- Page 1 BPT6021BT Instruction Manual Enjoy it. 2.1CH Sound Tower with Bluetooth...
-
Page 2: Table Of Contents
Content SPECIFICATION...............................1 ACCESSORIES..............................1 WARNING.................................2 INSTALLATION..............................4 PANELS................................5 REMOTE CONTROL............................6 BASIC OPERATION............................7 FM OPERATION..............................8 BLUETOOTH OPERATION...........................9 AUDIO OPERATION............................10 USB OPERATION............................11 TROUBLE SHOOTING..........................12 IMPORTANT INFORMATION........................13... -
Page 3: Specification
Specification Power supply AC 220V-240V~50Hz Max. power consumption Input joint Audio in, USB Frequency 87.5MHz-108.0MHz Operating conditions Temperature : 5 C~35 C Installation : on a flat horizontal surface Accessories DISPLAY USER MANUAL 1* Remote Control 1* Audio cable 1* User Manual 1* Power Cable... -
Page 4: Warning
Warning 1. Read these Instructions - All the safety and operating instructions should be read before this product is operated. 2. Keep these Instructions - The safety and operating instructions should be retained for future reference. 3. Heed all Warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4. - Page 5 Safety Instructions Please read and understand all the warnings provided below, as well as and those marked on the unit. This unit has been designed and manufactured to assure personal safety. Only use power source that is specified Keep the unit and power plug in the User Manual or on the system.
-
Page 6: Installation
Installation diagram Please install the machine as below (do not connect to power): Please remove the protective film before use. The tower Base plate Screw washers Fix the Screws... -
Page 7: Panels
Panel Controls PANELS USB PORT NFC SENSOR PREVIOUS STANDBY FAST FORWARD FAST REWIND NEXT STOP VOLUME -/+ PLAY/PAUSE SOURCE AUDIO INPUT L/R AUDIO IN SOCKET FM ANTENNA AUDIO IN AUDIO IN POWER SWITCH POWER INPUT... -
Page 8: Remote Control
Remote control 1. Align the remote control directly at the remote control sensor of the device (beside display screen). 2. The range of the remote control is 7 meters. 3. Bright light (sun or artificial light) should not fall directly at the remote control sensor. -
Page 9: Basic Operation
Basic Operation PREPARATION 1) Before the unit is turned on, please check if all the connections are right and safe. Then connect the main power. 2) Press the POWER ON/OFF button on the back panel to turn on the main power. 3) Press the STANDBY button to turn on the unit or to the standby mode. -
Page 10: Fm Operation
FM operation The range of FM frequency is from 87.50MHz to 108.00MHz. 2. Press SOURCE button or FM button to enter FM mode. 3. Extend the antenna as far as it can to get the best reception. 4. Press MO/ST button on remote control to turn on or off the stereo. If the reception is not good enough, it can turn on the stereo. -
Page 11: Bluetooth Operation
3. Enter the Bluetooth searching interface on the phone and start to search the devices. 4. Select the device name BPT6021BT from the search list. If they’re paired successfully, there comes a audible signal and the indicator lit steadily in blue. -
Page 12: Audio Operation
Audio operation Before connecting with the music devices, pay attention to the picture below. 1. Each connection must be safe and firm. Disconnect the power cable before you have finished all the connections. 2. The unit can connect with the Disc player/MP3 player/Smart phone/Computer or other music device via a audio cable. -
Page 13: Usb Operation
USB connection USB OPERATION 1. Insert USB stick to the USB port to connect with this unit. 2. Press SOURCE button or USB button to enter USB mode. 3. Once the unit detects the USB stick, it starts playing music automatically. 4. -
Page 14: Trouble Shooting
Trouble shooting For your convenience, we have listed some methods to solve common problems you may encounter when you use the system. If the problem occurs repeatedly, contact the nearest maintenance center. The product can not be turned on * Make sure you have turn ON the switch on the back of your product. * Try using a different power point. -
Page 15: Important Information
Important information Correct disposal of this product Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol reminds you of your obligation, that when you dispose of the appliance, it must be separately collected. - Page 16 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. SEP14 BPT6021BT...
