Freestanding Installation

• This appliance is designed to be built-in or freestanding.
• Locate the appliance away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption. Ambient temperature below 68
o o
90 F (32 C) will hinder the performance of this appliance. This unit is not designed
for use in a garage or any other outside installation.
• Avoid locating the appliance in moist areas.
• Plug the appliance into a dedicated, properly installed grounded wall outlet. This
appliance should be operated on a separate electrical circuit from other operating
appliances. Do not under any circumstances cut or remove the third (ground) prong
from the power cord. Any questions concerning power and/or grounding should be
directed toward a certified electrician or an authorized service center. This unit is not
designed to be installed in an RV or used with an inverter.
• After plugging the appliance into a wall outlet, allow the unit to cool down for
approximately 3-4 hours before placing wine bottles or beverage cans in the
appliance.

Built-In Installation

The cutout dimensions illustrated in
Figure A allows the door to swing open
and also allows access to the pull-out
shelves when installed as a built-in unit.
If you are installing the unit between
frameless cabinets, a ½" wide filler strip
or side panel may be needed on the hinge
side. The filler strip will act as a spacer
between the appliance case and the
adjacent cabinet door swing. The width of
the opening must include the filler panels.
Note: The door should protrude at least
1" beyond the surrounding cabinets.
Figure A – The cutout depth must be 24"
ENG - 6
6
o o
F (20 C) or above
