Summary of Contents for Profoto Pro-B MainsDock
- Page 1 Pro-B MainsDock User´s Guide...
- Page 2 www.profoto.com...
- Page 3 Thank you for choosing Profoto Thanks for showing us your confidence by investing in a Pro-B MainsDock unit. For more than four decades we have sought the perfect light. What pushes us is our conviction that we can offer even yet better tools for the most demanding photographers.
-
Page 4: Safety Instructions
Equipment contains electrical and electronic components that are harmful to the environment. Equipment may be returned to Profoto distributors free of charge for recycling according to WEEE. Do not throw away the packaging material. Ask your local authority for the location of a recycling centre close to you.Follow... -
Page 5: Table Of Contents
Generator features ....................9 Battery Indicator ..................9 Recycling time .....................9 Modeling light ....................9 Charger .......................9 Operating instructions .....................10 Mount generator ..................10 Dismount generator ...................10 Trouble shooting .....................11 Technical data ......................12 Warranty .........................12 Regulatory information ...................13 EC Declaration of conformity ..............13 www.profoto.com... -
Page 6: System Description
– update to work properly with the Pro-B Mainsdock. Please get in contact with your local distributor or service station for further information. We do not recommend using the Pro-B Mainsdock with generators that are not updated because some components may overheat! Not applicable to Pro-7b EOP stands for “Extended Overheat Protection”. -
Page 7: Nomenclature
1. Locking Bracket 2. Power On Indicator 3. Over Temperature Indicator 4. Power supply (AC) Connector 5. Air Vent (not visible in figure) www.profoto.com... -
Page 8: Functionality
Power supply The Pro-B MainsDock unit can be connected to 90-130 VAC or 180-240 VAC, 50-60 Hz. The unit automatically senses and adapts to the voltage and frequency supplied. When the Pro-B MainsDock is connected to AC mains power, the Power On Indicator [2] has a steady green light. -
Page 9: Generator Features
Technical data. Modeling light When the generator is powered from the Pro-B MainsDock unit, the modeling light can be continuously on. (Not applicable to Pro-7b generators, which automatically turn off the modeling light after maximum 60 seconds.) -
Page 10: Operating Instructions
3. Ensure that the Locking Bracket [1] locks the generator in place. 4. Connect the power cable to the Pro-B MainsDock and to AC mains power. The Power On Indicator [2] will be green, indicating that mains power is connected. -
Page 11: Trouble Shooting
Bad cable connection. Check that the AC mains cable [2] is not illuminated. is correctly connected. The Over Temperature The Pro-B MainsDock has Wait until the temperature Indicator [3] has a red automatically turned off decreases. The Pro-B light and the generator... -
Page 12: Technical Data
4.9s (0,2fps) @ 1200Ws NORMAL 50ms (20fps) @ 9.4Ws FAST 66ms (15fps) @ 9.4Ws NORMAL All data are to be considered as nominal and Profoto reserves the right make changes without further notice. Warranty All Profoto products are individually tested before they leave the company and guaranteed for a period of two years with the exception of flash tubes, glass covers, modeling lamps, batteries and cables. -
Page 13: Regulatory Information
Pro-B2 and Pro-B3 Type: Profoto Pro-B MainsDock Profoto declared that the product complies with the essential requirements of Low Voltage Directive (LVD) 2006/95/EC and EMC Directive 2004/108/EC. For the evaluation of compliance, applicable parts of the following standards has been... - Page 14 www.profoto.com...
- Page 15 www.profoto.com...
- Page 16 Profoto AB SWEDEN Phone +46 8 447 53 00 info@profoto.com www.profoto.com...
