AgfaPhoto DV-5580Z Rear View Zoom (wide-angle) 1. Microphone button / Thumbnail button 2. Status LED Left button Play button Assist light button Up button Power button MODE Mode button 12. USB or AV OUT terminal Right button 13. HDTV terminal...
AgfaPhoto DV-5580Z GETTING STARTED Preparation 1. Attach the camera strap. 2. Open the battery cover. 3. Insert the supplied battery with correct orientation as shown. (Label side to the back) Close the battery cover and make sure it is locked securely.
AgfaPhoto DV-5580Z CAPTURE MODE Your digital video camera is equipped with a 2.5" full color LTPS LCD monitor to help you capture/playback images and video clips or adjust menu settings. Recording Video Clips 1. Press the button until the digital video camera turns on.
AgfaPhoto DV-5580Z PLAYBACK MODE You can play back all the recorded files on the LCD monitor. Playing Back Video Clips 1. Press the button. The last recorded file appears on the LCD monitor. 2. Select the desired video clip with the (O) buttons.
Page 7
AgfaPhoto DV-5580Z Deleting Images/Video Clips 1. Press the button. Play 2. Select the file you wish to delete with the (O) buttons. Delete File 3. Press the MENU button. Delete All 4. Select [Delete File] or [Delete All] with the Slide Show 5 Sec.
AgfaPhoto DV-5580Z AUDIO MODE Recording Audio Files The digital video camera enables you to record and playback audio files anytime and anywhere. 1. Press the MODE button to switch to audio mode. 2. Press the button to start audio recording.
AgfaPhoto DV-5580Z INSTALLING THE SOFTWARE 1. Make sure you have Windows Media Player 9 or QuickTime 7.0 installed on your computer first. 2. Install the decoder program (available in the CD). H.264 files can be played back with Windows Media Player 9. (Decoder is designed for H.264 decode)
73066 Uhingen Germany AgfaPhoto is used under license of Agfa-Gevaert NV & Co. KG. Agfa-Gevaert NV & Co. KG. does not manufacture this product or provide any product warranty or sup- port. For service, support and warranty information, contact the distributor or manufac- turer.
AgfaPhoto DV-5580Z Disposal of Waste Equipment by Users in Private Households in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dis- pose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
