Summary of Contents for Whirlpool MWL1003X
- Page 1 Instructions for use MWL1003X...
-
Page 2: Microwave Oven
Microwave Oven INSTRUCTION MANUAL Model:MWL1003X Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service. SAVE THESE INSTRUCTIONS CAREFULLY... -
Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. Specifications Model: MWL1003X Rated Voltage: 220-230V~ 50Hz Rated Input Power(Microwave): 1450W... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock, injury to persons WARNING or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: ovens since they may explode, even 1. Warning: Liquids and other foods must after microwave heating has ended. -
Page 5: To Reduce The Risk Of Injury To Persons Grounding Installation
26.The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet 27.The appliances are not intended to be operated by means of an external timer or separate remote-control system. 28.The door or the outer surface may get hot when the appliance is operating. To Reduce the Risk of Injury to Persons Grounding Installation DANGER... -
Page 6: Materials You Can Use In Microwave Oven
UTENSILS See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not CAUTION safe to use for microwaving. If in doubt, you can test the Personal Injury Hazard utensil in question following the procedure below. -
Page 7: Materials To Be Avoided In Microwave Oven
Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing. -
Page 8: Turntable Installation
Turntable Installation a. Never place the glass tray upside down. The glass Hub (underside) tray should never be restricted. b. Both glass tray and turntable ring assembly must always be used during cooking. Glass tray c. All food and containers of food are always placed on the glass tray for cooking. -
Page 9: Operation
OPERATION Control Panel and Features cook time time defrost weight defrost 烹调时间 按时解冻 按重解冻 microwave clock timer 微波 时钟 时计 popcorn potato pizza 爆谷 薯仔 薄饼 reheat frozen vegetable beverage 冷冻蔬菜 饮品 按重翻热 (11) (10) STOP MEMORY START 停止 记忆 开始... - Page 10 OPERATION 1. Power Level 11 power levels are available. Level Power 100% Display PL10 2. Clock Setting (1) Press " CLOCK ", "00:00" will display. (2) Press the number keys and enter the current time. For example, time is 12:10 now, please press "1,2,1,0" in turn. (3) Press "...
- Page 11 Example: to cook the food with 50% microwave power for 15 minutes. a. Press " COOK TIME" once."00:00" displays. b.Press "1","5","0","0" in order. c.Press "MICROWAVE"once,then press "5" to select 50% microwave power. d.Press "START" to start cooking. Note:1) In the process of setting, if the " STOP " button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically.
- Page 12 POPCORN a)Press " POPCORN " repeatedly until the number you wish appears in the display, "50","100"g will display in order. For example, press "POPCORN" once , "50" appears. b) Press " START " to cook, buzzer will sound five times and then turn back to waiting state. Important Information About Microwave Popcorn Feature 1.
- Page 13 BEVERAGE a) Press " BEVERAGE " repeatedly until the number you wish appears in the display, "1","2","3" cup will display in order. One cup is about 120ml. For example, press "BEVERAGE" once , "1" appears. b) Press " START " to cook, buzzer sounds once.When cooking finish,buzzer sounds five times and then turn back to waiting state.
- Page 14 15. Multi-stage cooking At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall be placed at the first stage automatically. Note: Auto cooking cannot work in the multi-stage cooking. Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes.
-
Page 15: Troubleshooting
Trouble shooting It is forbidden to run the unit without any food inside. It is very dangerous. According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste.
