- Page 3 Cabinet (Not A Serviceable Part) 1112019 Leveler, Front (2) 1113249 Retainer (2) 1112023 Roller, Front & Rear (4) 1112695 Leveler, Adjustable (2) 2000670 Adjusting Rod (2) 1113250 Sleeve, Retainer (2) 1112937 Bushing, Rod (2) 489359 Screw 1112939 Hole Plug, Leveler 1112849 Cap, Grommet 1112970...
- Page 5 2000652 Breaker Trim & Retainer Assembly 1112682 Magnet, Side (4) 1112679 Magnet, Freezer (2) 1112681 Magnet, Refrigerator (2) 2000321 Cabinet, Trim R.S 2000322 Cabinet, Trim L.S 2001297 Screw 1112802 Cabinet, Trim (Bottom) 488649 Screw, 8-32 x 1/2 (8) 2000782 Cabinet, Trim Top...
- Page 7 LINER (Not A Serviceable Part) 1112591 Spacer, Control Panel (3) 843436 Grommet, Screw (3) 842339 Grommet 2001117 Ladder, Shelf (2) 520965 Screw Support, Ladder (8) 488357 Screw, 8 x 1-1/4 (8) 486194 Screw, 8 x 1/2 1112257 Hole Plug 2000740 Meat Pan, Air Duct Cover (Also Order 12) 2000337 Meat Pan, Air Duct...
- Page 9 Liner (Not A Serviceable Part) 538533 Support Clip, Icemaker (2) 2000193 Grommet, Screw (2) 488552 Screw, 10-12 x 3/8 (2) 992720 Stud, Support (4) 486194 Screw, 8 x 1/2 1112591 Spacer, Control Panel (3) 842534 Clip, Air Duct (4) 842339 Grommet (15) 1112260 Support, Evaporator...
- Page 11 Spacer, Track 1112282 Left Side 1112281 Right Side 1113870 Roller 1113871 Eyelet, Roller 1113169 Stop, Roller 488307 Washer 486194 Screw, 8 x 1/2 1113127 Bracket, Motor 1113960 Motor Assembly 488906 Screw, 8-32 x 5/16 983663 Coupling, Motor 1112613 Socket, Light 1113130 Cover, Motor 487294...
- Page 13 1112004 Frame, Shelf 1113956 Glass, Shelf 1112006 Reflector, Shelf 1113792 Gasket, Glass (2) 1125913 Rack, Wine 1112324 Retainer Glass 1112014 Frame Assembly 1112247 Cover, Crisper 1113238 Glass, Crisper 2000742 Meat, Pan Connector 2000554 Crisper Pan 1113870 Roller 1113871 Eyelet, Roller 489211 Screw, 10-16 x 3/4 488307...
- Page 15 1112367 Solid Shelf 2000529 Front, Ice Compartment 1112052 Shelf, Fixed (Large) 1113644 Trim, Basket 1113870 Roller 1113871 Eyelet, Roller 489211 Screw, 10-16 x 3/4 488307 Washer 1113641 Basket 2000061 Slide, Basket R.S. 2000062 Slide, Basket L.S. 1113169 Stop, Roller 486194 Screw, 8 x 1/2...
- Page 17 2000296 Door Panel, Refrigerator (Also Order Item 29) 939101 Screw Anchor (8) 2000696 Hinge Assembly, Top 2000303 Spacer 489282 Screw 2000698 Hinge Assembly, Bottom 1112533 Gasket Retainer, Side (2) 1112542 Gasket Retainer, Top & Bottom 2001049 Door Gasket, Magnetic 489101...
- Page 19 1112642 Control Panel 2000976 Inlay, Control Panel 2000789 Circuit Board 1116853 Control Knob 837444 Retainer, Knob 1108112 Switch, Rocker Arm 1113137 Seal, Control Panel 489260 Screw (3) 2000153 Hole Plug (3) 1113775 Shield, Control Panel 1112613 Socket, Light (2) 547225 Light Bulb (2) 486194 Screw, 8 x 1/2...
- Page 21 2001138 Exterior Door Panel, Freezer (Includes Insulation) 1112997 Tube, Wiring 1112928 Retainer, Tube 2000720 Hinge, Bottom 489282 Screw 2000721 Hinge, Top 2000303 Door Spacer 2001323 Wiring Harness, Freezer Door 1112533 Gasket Retainer, Side (2) 1112539 Gasket Retainer, Top & Bottom 2000878 Door Gasket, Magnetic 489101...
- Page 23 1112597 Control Panel 1113959 Inlay, Control Panel 1113466 Thermostat & Barrier Assembly 488974 Screw (2) 851387 Switch, Rocker Arm (Dispenser Motor) 1113136 Seal, Control Panel 489260 Screw (3) 1113769 Shield, Control Panel 1112613 Socket, Light 486194 Screw, 8 x 1/2 547225 Light Bulb 1112707...
- Page 25 1107943 Housing, Dispenser 987049 Bracket, Water Fitting 2155037 Water Fitting, Dispenser 487916 Screw, 8 x 3/8 987053 Water Tube 841707 Insert, Tube 488886 Screw, 8-18 x 1/2 488316 Screw, 8-18 x 3/4 987048 Grommet 2001334 Heater, Ice Dispenser 2147167 Ice Door Mechanism 2147168 Door, Ice 1129333...
- Page 27 2001123 Assembly, Unit Base 1113386 Assembly, Sound Barrier 4318071 Compressor (Includes Items 8, 9, 10, 11, 13) (Also Order 876765 Tube Kit) 1105220 Bracket, Mounting 1105219 Grommet, Bracket 1105200 Grommet, Mounting 489334 Screw 2154948 Overload 2154452 Terminal Cover 1105222 Strap, Cover 1118797 Relay 2149684...
- Page 29 2000528 Defrost Bi-Metal 1113043 Clamp, Bi-Metal 486194 Screw, 8 x 1/2 1113293 Tube, Connect (Suction) 1113209 Tube, Connect (Discharge) 1113296 Tube, Flow Divider (2) 1113292 Valve, Fluid Control 1113294 Tube, Connect (Drier) 2000756 Heater, Drain Pan 1113062 Hanger, Heater 1113105 Bracket, Heater 487534 Screw, 8 x 1...
- Page 31 2001086 Fan Motor 2154800 Fan Blade 548263 Bracket (Double) 938224 Bracket (Single) 548268 Grommet 486194 Screw, 8 x 1/2 2000618 Motor, Wiring 1129179 488366 Clamp, Tube 489348 Clamp, Nylon 2000113 Channel, Wiring 2150347 Union 2000783 Scroll, Fan 488772 Screw, 8 x 1/2 2000746 Assembly, Air Duct 2000048...
- Page 33 489084 Screw, 8 x 1/2 2000829 Fitting, Water Tube 2001087 Clamp, Tube 841707 Insert, Tube 628379 Clip, Fuse 2000392 Wire Clip 2001336 Tube, Water (To Ice Maker) 1106508 Seal Gasket 487627 Sleeve, Nut 2155062 Valve, Solenoid 627018 Nut, Compression 227991 Connector, Wire 2000836 Water Valve, Harness...
- Page 34 LIT2000850 Service & Wiring Sheet LIT628370 Modular Icemaker Service Sheet LIT2001094 Installation Instructions LIT4361435 Parts List...
- Page 36 2001055 Decorative Panel Assembly 1113356 Back Up Panel 2000846 Top Grille Assembly 2001088 Cover, Unit 486194 Screw, 8 x 1/2 1113300 Cover, Component Assembly...
