Philips 190C1SB/00 Service Manual

22 inch tft wxga lcd colour monitor
Hide thumbs Also See for 190C1SB/00:
Table of Contents

Advertisement

Quick Links

See also: User Manual
22 inch TFT WXGA LCD Colour Monitor
Description
Important Safety Notice--------------------------------------2
Technical Data--------------------------------------------- 3~5
Installation-------------------------------------------------------6
Troubleshooting-----------------------------------------------7
On Screen Display-----------------------------------------8~9
Lock/unlock, Aging,Factory mode------------------------10
Mechanical Instructions ------------------------------12~15
Color adjustment --------------------------------------------16
Electrical instruction ----------------------------------19~20
Service Tool-----------------------------------------------21~22
DDC Instructions & Serial Number -----------------23~29
DDC DATA -----------------------------------------------30~31
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOL TAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
Published by Philips Consumer Lifestyle Copyright reserved Subject to modification
190C1SB/00
190C1SB/93

TABLE OF CONTENTS

Page
---------------------------------11
------------------------32~33
SAFETY
REFER TO BACK COVER FOR IMPOR T ANT SAFETY GUIDELINES
Chassis:
Description
-
-----------------------------------34
Wiring Diagram--------------------------------------------35
Block Diagram----------------------------------------------36
Scaler Diagram & C.B.A. ----------------------------37~43
Power Diagram & C.B.A. ---------------------------44~47
General product specification----------------------56~85
Exploded V iew ----------------------------------------------86
Spare/
Recommended P
PCBA photos--------------------------------------------------88
Repair tips-----------------------------------------------89~90
Repair Flow chart--------------------------------------91~93
Safety Test Requirments-----------------------------------94
NOTICE
JMay15 2009
MERIDIAN 1
Horizontal frequencies
30 - 8 3 kHz
Page
arts List-----------------------87
GB
312278518590
