ViewSonic VA1930wm-1 Service Manual page 26

6.4 CN104 (Connect I/F BD to panel, FI-X30S-H or Equivalent)
Pin No.
*- RXO0-
2 RXO0+
3 RXO1-
4 RXO1+
5 RXO2-
6 RXO2+
7 GND
8 RXOC-
9 RXOC+
10 RXO3-
11 RXO3+
12 RXE0-
13 RXE0+
14 GND
15 RXE1-
16 RXE1+
17 GND
18 RXE2-
19 RXE2+
20 RXEC-
21 RXEC+
22 RXE3-
23 RXE3+
24 GND
25 GND
GND
26
27 GND
28 VCC
29 VCC
30 VCC
6.5 CN103 (D-SUB Connector)
Pin
1 Red video input
2 Green video input
3 Blue video input
4 GND
5 Cable Detect
ViewSonic Corporation
Symbol
minus signal of odd channel 0(LVDS)
plus signal of odd channel 0(LVDS)
minus signal of odd channel 1(LVDS)
plus signal of odd channel 1(LVDS)
minus signal of odd channel 2(LVDS)
plus signal of odd channel 2(LVDS)
Ground
minus signal of odd clock channel (LVDS)
plus signal of odd clock channel (LVDS)
minus signal of odd channel 3(LVDS)
plus signal of odd channel 3(LVDS)
minus signal of even channel 0(LVDS)
plus signal of even channel 0(LVDS)
Ground
minus signal of even channel 1(LVDS)
plus signal of even channel 1(LVDS)
Ground
minus signal of even channel 2(LVDS)
plus signal of even channel 2(LVDS)
minus signal of even clock channel (LVDS)
plus signal of even clock channel (LVDS)
minus signal of even channel 3(LVDS)
plus signal of even channel 3(LVDS)
Ground
Ground
Ground or Open
Ground
Power supply (5.0 V)
Power supply (5.0 V)
Power supply (5.0 V)
Symbol Pin
6
7
8
9
10
Function
Symbol
Red GND
Green GND
Blue GND
+5V(from PC)
GND
Confidential - Do Not Copy
23
Pin Symbol
11 GND
12 Serial data (SDA)
13 H / H+V SYNC
14 VSYNC
15 Data clock line (SCL)
VA1930wm-1
