3 7 63 1515 0 SERVICE MANUAL DVD RECEIVER WITH MONITOR MA184 2005 KD-AV7010 Area suffix J ------------- Northern America L 13942296513 MAIN ZOOM DUAL AVOUT VOL ASPECT MENU TOPMENU RETURN SET UP DISC TUNER 11 / 0 12 /+1 0...
Page 2
http://www.xiaoyu163.com 3 7 63 1515 0 SPECIFICATION Main unit AUDIO AMPLIFIER SECTION 20 W RMS × 4 Channels at 4 Ω and [< or =] 1% THD+N Power Output Front and Rear 18 W RMS × 1 Channel at 4 Ω and [< or =] 1% THD+N Center 80 dBA (reference: 1 W into 4 Ω) Signal to Noise Ratio...
Page 3
http://www.xiaoyu163.com 3 7 63 1515 0 REMOVABLE MONITOR Screen Size 7 inch wide liquid crystal display 336 960 pixels (480 vertical × 234 horizontal × 3) Number of Pixel Drive Method TFT (Thin Film Transistor) active matrix format Color System NTSC Aspect Ratio 16:9 (wide)
http://www.xiaoyu163.com SECTION 1 3 7 63 1515 0 PRECAUTIONS Safety Precautions Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
Page 5
http://www.xiaoyu163.com Preventing static electricity 3 7 63 1515 0 Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.2.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Page 6
http://www.xiaoyu163.com Important for laser products 3 7 63 1515 0 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated.
http://www.xiaoyu163.com SECTION 2 3 7 63 1515 0 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. L 13942296513 u163 (No.MA184)1-7 http://www.xiaoyu163.com...
http://www.xiaoyu163.com SECTION 3 3 7 63 1515 0 DISASSEMBLY Receiver unit section 3.1.1 Removing the detach panel assembly (See Fig.1) From the front side of the main body, slide the detach button in the direction of the arrow and remove the detach panel assem- Detach button bly.
Page 9
http://www.xiaoyu163.com 3.1.2 Removing the front panel assembly 3 7 63 1515 0 (See Fig.2 to 4) • Remove the detach panel assembly as required. (1) From the both sides of the main body, remove the two Front panel assembly screw A attaching the front panel assembly. (See Figs.2 and 3) (2) From the bottom side of the main body, remove the FPC cover.
Page 10
http://www.xiaoyu163.com 3.1.3 Removing the top drive unit 3 7 63 1515 0 (See Figs.5 to 8) • Prior to performing the following procedures, remove the de- tach panel assembly and front panel assembly. Top drive unit (1) From the both sides of the main body, remove the four screws B attaching the top drive unit.
Page 11
http://www.xiaoyu163.com 3.1.4 Removing the rear bracket 3 7 63 1515 0 (See Figs.9) Rear bracket • Prior to performing the following procedures, remove the de- tach panel assembly, front panel assembly and top drive unit. From the rear side of the main body, remove the five screws G attaching the rear bracket.
Page 12
http://www.xiaoyu163.com 3.1.6 Removing the main board 3 7 63 1515 0 (See Figs.12 and 13) • Prior to performing the following procedures, remove the de- tach panel assembly, front panel assembly, top drive unit and Rear bracket DVD mechanism assembly. (1) From the rear side of the main body, remove the four screws K attaching the rear bracket.
Page 13
http://www.xiaoyu163.com Top drive unit section 3 7 63 1515 0 • Remove the top drive unit from the main body. (See "3.1.4 Removing the top drive unit".) 3.2.1 Removing the display drive unit (See Fig.1) (1) From the both sides of the top drive unit, remove the two screws A attaching the display guides L/R and remove the display guides L/R from the top chassis assembly.
Page 14
http://www.xiaoyu163.com 3.2.2 Removing the drive gears and forth gear 3 7 63 1515 0 (See Figs.2 to 4) • Remove the display drive unit. (1) From the both sides of the display drive unit, remove the Guide rail (L) four screws B attaching the guide rails (L)/(R). (See Figs.2 Display drive unit and 3.) (2) From the top side of the display drive unit, pull the drive...
Page 15
http://www.xiaoyu163.com 3.2.3 Removing the cover 3 7 63 1515 0 (See Fig.5) • Remove the display drive unit. From the top side of the display drive unit, remove the two Cover Display drive unit screws C attaching the cover. Fig.5 L 13942296513 u163 (No.MA184)1-15...
Page 16
http://www.xiaoyu163.com 3.2.4 Removing the third gear, worm gear and double worm 3 7 63 1515 0 (See Figs.6 to 11) • Remove the display drive unit and cover. (1) Remove the wire sheet with the wire from the motor. (See Wire Fig.6.) Reference:...
Page 17
http://www.xiaoyu163.com 3 7 63 1515 0 Motor bracket (S) Fig.9 Motor Worm gear 16 ± 0.1 (mm) L 13942296513 Fig.10 Display drive unit Double worm Fig.11 u163 (No.MA184)1-17 http://www.xiaoyu163.com...
Page 18
http://www.xiaoyu163.com 3.2.5 Removing the worm gear, motor bracket (A) and third worm 3 7 63 1515 0 (See Figs.12 to 16) • Remove the display drive unit and cover. (1) Disconnect the wire from the connector CN311 on the mo- Motor tor board.
Page 19
http://www.xiaoyu163.com 3.2.6 Removing the second wheel and R.L.S. gear 3 7 63 1515 0 (See Figs.17 to 24) • Remove the display drive unit and cover. (1) Disconnect the wire from the connector CN311 on the mo- Motor bracket (A) Worm guide tor board.
Page 20
http://www.xiaoyu163.com 3 7 63 1515 0 Joint gear Torsion spring (R.L.S.) R.L.S. spring R.L.S. spring R.L.S. bracket Second wheel Hex gear Fig.20 Fig.23 Torsion spring (R.L.S.) R.L.S. bracket Hex gear Second wheel L 13942296513 Fig.21 Display drive unit Third gear R.L.S.
Page 21
http://www.xiaoyu163.com Display unit section 3 7 63 1515 0 • Remove the display unit from the main body. (See "3.1.1 Removing the display unit".) 3.3.1 Removing the display back panel (See Figs.1 to 3) (1) From the both sides of the display unit, remove the six screws A attaching the display back panel.
Page 22
http://www.xiaoyu163.com 3.3.2 Removing the switch board 3 7 63 1515 0 (See Fig.4) • Removing the switch board (See Fig.4) (1) Release the lock of the connector CN402 on the display Switch board Display board board in the direction of the arrow and disconnect the card wire.
Page 23
http://www.xiaoyu163.com DVD mechanism assembly section 3 7 63 1515 0 3.4.1 Removing the front end board (See Fig.1) Caution: Before disconnecting the flexible wire extending from the DVD DVD mechanism assembly pickup, solder the short-circuit point on the flexible wire using Flexible wire a grounding soldering iron.
Page 24
http://www.xiaoyu163.com 3.4.2 Removing the top cover 3 7 63 1515 0 (See Fig.2) (1) Remove the two screws C attaching the top cover on the back of the body. (2) Remove the top cover upward. Reference: When reassembling, set part b of the top cover under the bending part c of the chassis frame.
Page 25
http://www.xiaoyu163.com 3.4.4 Removing the clamper unit 3 7 63 1515 0 (See Figs.5 to 7) • Remove the top cover and the mechanism section. (1) Remove the clamper2 spring on the bottom of the mecha- Clamper spring nism section. (See Figs.5.and 6.) (2) Release the part d of the clamper spring from the bending part of the chassis base assembly.
Page 26
http://www.xiaoyu163.com 3.4.5 Reattaching the clamper unit 3 7 63 1515 0 (See Figs.5 to 9) (1) Attach the clamper spring to the clamper unit. (See Fig.8.) (2) Move the clamper unit to set the side joints e and f to each Clamper unit boss of the chassis base assembly.
Page 27
http://www.xiaoyu163.com 3.4.6 Removing the front unit 3 7 63 1515 0 (See Figs.10 to 12) • Remove the top cover and the mechanism section. (1) Disconnect the flexible wire from connector CN202 on the front end board at the bottom of the body. (See Fig.10.) Front unit (2) Remove the screw E attaching the front unit on the top of the body.
Page 28
http://www.xiaoyu163.com 3.4.7 Removing the loading arm assembly. 3 7 63 1515 0 (See Figs.13 and 14) • Remove the top cover, the mechanism section and the front unit. (1) From the top of the body, move the loading arm assembly. from the front side upward, and release the bosses from the right and left joints k and m of the chassis base assem- bly.
Page 29
http://www.xiaoyu163.com 3.4.8 Removing the rod (L)(R)/roller assembly 3 7 63 1515 0 (See Figs.15 and 16) • Remove the top cover, the mechanism section, the front unit and the loading arm assembly. Collar Collar (1) Release the rod (L) and (R) from the joints q at the bottom of the loading arm assembly.
Page 30
http://www.xiaoyu163.com 3.4.9 Removing the DVD pickup 3 7 63 1515 0 (See Figs.17 to 19) • Remove the front end board. (1) From the bottom of the body, turn the feed gear in the di- rection of the arrow to move the DVD pickup outwards. L.S.
Page 31
http://www.xiaoyu163.com 3.4.10 Removing the spindle motor 3 7 63 1515 0 (See Fig.20) • Remove the front end board. Remove the two screws J attaching the spindle motor on the DVD mechanism assembly bottom of the body. Spindle motor Caution: Perform adjustment when reattaching the spindle motor.
Page 32
http://www.xiaoyu163.com 3.4.11 Removing the feed motor assembly 3 7 63 1515 0 (See Figs.21 and 22) • Remove the front end board. (1) Remove the feed TRI. spring on the bottom of the body. (See Fig.21.) Feed TRI. spring Feed motor assembly (2) Remove the two screws K attaching the feed motor assem- bly.
Page 33
http://www.xiaoyu163.com Hideaway unit section 3 7 63 1515 0 3.5.1 Removing the top chassis (See Figs.11 to 3) (1) From the both sides of the main body, remove the four screws A attaching the top chassis. (See Fig.1 and 2.) Top chassis (2) From the front side of the main body, remove the three screws A, screw B and four screws C attaching the top...
Page 34
http://www.xiaoyu163.com 3.5.3 Removing the hideaway board 3 7 63 1515 0 (See Figs.5 and 6) • Prior to performing the following procedures, remove the top chassis and DSP board. (1) From the rear side of the main body, remove the four screws E attaching the hideaway board.
http://www.xiaoyu163.com SECTION 4 3 7 63 1515 0 ADJUSTMENT Adjustment method 4.1.1 Test instruments required for adjustment 4.1.2 Standard measuring conditions (1) Digital oscilloscope (100MHz) Power supply voltage DC14.4V(11 to 16V) (2) Jitter meter Load impedance 4Ω(2 Speakers connection) (3) Digital tester Line output 20kΩ...
Page 36
http://www.xiaoyu163.com 4.1.4 Connecting diagram of extension cable 3 7 63 1515 0 Fix it with tape. Fix it with tape. L 13942296513 Monitor stability base Extension cable Example : Wood panel EXTAV70X-50PF (200mm x 170mm x 15mm) Fix it in a slit. Extension stud STDV001-3P Fig.1...
Page 37
http://www.xiaoyu163.com 4.1.5 Adjustment method for jitter 3 7 63 1515 0 After replacing the pickup, set the unit in the service mode to display a jitter value on the LCD. Confirm that the jitter value measured with a jitter meter is within 12.0% of the jitter value displayed on the LCD. If it is within 12.0%, then adjustment is not necessary. If the measured jitter value is outside the 12.0% tolerance range, perform the following adjustments.
Page 38
http://www.xiaoyu163.com 4.1.6 Jitter value conversion table 3 7 63 1515 0 Load the test disc and set the unit to the service mode. A jitter value converted to the hex value is displayed on the LCD. Refer to the corresponding decimal notation value shown in the following Jitter Conversion Table. The adjustment is OK if the jitter value measured with a jitter meter is within 12.0% of the jitter value displayed on the LCD.
Page 39
http://www.xiaoyu163.com 4.1.7 Monitor adjustment 3 7 63 1515 0 Procedure: (1) Install a monitor to the main unit in the state that took off a display back panel. (2) Switch on the main unit. (3) According to the following chart, perform each adjustment. Item Adjustment points Adjustment volume Adjustment value...
Page 40
http://www.xiaoyu163.com Service mode 3 7 63 1515 0 4.2.1 Jigs and test instruments (1) Test disc: VT-501, VT-502 (2) NTSC signal generator (E version only) 4.2.2 Standard input/output conditions Power supply voltage: C14.4V (11V to 16V) 4 Ω (2 Speakers connection) Load impedance: 20k Ω...
Page 41
http://www.xiaoyu163.com 4.2.4 Service mode menu 3 7 63 1515 0 MENU AREA/REGION : Indication of destination and region Service Mode Menu AREA / REGION MONITOR HIDE - AREA : aa TOUCH PANEL TEST B / E - AREA : bb TOUCH PANEL CALIBRATION B / E - REGION : cc...
Page 42
http://www.xiaoyu163.com 3 7 63 1515 0 READ ERROR : Indication of an error history See "4.2.6 Error code table" for details. LOADING/EJECT mechanism error Monitor mechanism error Changer error "TOTAL ERROR :zzzzzz" Total error count (A figure between 0 and 999999 is displayed. 1000000 or more is also displayed as 999999.) "E-n :xxyyyy"...
Page 43
http://www.xiaoyu163.com 3 7 63 1515 0 Touch Panel Calibration : Touch panel proofreading mode TOUCH PANEL CALIBRATION CODE 8Dh See "4.2.8 Touch panel manual operation proofreading procedure" for details. Push with a finger from 81h in turn. After the proofreading end, push the [PREVIOUS ] button in order to switch off the panel.
Page 44
http://www.xiaoyu163.com 4.2.6 Error code table 3 7 63 1515 0 (1) Error code table of LOADING/EJECT mechanism error Error code (1 byte) Detailed error codes (2 bytes) First byte [01] Eject error First byte Higher 4 bits Route No. (Process of error occurrence) [09] Loading error Refer to charts 1.1 and 1.2.
Page 45
http://www.xiaoyu163.com 3 7 63 1515 0 (2) Error code table of monitor mechanism error Error code (1 byte) Detailed error codes (2 bytes) First byte [01] CLOSE error First byte Higher 4 bits Route No. (Process of error occurrence) [09] OPEN error Lower 4 bits Error type [0A] SLIDE error...
Page 46
http://www.xiaoyu163.com 4.2.7 Monitor adjustment 3 7 63 1515 0 1. Switch on the main unit and insert a test disc (VT-501 or VT-502). Play a 3TR(100% color bar) of the test disc and pause it. 2. In a state of procedure 1, set the main unit in a service mode. (See "5.1.3 Service mode setting procedure".) 3.
Page 47
http://www.xiaoyu163.com 4.2.8 Touch panel manual operation proofreading procedure 3 7 63 1515 0 Procedure 1 Proofreading (1) Set the main unit in a touch panel proofreading mode. (2) Push the center of the figure of a cross in a circle of green (81h to 89h) on the panel in turn. a) Push for each 3 points of the upper part of 81h and 82h and 83h with a thumb of the right hand (or, left hand) on the panel from a direction.
http://www.xiaoyu163.com SECTION 5 3 7 63 1515 0 TROUBLESHOOTING AV bus cable between main unit and hideaway unit QAM0612-002 6000 mm L 13942296513 QAM0612-001 2500 mm RESET Black Pink HPA-GND Black(Tube) P-ON White Light green SPDIFGND Black(Tube) Brown DVDAR DVDAL Green Yellow HPAL...
Page 49
http://www.xiaoyu163.com Center speaker / rear camera cord 3 7 63 1515 0 WHITE BLACK VI/WH VIOLET BK/WH 1 VI/WH BACK CAMERA 3 BK CENTER 4 BK/WH 2500 mm Extention aerial cord JACK PLUG L 13942296513 2593 mm u163 (No.MA184)1-49 http://www.xiaoyu163.com...
Page 50
http://www.xiaoyu163.com Power cord for main unit 3 7 63 1515 0 1 YL Yellow 4 BK Black Orange 2 RD 5 OR EARTH Earth CORE Core EARTH CORE POWER LEAD/ MEMORY BACK UP POWER LEAD GROUND ILLUMINATION CONTROL MJ-164A L 13942296513 u163 1-50 (No.MA184) http://www.xiaoyu163.com...
Page 51
http://www.xiaoyu163.com Power cord for hideway unit 3 7 63 1515 0 9 WH 8 GN Black Green GN/BK WH/BK Violet Blue VI/WH GY/BK Gray White 12 GY Yellow L.GN Light Green 5 VI 13 NC 4 BL BL/WH 14 L.GN 2 NC 15 NC 1 BK...
Page 52
http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MA184) Printed in Japan http://www.xiaoyu163.com...
Page 53
3 7 63 1515 0 SCHEMATIC DIAGRAMS DVD RECEIVER WITH MONITOR KD-AV7010 CD-ROM No.SML200504 Area suffix J ------------- Northern America L 13942296513 MAIN ZOOM DUAL AVOUT VOL ASPECT MENU TOPMENU RETURN SET UP TUNER DISC 11 / 0 12 /+1 0...
http://www.xiaoyu163.com 3 7 63 1515 0 Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
Page 55
http://www.xiaoyu163.com 3 7 63 1515 0 < M E M O > L 13942296513 u163 http://www.xiaoyu163.com...
http://www.xiaoyu163.com 3 7 63 1515 0 Block diagram Front panel section Front end section ILL10V IC51 SYS5V IC301 SPINDLE FEED DISC POSITION 6SEG.LCD IC291 LCDCLK MOTOR MOTOR SODC KEY (MATRIX) AV8V/DVM8V LCDDI LCDCE DRIVER DVD3.3V DISC IN LED IC81 LCDKEY /D1.8V IC201 EJECT BUTTON LED...
Page 57
http://www.xiaoyu163.com 3 7 63 1515 0 Audio/Video output, amplifier, system control and tuner & DC/DC converter section IC51 IC850 HIDEAWAY CPU IC875 MEMORY FM/AM RDS EUR J-BUS Buffer IC81 J-BUS DAB DVD-ON SOURCE SEL GUI-ON CONT E-VOL CONTROL P-ON LEVEL DETECT FOR LEVEL METER CN893 BUS CONNECTOR CNTL...
Page 104
http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MA184SCH) http://www.xiaoyu163.com...
3 7 63 1515 0 PARTS LIST [ KD-AV7010 ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix J ------------- Northern America L 13942296513 - Contents - Exploded view of general assembly and parts list (Block No.M1) Hideaway assembly and parts list (Block No.M2)
Page 106
http://www.xiaoyu163.com 3 7 63 1515 0 Exploded view of general assembly and parts list Block No. Main board L 13942296513 Switch board 62 56 u163 http://www.xiaoyu163.com...
Page 107
http://www.xiaoyu163.com 3 7 63 1515 0 Display Drive unit Connect board Display Drive unit L 13942296513 Top view u163 http://www.xiaoyu163.com...
Page 108
http://www.xiaoyu163.com 3 7 63 1515 0 General Assembly Block No. [M][1][M][M] Symbol No. Part No. Part Name Description Local LV10946-004A TOP DRIVE UNIT LV34862-002A F.P.C.GUIDE LV44159-001A SCREW M2 x 3mm(x2) LV43745-001A SPECIAL SCREW LV34867-001A PWB BASE LV44159-001A MINI SCREW (x3) LV43747-001A INSULATOR...
Page 109
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local QUQ105-1304AB FFC WIRE 13pin 4cm QAL0583-001 LV44218-002A SUPPORT SHEET LV44218-003A SUPPORT SHEET LV36094-001A NAME PLATE QUQ110-2003AF FFC WIRE 20pin 3cm LV35183-001A LABEL(DVD) LV34887-001A PCB BKT LV34888-001A CONNECTOR COVER LV43730-003A...
Page 110
http://www.xiaoyu163.com 3 7 63 1515 0 Hideway assembly and parts list Block No. DSP board Hideaway board L 13942296513 u163 http://www.xiaoyu163.com...
Page 111
http://www.xiaoyu163.com 3 7 63 1515 0 Hideway assembly and parts list Block No. [M][2][M][M] Symbol No. Part No. Part Name Description Local LV10897-006A TOP CHASSIS LV35421-002A SHIELD QYSDST2606MA TAP SCREW M2.6 x 6mm(x4) LV34933-002A B.CHASSIS ASSY LV34909-001A INSURATING SHEE LV41200-004A SPECIAL SCREW (x3)
Page 112
http://www.xiaoyu163.com 3 7 63 1515 0 Monitor assembly and parts list Block No. L 13942296513 u163 http://www.xiaoyu163.com...
Page 113
Monitor assembly and parts list Block No. [M][4][M][M] Symbol No. Part No. Part Name Description Local LV10891-021A DISPLAY PANEL GE40204-001A JVC BADGE LV34872-002A BLIND SHEET LV34873-005A OPEN BUTTON LV34874-003A ANGLE BUTTON LV21682-006A DISP BACK PANEL LV43819-003A SPECAL SCREW (x6)
Page 114
http://www.xiaoyu163.com 3 7 63 1515 0 DVD mechanism assembly and parts list Block No. Grease FLM-JD2-1D = JVS-1003 = MOBIL-1 = JVG-31N = JC-803B = 1401C L 13942296513 u163 The parts without symbol number are not service. 3-10 http://www.xiaoyu163.com...
Page 115
http://www.xiaoyu163.com 3 7 63 1515 0 DVD mechanism Block No. [M][J][M][M] Symbol No. Part No. Part Name Description Local VKZ4539-026 MINI SCREW (x2) QYSPSFT2040Z TAP SCREW M2 x 4mm LV43481-001A COOLING RUBBER (x2) LV10674-002A CHASSIS FRAME LV30225-0J6A SPACER (x2) LV33684-001A DAMPER(F) (x2)
Page 116
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local LV43063-001A L.S.COLLAR LV43011-001A THRUST SPRING QYSPSFT2040Z TAP SCREW M2 x 4mm LV33624-001A HOLDER(M) VKZ4539-026 MINI SCREW (x2) LV21288-001A HOLDER(S) VKZ4539-026 MINI SCREW (x2) LV43064-001A ROD(M) LV43065-001A ROD(S) LV43066-001A...
http://www.xiaoyu163.com 3 7 63 1515 0 Electrical parts list Main board Symbol No. Part No. Part Name Description Local Block No. [0][1] Q701 2SB709A/R/-X TRANSISTOR Symbol No. Part No. Part Name Description Local Q702 UN2211-X TRANSISTOR Q801 UN2211-X TRANSISTOR Q901 RSQ035P03-W...
Page 118
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C513 NCB31CK-104X C CAPACITOR 0.1uF 16V K C948 NBE41CM-226X TA E CAPACITOR 22uF 16V M C514 NBE41DM-106X TA E CAPACITOR 10uF 20V M...
Page 119
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C1204 NDC31HJ-101X C CAPACITOR 100pF 50V J C2021 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1205 NCB31CK-104X C CAPACITOR 0.1uF 16V K C2022...
Page 120
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C2503 NBE41CM-106X TA E CAPACITOR 10uF 16V M R305 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J C2504 NDC31HJ-100X C CAPACITOR 10pF 50V J...
Page 121
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R404 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R931 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R411 NRSA63J-331X MG RESISTOR 330Ω...
Page 122
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R1107 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1706 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R1109 NRSA63J-471X MG RESISTOR 470Ω...
Page 123
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R2057 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R2235 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R2058 NRSA63J-101X MG RESISTOR 100Ω...
Page 124
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R2522 NRSA63J-100X MG RESISTOR 10Ω 1/16W J K101 NQR0007-002X FERRITE BEADS R2523 NRSA63J-681X MG RESISTOR 680Ω 1/16W J K102 NQR0007-002X FERRITE BEADS...
Page 125
http://www.xiaoyu163.com 3 7 63 1515 0 Monitor board Symbol No. Part No. Part Name Description Local Block No. [0][3] D2941 MA152WK-X SI DIODE Symbol No. Part No. Part Name Description Local D2942 SML-310LT/MN/-X D2943 SML-310LT/MN/-X D2944 NSCW505CT/BST-X IC401 UPD780053GC-184 IC(MCU) IC402...
Page 126
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local D5102 SML-310LT/MN/-X C4242 NCB31CK-104X C CAPACITOR 0.1uF 16V K D5103 SML-310LT/MN/-X C4243 NCB30JK-105X C CAPACITOR 1uF 6.3V K D5104 SML-310LT/MN/-X C4244...
Page 127
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C4491 NCB31CK-104X C CAPACITOR 0.1uF 16V K C4852 NCB31CK-104X C CAPACITOR 0.1uF 16V K C4492 NCB31CK-104X C CAPACITOR 0.1uF 16V K C4861...
Page 128
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R4228 NRSA63D-752X MG RESISTOR 7.5kΩ 1/16W D R4457 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J R4229 NRSA63D-473X MG RESISTOR 47kΩ...
Page 129
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local L4201 NQL382M-470X COIL 47uH M IC721 M62449FP-X L4202 NQL382M-470X COIL 47uH M IC731 M62449FP-X L4301 NQL085J-100X COIL 10uH J IC751...
Page 130
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local D6093 1N5401-F64 DIODE C6123 QERF1EM-475Z E CAPACITOR 4.7uF 25V M D6502 1SS355-X SI DIODE C6124 QERF1HM-225Z E CAPACITOR 2.2uF 50V M D6503...
Page 131
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C7001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7412 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7002 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7413...
Page 132
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C8362 QERF1EM-475Z E CAPACITOR 4.7uF 25V M R6094 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C8363 QERF1EM-475Z E CAPACITOR 4.7uF 25V M R6097...
Page 133
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R6523 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R8002 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6524 NRSA63J-473X MG RESISTOR 47kΩ...
Page 134
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local R8584 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J L8917 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8585 NRSA63J-102X MG RESISTOR 1kΩ...
Page 135
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C9013 NCB31CK-104X C CAPACITOR 0.1uF 16V K C9606 NCB31HK-471X C CAPACITOR 470pF 50V K C9015 NCB31CK-104X C CAPACITOR 0.1uF 16V K C9607...
Page 136
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C9841 QERF1CM-106Z E CAPACITOR 10uF 16V M R9157 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C9842 QERF1CM-106Z E CAPACITOR 10uF 16V M R9161...
Page 137
http://www.xiaoyu163.com 3 7 63 1515 0 Front end board Symbol No. Part No. Part Name Description Local Block No. [0][6] R9705 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9706 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J Symbol No. Part No. Part Name Description Local...
Page 138
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local Symbol No. Part No. Part Name Description Local C271 NCB21CK-105X C CAPACITOR 1uF 16V K R120 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J C272 NCB21CK-105X C CAPACITOR 1uF 16V K R125...
Page 139
http://www.xiaoyu163.com 3 7 63 1515 0 Symbol No. Part No. Part Name Description Local R339 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R340 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R341 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R342 NRSA63J-103X MG RESISTOR 10kΩ...
Page 140
http://www.xiaoyu163.com 3 7 63 1515 0 Packing materials and accessories parts list Block No. No additional / supplemental order of WARRANTY CARDs are available A8,A9,A10, A11,A12,A14, A21,A22 A1,A2,A3, A4,A5,A6 A13,A23,A24 L 13942296513 u163 The parts without symbol number are not service. 3-36 http://www.xiaoyu163.com...
Page 141
http://www.xiaoyu163.com 3 7 63 1515 0 Packing and Accessories Block No. [M][3][M][M] Symbol No. Part No. Part Name Description Local LVT1369-001A INST BOOK LVT1369-002A INSTALL MANUAL LVT1175-001A IMPORTANT SHEET ------------ WARRANTY CARD BT-51018-4 ------------ J=REGIST CARD BT-51034-2 ------------ WARRANTY CARD BT-52006-2 LVT1318-001A CAUTION SHEET...
