Your circular saw has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
7-1/4 in. LASER CIRCULAR SAW
DOUBLE INSULATED
CSB133L

Advertisement

Table of Contents
loading

Summary of Contents for Ryobi CSB133L

  • Page 1 7-1/4 in. LASER CIRCULAR SAW DOUBLE INSULATED CSB133L Your circular saw has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTy COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...
  • Page 3: General Safety Rules

    GENERAL SAFETy RULES  Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to WARNING! a rotating part of the power tool may result in personal Read all instructions. Failure to follow all instructions injury.
  • Page 4: Specific Safety Rules

    GENERAL SAFETy RULES SERVICE  When servicing a power tool, use only identical replacement parts. Follow instructions in the  Have your power tool serviced by a qualified repair Maintenance section of this manual. Use of unauthorized person using only identical replacement parts. This will parts or failure to follow Maintenance instructions may ensure that the safety of the power tool is maintained.
  • Page 5 SPECIFIC SAFETy RULES  Inspect tool cords periodically and, if damaged, have lower guard may be bent. Raise the lower guard with the repaired at your nearest authorized service center. retracting handle. Make sure it moves freely and does Constantly stay aware of cord location. Following this not touch the blade or any other part, in all angles and depths of cut.
  • Page 6: Symbols

    SyMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SyMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 7: Save These Instructions

    If you do not understand ing, use only identical replacement parts. the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.
  • Page 8: Electrical

    ELECTRICAL DOUBLE INSULATION EXTENSION CORDS Double insulation is a concept in safety in electric power When using a power tool at a considerable distance from tools, which eliminates the need for the usual three- a power source, be sure to use an extension cord that has wire grounded power cord.
  • Page 9: Features

    FEATURES PRODUCT SPECIFICATIONS  Blade Diameter ..........7-1/4 in.  Input ......10 V, AC Only, 60 Hz, 13 Amps  Blade Arbor ............5/8 in.  No Load Speed .........5,000 r/min. (RPM)  Cutting Depth at 0° ........... -3/8 in.  Net Weight ............
  • Page 10: Assembly

    FEATURES kNOW yOUR CIRCULAR SAW LASER GUIDE See Figure 1. The laser guide will generate a red laser beam on the work The safe use of this product requires an understanding of surface in front of and behind the saw when turned on. the information on the product and in this operator’s manual SPINDLE LOCk as well as a knowledge of the project you are attempting.
  • Page 11: Removing Blade

    ASSEMBLy ATTACHING BLADE SPINDLe See Figures 2 - 4. LOCK BUTTON arrOw ON  Unplug the saw. UPPer GUarD  Depress and hold spindle lock button.  Remove blade screw by turning it counterclockwise with LOOSeN BLaDe the blade wrench, while keeping the spindle lock button GUarD depressed.
  • Page 12: Operation

    OPERATION WARNING: Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating power tools. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury.
  • Page 13 OPERATION  Inspect the workpiece for knots or nails before cutting. Never saw into a knot or nail.  Make straight cuts. Always use a straight edge guide when rip cutting. This helps prevent twisting the blade.  Use clean, sharp, and properly set blades. Never make cuts with dull blades.
  • Page 14 OPERATION If at any time the lower blade guard does not snap closed, unplug the saw from the power supply. Exercise the lower SwITCH guard by moving it rapidly back and forth from the full open position to the closed position several times. Normally this will restore the guard to its normal operating condition.
  • Page 15 OPERATION USING THE LASER GUIDES PUSH IN See Figure 12. TUrN ON LaSer GUIDe BUTTON WARNING: Do not stare into the laser beams or turn the lasers on when the tool is not in use. Failure to heed this warning could result in possible serious personal injury.
  • Page 16 OPERATION OPERATING THE SAW See Figures 13 - 15. It is important to understand the correct method for operat- ing the saw. Refer to the figures in this section to learn the correct and incorrect ways for handling the saw. WARNING: To make sawing easier and safer, always maintain proper control of the saw.
  • Page 17 OPERATION LENGTH OF CUT SCALE See Figure 16. The saw is equipped with a length of cut scale on its base. It is parallel with the saw blade and can be used to measure the distance into the material the blade cuts. NOTE: Six inches is the maximum length of cut that you can measure.
  • Page 18 OPERATION WARNING: BeVeL aDJUSTMeNT BeVeL Attempting a bevel cut without having the bevel ad- KNOB SCaLe justment knob securely tightened can result in serious injury. TO BEVEL CUT See Figure 21.  Hold the saw firmly with both hands as shown.  Rest the front edge of the base on the workpiece.
  • Page 19: Pocket Cutting

    OPERATION POCkET CUTTING See Figure 22. WARNING: Always adjust bevel setting to zero before making a LOwer BLaDe pocket cut. Attempting a pocket cut at any other setting GUarD can result in loss of control of the saw possibly causing serious injury.
  • Page 20 OPERATION 0° BEVEL STOP aDJUSTING See Figure 23. SCrew The saw has a 0° bevel stop that has been factory adjusted to assure 0° angle of the saw blade when making 90° cuts. To check 0° bevel stop:  Unplug the saw.  Place the saw in an upside down position on a work- bench.
  • Page 21 OPERATION OPTIONAL EDGE GUIDE See Figure 24. Use the optional edge guide, part no. 96986009, when making long or wide rip cuts with the saw. eDGe GUIDe To assemble edge guide: KNOB  Unplug the saw.  Place edge guide through holes in base as shown in the figure.
  • Page 22: Adjustments

    ADJUSTMENTS aDJUSTING WARNING: SCrew Before performing any adjustment, make sure the product is unplugged from the power supply and the switch is in the OFF position. Failure to heed this warning could result LaSer BarreL in serious personal injury. WARNING: DO NOT point the laser at yourself or others.
  • Page 23: Accessories

    MAINTENANCE Electric tools used on fiberglass material, wallboard, spack- WARNING: ling compounds, or plaster are subject to accelerated wear and possible premature failure because the fiberglass chips When servicing, use only identical replacement parts. and grindings are highly abrasive to bearings, brushes, Use of any other parts may create a hazard or cause commutators, etc.
  • Page 24: Parts And Service

    HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-55-579. RYOBI is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 148 Pearman Dairy Road, Anderson, SC 965 Phone 1-800-55-579 www.ryobitools.com...
