Page 1: Table Of Contents
3406079 Electric and Gas Dryers A Note to You ...2 Dryer Safety ...3 Parts and Features ...5 Checking Your Vent ...6 Using Your Dryer...8 Starting your dryer...8 Loading ...10 Selecting a cycle and temperature setting ...10 No Heat Fluff cycle ...13 Using the drying rack ...14...
Page 2: A Note To You
OTE TO Thank you for buying a Kirkland Signature™ appliance by Whirlpool Corporation. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. It is full of valuable information about how to operate and maintain your appliance properly and safely. Please read it carefully.
Page 3: Dryer Safety
RYER AFETY Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others. All safety messages will be preceded by the safety alert symbol and the word “DANGER”...
Page 4 RYER AFETY IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions, including the following: • Read all instructions before using the dryer. • Do not place items exposed to cooking oils in your dryer.
Page 5: Parts And Features
ARTS AND FEATURES The drawings in this book may vary from your dryer model. They are designed to show the different features of all models covered by this book. Your model may not include all features. Cycle control knob (pp. 8-14) Model and serial number label...
Page 6: Checking Your Vent
HECKING Your dryer must be properly installed and vented to achieve maximum drying efficiency and shorten drying times. Use the minimum recommended installation clearances (found in your Installation Instructions) to avoid blocking the flow of combustion and ventilation air. Install your dryer in a well-ventilated room where the temperature is always above 45ºF (7ºC).
Page 7 ENTING CONT Use the straightest path possible when routing the exhaust vent. Avoid 90° turns, if possible. Allow room when using elbows or making turns. Bend vent gradually to avoid kinking. Use duct tape to seal all joints. Do not use screws to secure vent.
Page 8: Using Your Dryer
SING TARTING YOUR DRYER wWARNING Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Do not dry anything that has ever had anything flammable on it (even after washing). Failure to follow these instructions can result in death, explosion, or fire. Before using your dryer, wipe the dryer drum with a damp cloth to remove dust from storing and shipping.
Page 9 TARTING YOUR DRYER (OPTIONAL STEP) On some models, the Cycle Signal selector is part of the Start button. Set the Cycle Signal selector to On if you want the dryer to sound a signal when a cycle is finished. The sig- nal is helpful when you are drying permanent press, synthetics, and...
Page 10: Loading
USING YOUR DRYER OADING Loading suggestions The chart below provides some guidelines on various types of drying loads. Load clothes loosely into the dryer. Do not pack the dryer; allow space for clothes to tumble freely. Heavy Work Clothes 3 pair pants 3 shirts 4 pair jeans 1 coverall...
Page 11 ODELS SEDX Automatic Dry The Automatic Dry cycle uses the Energy Preferred Automatic Setting ( * ). Use this high heat cycle for drying heavyweight and mediumweight: • Cotton items, such as towels, linens, bedspreads, work clothes, blue jeans, and corduroys. •...
Page 12 USING YOUR DRYER ODELS SEDS Automatic Dry The Automatic Dry cycle uses the Energy Preferred Automatic Setting ( * ). Use this cycle for drying heavyweight and medium-weight: • Cotton items, such as towels, linens, bedspreads, work clothes, blue jeans, and corduroys.
Page 13: No Heat Fluff Cycle
ODELS SEDS Towels When you have large loads of towels to dry, you may want to use the Towels feature in the Automatic Dry cycle. The Towels setting allows for more drying time and automatically shuts off the dryer when the selected dryness is reached. The Towels feature also can be used for extra heavy items such as mattress pads and quilts.
Page 14: Using The Drying Rack
USING YOUR DRYER SING THE DRYING RACK Your dryer may include a drying rack. If your model doesn’t include one, you can order a drying rack by calling 1-800-253-1301, from anywhere in the U.S.A. You will hear a recording. Follow the instructions to place an order.
Page 15: Caring For Your Dryer
ARING FOR LEANING THE LINT SCREEN Every load cleaning The lint screen is located under a lid on top of the dryer. Clean it before starting each load. A screen blocked by lint can increase drying time. To clean: Open the lid and pull the lint screen towards you.
Page 16 CARING FOR YOUR DRYER LEANING THE DRYER INTERIOR Garments which contain unstable dyes, such as denim blue jeans or brightly colored cotton items, may discolor the dryer interior. These stains are not harmful to your dryer and will not stain future loads of clothes.
Page 17 HANGING THE DRUM LIGHT The dryer light automatically turns on inside the dryer drum when you open the door. To change drum light: Unplug the dryer or disconnect the electricity leading to the dryer at the main power supply. Open the dryer door. Remove the light bulb cover from the back wall of the dryer by removing the screw...
Page 18: Troubleshooting
ROUBLESHOOTING OMMON DRYING PROBLEMS PROBLEM CAUSE • Lint screen is clogged with lint. Not drying satisfactorily • Restricted air movement. Exhaust vent or outside exhaust hood is clogged with lint. • Exhaust vent is crushed or kinked. • One fuse is blown or circuit breaker is tripped.
Page 19 OMMON DRYING PROBLEMS PROBLEM CAUSE Lint in load • Lint screen is clogged. • Improper sorting. • Load is too big or heavy. • Load is overdried. • Paper or tissue in pockets. • Pilling being mistaken for lint. Stains on •...
Page 20: Assistance Or Service
SSISTANCE OR F YOU NEED ASSISTANCE OR SERVICE Call the Whirlpool Consumer Assistance Center toll free at 1-800-253-1301. Consultants are available to assist you. When calling: Please know the purchase date, and the complete model and serial number of your appliance (see the “A Note to You”...
Page 21 NOTES...
Page 22: Warranty
Factory Specified Parts and repair labor to correct defects in materials or workmanship. Service must be provided by a Whirlpool designated service company. TM Kirkland Signature is a Trademark of Costco Wholesale Corporation 1/99 DISTRIBUTED BY: CWC, P.O. BOX 34535 SEATTLE, WA 98124-1535 1-800-774-2678 U.S.

This manual is also suitable for:

Kirkland signature seds800h Kirkland signature sgds800h Kirkland signature sedx600h Kirkland signature sgdx600h
