Kodak i6000 Series Quick Tips

REPLACING THE INK CARTRIDGE
If you are using the Inkjet Printer, periodically you will need
to change the ink cartridge.
1. Turn off the scanner.
2. Remove the scanner top cover.
3. Lift up the tab at the rear of the ink cartridge and pull it
out of the ink cartridge holder.
4. Dispose of the empty ink cartridge in accordance with
all federal, state and local laws.
5. Take the new cartridge out of its packaging and remove
the protective tape from the cartridge.
IMPORTANT:Do not touch the exposed metal chip or the
cartridge could be damaged.
6. Insert the ink cartridge into the ink cartridge holder and
push the ink cartridge down until it snaps into place.
7. Reinstall the scanner top cover and turn on the scanner.
TROUBLESHOOTING
For a list of error codes and possible solutions, see the
User's Guide, Chapter 5, Troubleshooting.
Periodic and scheduled cleanings should be performed
before determining if any further problem resolution is
needed.
Helpful Hints
Always jog the documents to align the leading and
bottom edges. Visually check the leading edges for
bent or curled corners and straighten them as needed.
Place the stack of documents halfway into the input
tray, then slide the stack forward until the left indicator
comes on.
Be sure the exit wire stop is extended enough to allow
approximately 1/2-inch or more than the longest
document.
If you are experiencing image quality problems,
thoroughly clean your scanner.
SUPPLIES*
CAT No. Description
802 7393 Cleaning Kit / Kodak i6000 Series Check
Scanners (includes cleaning cards and
swabs)
830 1087 Inkjet Cartridge hp 6602a
* Items are subject to change.
EASTMAN KODAK COMPANY
Document Imaging
Rochester, New York 14650
Kodak is a trademark of Eastman Kodak Company.
© Eastman Kodak Company, 2006
A-61547 6/06
CAT No. 123 5779
Part No. 9E4522
Kodak i6000 Series Check
Scanners
Quick Tips
www.kodak.com
Kodak Service
1-800-822-1414
Kodak Parts Services
1-800-471-0803
1-585-724-6042
Kodak Professional Services
1-800-525-6325
