-083 Rear baffle
84 650A-084 Main Buner Igniter Wire A
85 650A-085 Main Buner Igniter Wire B
86 650A-086 Main Buner Igniter Wire C
87 650A-087 Main Buner Igniter Wire D
88 650A-088 Main Buner Igniter Wire E
89 650A-089 Main Burner
90 650A-090 Heat Diffuser
91 650A-091 Cooking Grid With Hole
92 650A-092 Warming Rack
93 650A-093 Igniter Junction Wire
94 650A-094 Side Shelf, Side burner back bracket
95 650A-095 Side shelf handle bezel
96 650A-096 Rotisserie Control Knob
Important: Use only parts listed above. When ordering
parts, providing the following information:
1. Model #
2. Part Number (see PART# in chart)
3. Part Description
4. Quantity of parts needed
You can purchase the Kenmore rotisserie kit, item #
15803 or NG conversion kit, item #710-0650 at your
local Sear's store.
Important: Keep this Owner's Manual for convenient
reference and for part replacement.
