Summary of Contents for Sangean DPR-26BT

  • Page 1 DPR-26BT 中文 Version 1...
  • Page 2 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SANGEAN ELECTRONICS INC. is under license.

  • Page 3: Table Of Contents

    Contents Controls................3-5 Display backlight ............... 29 Battery operation using alkaline batteries ......6 A few words about batteries ..........30 Battery operation using rechargeable batteries ....7 Rechargeable batteries ..........30-31 Using the AC adaptor ............8 Specifications ..............32 Operation modes ..............

  • Page 4: Controls

    Controls(Front) . Power On/Off 6. LCD display . Charge/Low battery indicator 7. Tuning Control/Select knob . Band button 8. Volume Control 4. Auto Tune button/Bluetooth pair button 9. Station presets 5. Advanced information button (Preset 5: Fast- forward button) (Preset 4: Play/Pause button) (Preset : Rewind button)
  • Page 5 Controls(Back) 0. Battery compartment 4. Line Out socket . Telescopic aerial 5. Headphone socket . Music/News tone control 6. DC input socket . Aux In socket...

  • Page 6: Controls

    Controls(Back) 7. Rechargeable/Alkaline battery switch 8. Handle 9. USB socket for software upgrade...

  • Page 7: Battery Operation Using Alkaline Batteries

    Battery operation using alkaline batteries . Remove the battery cover on the rear of the unit by sliding the catch. . Insert six C size (UM, LR 4) alkaline batteries into the spaces in the compartment. Ensure all batteries are inserted with the correct polarity as shown inside the battery compartment. .

  • Page 8: Battery Operation Using Rechargeable Batteries

    Battery operation using rechargeable batteries . Remove the battery cover on the rear of the unit by pushing the catch. . Insert six Rechargeable LR 4 (C size, UM ) batteries into the spaces in the compartment. Take care to ensure all batteries are inserted with the correct polarity as shown inside the battery compartment.

  • Page 9: Using The Ac Adaptor

    Using the AC adaptor Your radio is supplied with a Mains adaptor. 1. Place your radio on a flat surface. . Insert the adaptor plug into the DC socket located on the left hand end of your radio. . Plug the adaptor into the mains socket outlet. Whenever the adaptor is used, the batteries are automatically disconnected.

  • Page 10: Operation Modes

    4. Bluetooth mode is used for listening to music streamed from your Bluetooth device. 5. The DPR-26BT has a Auxiliary input socket which can be used an amplifier and loudspeaker system for external MP players, mini disc players and similar devices.

  • Page 11: Operating Your Radio - Dab

    Operating your radio – DAB . Carefully extend the telescopic aerial. 2. Press the On/Off button to switch on your radio. The display will show “Welcome to Digital radio“. Welcome to Digital Radio 3. If this is the first time the radio is used, a quick scan of Band III DAB channels will be carried Scanning...

  • Page 12: Selecting A Station - Dab

    Selecting a station – DAB . The top line of the display shows the name of the station currently selected. BBC Radio 5 . Rotate the Tuning control to scroll through the list of available stations. Stop rotating the tuning control when you find the station you wish to hear.

  • Page 13: Display Modes- Dab

    Display modes – DAB Your radio has seven display modes: . Press the Advanced info button to cycle through the various modes BBC 7 a. Scrolling text Displays scrolling text messages such as artist/track name, phone in number etc. BBC 7 Culture b.

  • Page 14: Finding New Stations - Dab

    Finding new stations – DAB As time passes, new station may become available. To find new stations proceed as follows: 1. Press and release the Auto Tune button, the display will show “Scanning“. Your radio will perform Scanning... a scan of the DAB frequencies. As new stations are found, the station counter on the right-hand side of the display will increase and stations will be added to the list.

  • Page 15: Dynamic Range Control (Drc) Settings- Dab

    Dynamic Range Control (DRC) settings – DAB DRC can make quieter sounds easier to hear when your radio is used in a noisy environment. . Press the On/Off button to switch on your radio. 2. Press and hold in the Advanced in button until display shows “Manual tune“. <Manual tune >...

  • Page 16: Prune Stations

    Prune stations If you move to a different part of the country, some of the stations which were listed may no longer be available. Also, from time to time, some DAB services may stop broadcasting, or may change location or frequency. Stations which cannot be found, or which have not been received for a very long time are shown in the station list with a question mark.

  • Page 17: Software Version

    Software version- DAB only The software version display cannot be altered and is provided for reference only. . To view the DAB software version installed in your radio, press the Band button to select DAB band. <SW version > SW version .

  • Page 18: Operating Your Radio - Search Tuning Fm

    Operating your radio – Search tuning FM Fully extend the telescopic aerial for FM reception. Press and On/Off button to switch on your radio. The display will show “Welcome to Digital Radio“. Welcome to Digital Radio Press the Band button to select the FM band. 89.30MHz Press and immediately release the Auto tune button, your radio will scan in an upwards direc- tion (low frequency to high frequency) and stop automatically when it finds a station of suf-...

  • Page 19: Manual Tuning - Fm

    Manual tuning – FM . Press the On/Off button to switch on your radio. 89.30MHz . Press the Band button to select the FM band. 3. Rotate the Tuning control to tune to a station. The frequency will change in steps of 50 kHz on FM. 4.

  • Page 20: Display Modes - Fm

    Display modes – FM In FM mode the bottom line of the display can be set to any of the following modes: . Press the Advanced info button to cycle through the various modes. 99.70 MHz The best variety of a.

  • Page 21: Stereo/Mono Setting - Fm

    Stereo/Mono setting – FM Your radio will play stereo broadcasts in stereo so long as the received signal is of adequate strength. However, as a stereo signal becomes weaker, the audio signal will become poorer. It may be preferable to force the radio to play the station in mono in order to reduce the level of au- dio noise.

  • Page 22: Scan Sensitivity Setting - Fm

    Scan sensitivity setting – FM Your radio will normally scan for FM broadcasts which are strong enough to give good reception. However, you may wish the Auto-scan function to be able to find weaker signals, possibly from more distant radio transmitters. Your radio includes a local/distant option for the Auto-scan function. .

  • Page 23: Presetting Stations/Recalling A Preset Station- Dab/Fm

    Presetting stations There are 5 memory presets on each radio band DAB and FM. . Press the On/Off button to switch on the radio. 2. Tune to the required station as previously described. 3. Press and hold down the required Preset button until the display show e.g. “Preset 1 stored“. BBC R2 The station will be saved under the chosen preset button.

  • Page 24: Listening To Bluetooth Music

    ) If ‘DPR-6BT’ shows on your Bluetooth device list but your device cannot connect with it, please delete the Sangean DPR-6BT item from your list and pair the device with DPR-6BT again following the steps described previously.
  • Page 25 Playing Bluetooth music . Once your Bluetooth device and the DPR-6BT are linked you can start to play Bluetooth music via your radio. . Press the Play/Pause button on the panel or the native controls on your Bluetooth-enabled device to start playing the Bluetooth music. .
  • Page 26 Pairing additional devices Before pairing another device to the radio, you need to make the radio discoverable. . Press and hold the Bluetooth pairing /Auto tune button to allow DPR-6BT discoverable for Bluetooth pairing with other Bluetooth device. The display will now show ‘Bluetooth discoverable’ for a Pairing...

  • Page 27: System Reset

    System reset If your radio fails to operate correctly, or some digits on the display are missing or incomplete, carry out the following procedures. <Manual tune > . Switch on your radio. <Factory reset > 2. Press and hold in the Advanced info button until “Manual tune“ appears on the display. Press SELECT to 3.

  • Page 28: Software Upgrade

    USB upgrade port. You should not attempt to update your radio unless it is recommended to you by Sangean Customer Services. Updating the software may remove all network settings, radio station presets and alarm settings from your radio.

  • Page 29: Auxiliary In Socket

    Auxiliary in socket . Connect stereo or mono audio source (i.e. CD Walkman, iPod, MP players) to the Auxiliary in AUX IN socket. 2. “Aux In“ will show on the display. . Adjust the Volume control for comfortable listening. Line out socket A .5 mm Line out socket located on the left hand end of your radio is provided for connecting the audio signal to an external amplifier.

  • Page 30: News/Music Sound Switch

    News/Music sound switch For all normal listening, it is recommended to use the sound/music switch in the music position. The alternative news position is intended to make speech clearer when there is significant back- ground noise or music in the program content. Display backlight .

  • Page 31: A Few Words About Batteries

    A few words about batteries Rechargeable batteries Your radio has been designed to use a choice of power sources. You Your radio use a range of methods to ensure correct and safe charging may plug it into the mains using the supplied adaptor. or for listening of Rechargeable Nickel-Metal-Hydride batteries.
  • Page 32 If you use the radio powered from batteries, the battery light will be off To avoid danger and risk of injury, please follow these guide lines until the batteries are exhausted. The battery light will then show red for Improper use of batteries may result in leakage of fluid, overheating a while before the radio switches itself off.

  • Page 33: Specifications

    Specifications Circuit features Power Requirements Loudspeaker  x 89 mm 8 ohms Mains AC 00-40 Volts, 50-60 Hz ~ only (adaptor) Batteries 6 x LR4 (C size, UM) Output Power  x  Watt Battery life Headphone socket .5 mm dia Approx.
