No. Description
ATX 12V Power Connector (ATX12V1)
1
2
CPU Fan Connector (CPU_FAN1)
3
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4
2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
5
ATX Power Connector (ATXPWR1)
6
TPM Header (TPMS1)
7
Chassis Speaker Header (SPEAKER1)
8
Chassis Fan Connector (CHA_FAN1)
9
SATA3 Connector (SATA_6)
10 SATA3 Connector (SATA_5)
11
SATA3 Connector (SATA_4)
12
SATA3 Connector (SATA_3)
13
SATA3 Connector (SATA_2)
14
SATA3 Connector (SATA_1)
15
System Panel Header (PANEL1)
16 USB 2.0 Header (USB_6_7)
17
USB 2.0 Header (USB_8_9)
18
USB 3.0 Header (USB_10_11)
19
Front Panel Audio Header (HD_AUDIO1)
20 Clear CMOS Jumper (CLRCMOS1)
21 Chassis Intrusion Header (CI1)
7
