DIRECT-VENT FIREPLACE
OWNER'S OPERATION AND INSTALLATION MANUAL
REMOTE REQUIRES
TWO 9-VOLT
BATTERIES -
NOT INCLUDED
CDV37N/P(A,B) AND CDV41N/P(A,B)
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited
by state or local codes.
*
Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Save this manual for future reference.
®
WARNING: Improper in-
stallation, adjustment, al-
teration, service, or main-
tenance can cause injury
or property damage. Re-
fer to this manual for cor-
rect installation and op-
erational procedures. For
assistance or additional
information consult a
qualified installer, ser-
vice agency, or the gas
supplier.
— Installation and ser-
vice must be performed
by a qualified installer,
service agency, or the
gas supplier.
Advertisement
Table of Contents
Related Manuals for Comfort Glow CDV37N/PA
Summary of Contents for Comfort Glow CDV37N/PA
- Page 1 DIRECT-VENT FIREPLACE OWNER’S OPERATION AND INSTALLATION MANUAL ® REMOTE REQUIRES TWO 9-VOLT BATTERIES - NOT INCLUDED CDV37N/P(A,B) AND CDV41N/P(A,B) WARNING: If the information in this manual is not WARNING: Improper in- followed exactly, a fire or explosion may result caus- stallation, adjustment, al- ing property damage, personal injury, or loss of life.
-
