Page 1
A83400HLW0 EN CHEST FREEZER USER MANUAL FR CONGÉLATEUR COFFRE NOTICE D'UTILISATION DE GEFRIERTRUHE BENUTZERINFORMATION...
Page 2
Please spend a few minutes reading to get the very best from it. ACCESSORIES AND CONSUMABLES In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories...
Contents CONTENTS 4 Safety information 6 Control panel 10 First use 10 Daily use 12 Helpful hints and tips 12 Care and cleaning 14 What to do if… 16 Technical data 17 Installation 17 Noises 19 Environmental concerns The following symbols are used in this user manual: Important information concerning your personal safety and information on how to...
Safety information SAFETY INFORMATION In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the ap- pliance are thoroughly familiar with its operation and safety features.
Page 5
Safety information – thoroughly ventilate the room in which the appliance is situated • It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a short-circuit, fire and/or electric shock. WARNING! Any electrical component (power cord, plug, compressor) must be replaced by a certified service agent or qualified service personnel to avoid hazard.
Control panel Installation For electrical connection carefully follow the instructions given in specific paragraph. • Unpack the appliance and check if there are damages on it. Do not connect the appli- ance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing.
Control panel Display Excessive temperature alarm If on the function timer is on If on the appliance is on and if If on the Child Lock function is on flashes faster the Frostmatic func- tion is on Negative Temperature indicator If on the Frostmatic function is on Temperature indicator If on the Drinks Chill function is on...
Control panel By pressing the Temperature regulation button the current temperature setting flashes on the indicator and by pressing the button again it is possible to change it. You confirm the choice of the temperature by pressing the Confirmation button. The tem- perature indicator shows the set temperature.
Control panel Eco Mode Function The Eco Mode function is activated by pressing the Function button (several times if neces- sary) until the corresponding icon appears (or setting the temperature at -18°C). You must confirm the choice by pressing the Confirmation button within few seconds. You will hear the buzzer and the icon remains lighted.
First use FIRST USE Cleaning the interior Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand- new product, then dry thoroughly. Do not use detergents or abrasive powders, as these will damage the finish.
The appliance is equipped with Low frost System (you can see a valve inside the freezer in the backside) what reduces ice-build-up in the chest freezer by up to 80 percent. That means for you up to 5 years without defrosting.
Helpful hints and tips Plastic Low divider With the low divider you can have a better use of the space above the compressor. The space formed this way will allow you to store small food packs that can be found more easily.
Care and cleaning This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians. Periodic cleaning Switch off the appliance. Disconnect the mains plug from the mains socket. Regularly clean the appliance and the accessories with warm water and neutral soap. Clean the lid seal carefully.
What to do if… Switch off the appliance. Disconnect the mains plug from the mains socket. Remove all food. Defrost and clean the appliance and all accessories. Leave the lid open to prevent unpleasant smells. If the cabinet will be kept on, ask somebody to check it once in a while to prevent the food inside from spoiling in case of a power failure.
Page 15
What to do if… Problem Possible cause Solution The lid is not shut properly or do Check if the lid closes well and not close tightly. the gaskets are undamaged and clean. The temperature is not set cor- Set a warmer temperature. rectly.
Technical data Problem Possible cause Solution The appliance does not Plug is not connected to the Connect the mains plug properly. work at all. Neither cool- mains socket properly. ing nor lighting works. Power does not reach the appli- Try connecting another electrical ance.
Installation INSTALLATION Positioning WARNING! If you are discarding an old appliance that has a lock or catch on the lid, you must ensure that it is made unusable to prevent young children being trapped inside. The appliance shall have the plug accessible after installation. This appliance can be installed in a dry, well ventilated indoor (garage or cellar), but for op- timum performance install this appliance at a location where the ambient temperature cor- responds to the climate class indicated on the rating plate of the appliance:...
Environmental concerns HISSS! HISSS! SSSRRR! SSSRRR! CRACK! CRACK! ENVIRONMENTAL CONCERNS The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment.
Page 20
Veuillez prendre quelques instants pour lire cette notice afin d'utiliser au mieux votre appareil. ACCESSOIRES ET CONSOMMABLES Dans la boutique en ligne d'AEG, vous trouverez tout ce qu'il vous faut pour que vos appareils AEG fonctionnent parfaitement. Sans oublier une vaste gamme d'accessoires conçus et fabriqués selon les critères de qualité...
Page 21
Sommaire SOMMAIRE 22 Consignes de sécurité 25 Bandeau de commande 28 Première utilisation 28 Utilisation quotidienne 31 Conseils utiles 31 Entretien et nettoyage 33 En cas d'anomalie de fonctionnement 36 Caractéristiques techniques 36 Installation 37 Bruits 39 En matière de sauvegarde de l'environnement Les symboles suivants sont utilisés dans ce manuel:...
Consignes de sécurité CONSIGNES DE SÉCURITÉ Pour votre sécurité et garantir une utilisation correcte de l'appareil, lisez attentivement cet- te notice, y compris les conseils et avertissements, avant d'installer et d'utiliser l'appareil pour la première fois. Pour éviter toute erreur ou accident, veillez à ce que toute personne qui utilise l'appareil connaisse bien son fonctionnement et ses fonctions de sécurité.
Page 23
Consignes de sécurité • Le circuit frigorifique de l’appareil contient de l’isobutane (R600a), un gaz naturel offrant un haut niveau de compatibilité avec l’environnement mais qui est néanmoins inflam- mable. Pendant le transport et l'installation de votre appareil, assurez-vous qu'aucune partie du circuit frigorifique n'est endommagée.
Page 24
Consignes de sécurité • Respectez scrupuleusement les conseils de conservation donnés par le fabricant de l'ap- pareil. Consultez les instructions respectives. • Ne mettez pas de bouteilles ni de boîtes de boissons gazeuses dans le compartiment con- gélateur, car la pression se formant à l'intérieur du contenant pourrait le faire éclater et endommager ainsi l'appareil.
Bandeau de commande BANDEAU DE COMMANDE Mode Bouton ON/OFF ARRET MARCHE de l'appareil Bouton de réglage de la température Voyant de température et de fonction Bouton Mode (fonction) Bouton de confirmation Ecran d'affichage Alarme de température S'il est allumé, la fonction Minuteur est activée S'il est allumé, l'appareil est en fonc- S'il est allumé, la fonction Sécurité...
Page 26
Bandeau de commande • Avant d'introduire des aliments dans le congélateur, attendez que la température du compartiment soit de -18°C. • Pour sélectionner une température différente, reportez-vous au paragraphe " Réglage de la température ". Mise à l'arrêt En appuyant sur la touche Marche / Arrêt de l'appareil pendant plus d'une seconde, l'appa- reil est mis à...
Bandeau de commande • Clignotement des voyants d'alarme et de température et • déclenchement d'une alarme sonore Pour réinitialiser l'alarme : Appuyez sur la touche de confirmation. L'alarme s'éteint. La température maximum régnant dans le compartiment apparaît sur l'afficheur pendant quelques secondes. Puis il affiche à nouveau la température programmée. Le voyant d'alarme continue à...
Première utilisation Placez les aliments à congeler dans le congélateur dès que la période de pré-refroidisse- ment de 24 heures est écoulée. Le processus de congélation prend 24 heures : Vous ne devez ajouter aucune autre denrée à congeler au cours de cette période. Cette fonction s'arrête automatiquement au bout de 54 heures.
Utilisation quotidienne La quantité maximale de denrées que vous pouvez congeler par 24 heures est indiquée sur la plaque signalétique. Le processus de congélation prend 24 heures : vous ne devez ajouter aucune autre denrée à congeler au cours de cette période. Conservation des aliments congelés À...
Utilisation quotidienne Paniers de rangement Accrochez les paniers en haut du congélateur (X) ou placez-les à l'intérieur (Y). Tournez et bloquez les poignées en fonction de ces deux positions, comme indiqué. Les paniers s'emboîtent les uns dans les autres. Les figures suivantes vous indiquent les différen- 1061 1201 tes possibilités de chargement en fonction du type...
Conseils utiles CONSEILS UTILES Conseils pour la congélation Pour obtenir les meilleurs résultats, voici quelques conseils importants : • la quantité maximale de denrées que vous pouvez congeler par 24 heures est indiquée sur la plaque signalétique. • le temps de congélation est de 24 heures. Aucune autre denrée à congeler ne doit être ajoutée pendant cette période.
Page 32
Entretien et nettoyage Nettoyage périodique Mettez l'appareil à l'arrêt. Débranchez l'appareil. Nettoyez régulièrement les parois de l'appareil et les accessoires avec de l'eau tiède et un détergent liquide inodore (produit utilisé pour la vaisselle par exemple). Lavez le joint du couvercle avec précaution sans omettre de nettoyer également sous le joint. Rincez et séchez soigneusement les parois et les accessoires de l'appareil.
En cas d'anomalie de fonctionnement N'utilisez en aucun cas de couteau ou tout autre objet tranchant, d'objet métallique pour gratter la couche de givre, vous risquez de détériorer irrémédiablement l'évaporateur. N'uti- lisez aucun autre dispositif mécanique ou moyen artificiel que ceux qui sont recommandés par le fabricant pour accélérer le dégivrage de votre appareil.
Page 34
En cas d'anomalie de fonctionnement Anomalie Cause possible Solution Les aliments introduits dans Laissez refroidir les aliments à l'appareil étaient trop chauds. température ambiante avant de les stocker. La température ambiante du lo- Veillez à respecter la température cal où est installé l'appareil est idéale (classe climatique) dans la trop élevée pour permettre un pièce où...
Page 35
En cas d'anomalie de fonctionnement Anomalie Cause possible Solution Avant la congélation, la tempé- Laissez refroidir l'appareil à vide rature à l'intérieur de l'appareil pendant un temps suffisant. n'était pas suffisamment froide. Trop de produits frais ont été in- Attendez quelques heures et véri- troduits dans l'appareil.
Caractéristiques techniques Remplacement de l'ampoule Débranchez l'appareil du secteur. Remplacez l'ampoule défectueuse par une ampoule neuve de puissance identi- que, spécifiquement conçue pour les ap- pareils électroménagers (la puissance maximale est indiquée sur le diffuseur d'éclairage). Branchez l'appareil sur le secteur. Ouvrez la porte.
Bruits Classe climatique Température ambiante + 16 °C à + 43 °C Branchement électrique Contrôlez, avant de brancher l'appareil, si la tension et la fréquence indiquées sur la plaque signalétique correspondent à celles de votre réseau. L'appareil doit être relié à la terre. La fiche du câble d'alimentation comporte un logement pour mise à...
En matière de sauvegarde de l'environnement SSSRRR! SSSRRR! CRACK! CRACK! EN MATIÈRE DE SAUVEGARDE DE L'ENVIRONNEMENT Le symbole sur le produit ou son emballage indique que ce produit ne peut être traité comme déchet ménager. Il doit être remis au point de collecte dédié à cet effet (collecte et recyclage du matériel électrique et électronique).
Page 40
Minuten Zeit zum Lesen, um seine Vorzüge kennen zu lernen. ZUBEHÖR UND VERBRAUCHSMATERIALIEN Im AEG Webshop finden Sie alles, was Sie für ein makelloses Aussehen und perfektes Funktionieren Ihrer AEG Geräte benötigen. Wir bieten auch ein umfangreiches Zubehörsortiment, das Ihre höchsten Qualitätsansprüche erfüllt, vom Profi-Kochgeschirr bis zu...
Page 41
Inhalt INHALT 42 Sicherheitshinweise 45 Bedienfeld 48 Erste Inbetriebnahme 48 Täglicher Gebrauch 50 Praktische Tipps und Hinweise 51 Reinigung und Pflege 53 Was tun, wenn … 56 Technische Daten 56 Montage 57 Geräusche 59 Hinweise zum Umweltschutz In dieser Benutzerinformation werden folgende Symbole verwendet: Wichtige Hinweise zur Sicherheit von Personen und Informationen zur...
Sicherheitshinweise SICHERHEITSHINWEISE Lesen Sie zu Ihrer Sicherheit und für die optimale Geräteanwendung vor der Installation und dem Gebrauch des Gerätes die vorliegende Benutzerinformation aufmerksam durch, einschließlich der Ratschläge und Warnungen. Es ist wichtig, dass zur Vermeidung von Feh- lern und Unfällen alle Personen, die das Gerät benutzen, mit der Bedienung und den Sicher- heitsvorschriften vertraut sind.
Page 43
Sicherheitshinweise Achten Sie beim Transport und bei der Aufstellung des Gerätes darauf, nicht die Kompo- nenten des Kältekreislaufs zu beschädigen. Bei einer eventuellen Beschädigung des Kältekreislaufs: – Offene Flammen und Zündfunken vermeiden – Den Raum, in dem das Gerät installiert ist, gut lüften •...
Page 44
Sicherheitshinweise Reinigung und Pflege • Schalten Sie vor Wartungsarbeiten immer das Gerät ab und ziehen Sie den Netzstecker aus der Steckdose. • Reinigen Sie das Gerät nicht mit Metallgegenständen. • Verwenden Sie keine scharfen Gegenstände zum Entfernen von Reif und Eis im Gerät. Benutzen Sie einen Kunststoffschaber.
Bedienfeld BEDIENFELD Mode Taste Gerät ON/OFF Temperaturreglertaste Temperatur- und Funktionsanzeige Taste Modus (Funktion) Bestätigungstaste Display Temperaturwarnung (Temperatur zu Wenn dieses Symbol leuchtet, ist die hoch) Timer-Funktion aktiv Wenn dieses Symbol leuchtet, ist das Wenn dieses Symbol leuchtet, ist die Gerät eingeschaltet. Wenn das Sym- Kindersicherung aktiv bol schnell blinkt, ist die Frostmatic- Funktion aktiv...
Page 46
Bedienfeld • Warten Sie mit dem Einlegen von Lebensmitteln in den Gefrierraum, bis die Innentempe- ratur -18 °C erreicht hat. • Näheres zur Wahl einer anderen Temperatur siehe "Temperaturregelung". Ausschalten Das Gerät wird ausgeschaltet, wenn Sie die Taste Gerät ON/OFF länger als 1 Sekunde lang drücken.
Page 47
Bedienfeld • Blinkende Alarm- und Temperaturanzeige des Gefriergeräts. • Ein Alarmsignal ertönt. Zurücksetzen des Alarms: Bestätigungstaste drücken. Der Summer wird abgeschaltet. Die in dem Fach erreichte höchste Temperatur wird an der Anzeige für einige Se- kunden angezeigt. Danach zeigt sie wieder die eingestellte Temperatur an. Die Alarmanzeige blinkt so lange, bis die normalen Bedingungen wieder hergestellt sind.
Erste Inbetriebnahme Der Gefriervorgang dauert 24 Stunden. Legen Sie während dieses Zeitraums keine weiteren Lebensmittel in das Gefriergerät. Diese Funktion endet automatisch nach 54 Stunden. Diese Funktion kann jederzeit ausgeschaltet werden. Drücken Sie die Funktionstaste, bis das entsprechende Symbol blinkt, und drücken Sie dann die Bestätigungstaste. Funktion Getränke kühlen Die Funktion Getränke kühlen dient als Sicherheitseinrichtung, wenn Flaschen in den Ge- frierraum eingelegt werden.
Täglicher Gebrauch Der Gefriervorgang dauert 24 Stunden. Legen Sie während dieses Zeitraums keine weiteren einzufrierenden Lebensmittel in den Gefrierraum. Lagerung gefrorener Produkte Lassen Sie das Gerät vor der ersten Inbetriebnahme oder nach einer Zeit, in der das Gerät nicht benutzt wurde, mindestens zwei Stunden lang auf den höheren Einstellungen laufen, bevor Sie Lebensmittel in das Gefrierfach hinein legen.
Praktische Tipps und Hinweise Die folgenden Abbildungen zeigen, wie viele Körbe 1061 1201 in die verschiedenen Gefrierschrankmodelle ein- gesetzt werden können. Weiter Körbe können Sie bei Ihrem Fachhändler 1336 1611 beziehen. Sicherheits-Verriegelung Die Gefriertruhe ist mit einer Spezialverriegelung ausgestattet, um eine versehentliche Ver- riegelung zu vermeiden.
Reinigung und Pflege • frieren Sie ausschließlich frische und gründlich gewaschene Lebensmittel von sehr guter Qualität ein; • teilen Sie die Lebensmittel in kleinere Portionen ein, damit diese schnell und vollständig gefrieren und Sie später nur die Menge auftauen müssen, die Sie gerade benötigen; •...
Page 52
Reinigung und Pflege Schalten Sie das Gerät ein. VORSICHT! Benutzen Sie zur Reinigung des Innenraums keinesfalls Putzmittel, Scheuerpulver, stark parfümierte Reinigungsmittel oder Wachspolituren, da diese die Oberfläche des Innenraums beschädigen können. Bitte achten Sie darauf, das Kühlsystem nicht zu beschädigen. Der Kompressorbereich muss nicht gereinigt werden.
Was tun, wenn … Lassen Sie den Deckel offen, um das Entstehen unangenehmer Gerüche zu vermeiden. Möchten Sie bei einer längeren Abwesenheit das Gerät weiterlaufen lassen, bitten Sie je- manden, gelegentlich die Temperatur zu prüfen, damit das Gefriergut bei einem möglichen Stromausfall nicht im Innern des Gerätes verdirbt.
Page 54
Was tun, wenn … Störung Mögliche Ursache Abhilfe Zu starke Reif- und Eisbil- Das Gefriergut ist nicht korrekt Verpacken Sie die Lebensmittel dung. verpackt. besser. Der Deckel schließt nicht richtig Prüfen Sie, ob der Deckel gut oder ist nicht richtig geschlos- schließt und die Dichtungen un- sen.
Page 55
Was tun, wenn … Störung Mögliche Ursache Abhilfe Der Deckel stand zu lange Zeit Lassen Sie den Deckel nicht län- auf. ger als unbedingt erforderlich of- fen. Es ist zu kalt im Gefrier- Die Temperatur ist nicht richtig Stellen Sie eine höhere Tempera- schrank.
Technische Daten TECHNISCHE DATEN Abmessungen Höhe × Breite × Tiefe (mm): Weitere technische Informationen be- finden sich auf dem Typenschild auf 876 × 1611 × 665 der rechten Außenseite des Gerätes. Ausfalldauer 58 Stunden MONTAGE Aufstellung WARNUNG! Wenn Sie ein altes Gerät entsorgen möchten, das ein Schloss oder einen Riegel an der Tür besitzt, müssen Sie das Schloss bzw.
Geräusche Vergewissern Sie sich, dass der Abstand zwischen dem Gerät und dem Schrank 5 cm beträgt. Vergewissern Sie sich, dass der Abstand zwischen dem Gerät und den Seiten 5 cm be- trägt. Die Luftzirkulation hinter dem Gerät muss ausreichend groß sein. GERÄUSCHE Während das Gerät in Betrieb ist, entstehen bestimmte Geräusche (Kompressor und Kühl- kreislauf).
Hinweise zum Umweltschutz HINWEISE ZUM UMWELTSCHUTZ Das Symbol auf dem Produkt oder seiner Verpackung weist darauf hin, dass dieses Produkt nicht als normaler Haushaltsabfall zu behandeln ist, sondern an einem Sammelpunkt für das Recycling von elektrischen und elektronischen Geräten abgegeben werden muss.
