- Page 1 Series Scanners User’s Guide A-61514 Part No. 9E3718 CAT No. 126 4951 KODAK iNnovation Series Scanners...
-
Page 2: Table Of Contents
Installing the IEEE-1394 (FireWire) card in the host computer ..12 Installing the Kodak Driver Software ......12 Installing the IEEE-1394 (FireWire) cable . - Page 3 Transporting the scanner ........
-
Page 4: Introduction
Introduction Scanner features A-61514 September 2004 Before you install and operate your Kodak i100 Series Scanner, take a few minutes to read through this guide. It contains important information about installing, using, and maintaining your scanner. • Kodak i150 Scanner is a desktop simplex color scanner with an automatic document feeder. -
Page 5: Paper Transport Features
• Automatic document feeder (ADF) with operator-assisted “infinite” and single-sheet feeding The following speeds in pages per minute (ppm) are for color, grayscale, and bi-tonal output. Landscape (A4) Resolution i150 Scanner i160 Scanner i150 Scanner i160 Scanner 150 dpi 53 ppm 200 dpi 40 ppm 300 dpi 27 ppm •... -
Page 6: Preparing Documents For Scanning
• When scanning documents in a clear protective sleeve, the input tray guides must be adjusted to accommodate the width of the sleeve. NOTE: Kodak scanners have been tested with a range of documents that represent the broad spectrum of document types found in the most common business applications. -
Page 7: Safety Information
CAUTION: The scanner and power supply must only be used indoors in a dry location. • Material Safety Data Sheets (MSDS) for information about chemicals used in Kodak products are available on the Kodak web site at www.kodak.com/go/MSDS. Refer to Appendix B, “Supplies and Accessories,” for catalog number information. -
Page 8: Safety And Regulatory Agency Approvals
CNS 13438 Class B CFR 47 Part 15 Subpart B FCC Class B • The Kodak i100 Series Scanners are designed to meet worldwide environmental requirements. • The i100 Series Scanners’ power supply cord jacket and the solder on the circuit boards contain lead. -
Page 9: Emc Statements
EMC statements United States Japan KODAK i150 / i160 Scanner This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 10: Installing The Scanner
• IBM PC (or compatible) with a Pentium III 1 GHz processor - i160 Scanner: for scanning at 300 dpi with deskew, you will need at least a 1.8 GHz processor for bi-tonal scanning or a 2.5 GHz processor for color scanning. -
Page 11: Unpacking The Scanner
• IEEE FireWire Kit NOTE: Save all packing materials for possible future use. It is very important that you register your scanner so Kodak can provide you with the best possible service and support. Registering your scanner will help us provide you with firmware and hardware updates as they become available. -
Page 12: Removing The Foam Sheet
The scanner is packed with a foam sheet inside to protect the rollers during shipping. This foam sheet must be removed before you can begin scanning. 1. Lift the scanner out of the box and place it on a stable, level work surface that is capable of supporting it. -
Page 13: Rear
3 IEEE-1394 (FireWire) port 4 Power input 5 Input tray 6 Input tray extender 7 Service LEDs 8 Upper imaging guide access door (i160 Scanner only) Side 1 Red indicator 2 Green indicator See the section entitled, “Indicator lights” in the... -
Page 14: Internal
Internal 1 Separator module 2 Normal force rollers 3 Rear drive roller cover 4 Front drive roller cover 5 Feed module A-61514 September 2004... -
Page 15: Making Connections
(FireWire) cable Follow the instructions for installing the IEEE-1394 (FireWire) card and the Kodak Driver Software before you plug the scanner into the host computer. IMPORTANT: You must install the software on the host computer before you install the scanner. -
Page 16: Power Setup
Power setup A-61514 September 2004 One or more power cords may be supplied with the scanner. Use only the cord required for your power type. Dispose of any unneeded power cords properly. Use only the power supply that was provided with the scanner. - Page 17 If you are installing the scanner on a computer that is running Windows 2000, the following screen may appear. • Select Yes. Kodak has successfully tested the i100 Series Scanners with Windows 2000. Your scanner is now installed. If you are installing the scanner on a computer that is running Windows XP, the following screen may appear.
- Page 18 1. Select Next. The following screen appears. 2. Select Continue Anyway. Kodak has successfully tested the i100 Series Scanners with Windows XP. The following screen appears. 3. Select Finish. Your scanner is now installed. A-61514 September 2004...
-
Page 19: Input And Output Trays
2. Align the input tray pins with the slots. 3. Press the input tray until it snaps into place. NOTE: Opening the scanner door may make it easier to see the slots and align and install the tray. 1. Locate the output tray slots on the scanner. -
Page 20: Adjusting The Output Tray
1. Grasp the tray on each side. 2. Lift up the tray and move it up or down to the desired position. You can move the scanner trays out of the way when the scanner is not in use. 1. Grasp the input tray. -
Page 21: Using The Scanner
(ADF) in landscape orientation (longer side as the leading edge). IMPORTANT: Staples and paper clips in documents may damage the scanner. Remove all staples and paper clips before scanning. 1. Align the leading edges of the stacked documents. -
Page 22: Continuous Feeding
Continuous feeding Manual feeding A-61514 September 2004 Continuous feeding allows you to place additional batches of documents in the feeder for “infinite” feeding (with operator assistance). • When only a few documents from one batch remain in the feeder, place the next batch face down on top of those documents. -
Page 23: Damaged Documents
Damaged documents You can scan torn or fragile documents through the automatic document feeder if they are placed in a protective plastic sleeve. 1. Place the damaged document into a protective sleeve. 2. Position the sleeve face down, folded edge first, and centered in the ADF. 3. -
Page 24: Maintenance
Wash your hands with soap and water after performing maintenance procedures. Refer to the Material Data Safety Sheet (MSDS) for more information. The MSDS is available on the Kodak web site at www.kodak.com/go/MSDS. The roller cleaning pad contains sodium lauryl ether sulfate and sodium silicate which can cause eye irritation. -
Page 25: Cleaning The Separator Module
1. Power down the scanner. 2. Remove any documents from the feeder area. 3. Lift up the scanner door release to unlatch the scanner door. 4. Pull up to open the scanner door. 5. Remove the separator module by pulling it down and lifting it off. -
Page 26: Cleaning The Feed Module
Cleaning the feed module A-61514 September 2004 7. Inspect the rollers. If the separator roller tires show signs of wear or damage, replace the tires or the separator module. 8. Insert the separator module and align the shaft ends. 9. Press until the separator module clicks into place. 10. -
Page 27: Cleaning The Drive Rollers And Transport Area
Cleaning the drive rollers and transport area 3. Manually rotate and wipe the feed module rollers with a roller cleaning pad. 4. Inspect the feed module. If the feed module tires show signs of wear or damage, replace the tires or the feed module. -
Page 28: Cleaning The Imaging Guides
If you need to remove the imaging guides, follow the instructions for “Installing the Kodak Imaging Guide Set for i100 Series Scanners”. -
Page 29: Cleaning The Paper Path
Kodak Extra-Large Feeder Consumables Kit for i100 Series Scanners (5 complete feed modules, 5 complete separator modules, 10 pre-separation pads, 120 roller tires) Kodak Imaging Guide Set (1 upper guide, 1 lower guide) Calibration Target (12” x 12”) Kodak White Background Accessory Use only these replacement parts in your scanner. -
Page 30: Calibrating The Scanner
Frequent calibration is not needed or recommended. Calibration instructions can be found in the Image Processing Guide for Kodak i100 Series Scanners. A copy of this guide (PDF file) can be found on the installation CD. -
Page 31: Troubleshooting
Troubleshooting Indicator lights Service indicator lights There are two indicator lights — one red, one green — on the scanner that provides information about what the scanner is doing. Green on — scanner is ready to scan Green flashing — scanner is busy Red on —... -
Page 32: Lamps
A-61514 September 2004 The scanner has a lamp saver feature to prolong lamp life. The lamps shut off after five minutes of scanner idle time. 1. Remove any documents from the feeder area. 2. Lift up the scanner door release to unlatch the scanner door. -
Page 33: System Is Not Responding
However, the host computer may require several seconds to detect the scanner. 6. Wait until the scanner light is green and no longer in the power-up mode. 7. Attach the IEEE-1394 (FireWire) cable to the IEEE-1394 port on the back of the scanner. -
Page 34: Problem Solving
• for thicker documents, you lift the gap release button during feeding. • you check the feed module and separator module for signs of wear, and You can also power the scanner down and power up again or follow the instructions in “System Is Not Responding” in this section. - Page 35 The lamps in the i100 Series Scanners will turn off after 5 minutes of no scanner activity. If the lamps are off, but the scanner has not yet gone into the Energy Star mode (default 15 minutes), there will be a delay of about 5 seconds for the lamps to warm up again.
-
Page 36: Transporting The Scanner
A-61514 September 2004 If it becomes necessary to transport the scanner after installation, you must repack the scanner using the original packaging materials. If you do not have the original packaging materials, contact your supplier. 1. Power down the computer. -
Page 37: Appendix A Specifications
Appendix A Specifications Scanner Type i150 Scanner: simplex color scanner with automatic document feeder i160 Scanner: duplex color scanner with automatic document feeder Image Capture Resolution 75 dpi to 300 dpi color and bi-tonal ADF Scanning Speed i150 Scanner/i160 Scanner:... - Page 38 Heat Load 600 BTU Altitude Up to 2440 m (8000 ft) Acoustic Noise Data was measured in accordance with DIN 45 635, ANSI S12.10-1985, and ISO 7779 in a semi-anechoic chamber. • Operating: < 60 dB • Standby: < 40 dB A-61514 September 2004...
-
Page 39: Appendix B Supplies And Accessories
