Tiger PLUS Installation And Operating Instructions

THE INSTALLATION AND SERVICING OF THIS APPLIANCE MUST BE SUPERVISED BY A
QUALIFIED SOLID FUEL ENGINEER. THE SUPPLIERS WILL ACCEPT NO RESPONSIBILITY
UK: The Solid Fuel Association, 7 Swanwick Court Alfreton Derbyshire DE55 7AS Tel:0845-601-4406 www.solidfuel.co.uk
THIS APPLIANCE BECOMES
AND CAN PRODUCE
A fire-guard should be used if children or the infirm are present. The
installer is required to EXACTLY follow these instructions and to
completely comply with all local, national and international standards.
This document is a guide to installing and using the Tiger Plus stove, any
national or local regulations must be complied with. Building regulations for
the UK, RoI and IoM can be found at
ASBESTOS: Tiger does not contain asbestos, but you should be careful to
avoid disturbing any asbestos when removing an old installation.
FIRE CEMENT is caustic - wash your hands thoroughly after using it.
WEIGHT Protect your spine by moving the stove only with assistance.
FUME EMISSION: Properly installed and operated this appliance will not
emit fumes into the dwelling. Occasional fumes from de-ashing and
refuelling may occur. However, persistent fume emission is potentially
dangerous and must not be tolerated. If fume emission persists, then the
following immediate action should be taken:
(a) open doors and windows to ventilate the room. (b) let the fire go out or
eject and safely dispose of fuel from the appliance. (c) check the flue or
chimney for blockage and clean if required. (d) do not attempt to re-light the fire until the case of the fume emission has been identified
and corrected. If necessary seek expert advice
HEAT: The surfaces of the appliance and the attached fluepipe will become extremely hot- a fireguard should be used if children or
the infirm are present. Flammable materials (including fuel) should not be stored near to the appliance. If the Europa Hi-Leg unit is
fitted and used as a log store, logs must not be placed higher than the central 'bridging' member.
BEFORE YOU BEGIN...
CHIMNEY Your chimney creates the draught which Tiger needs in order to work - it must:
Conform to local building regulations.
•
Be at least 5m high.
•
Terminate at least 1m above any roof ridge.
•
Have an internal cross-section not less than 0.018m² (eg 150mm dia) and not more than 0.14m² (eg 375 x 375mm)
•
Be free from even the slightest crack or source of leakage.
•
Have no bends sharper than 45 degrees.
•
Be entirely free of obstructions and swept by a qualified chimney sweep.
•
Be connected only to the one appliance.
•
Have a wall thickness of at least 100mm throughout its length, or be thoroughly insulated
•
New masonry chimneys should be fitted with ceramic liners of at least 200mm diameter.
•
Prefabricated chimneys should be fully insulated, of at least 150mm internal diameter, conform to BS4543 Part 2 and be installed
•
in accordance with the manufacturer's instructions.
INSTALLATION CLEARANCES The stove must be placed on a solid non-combustible hearth conforming to building regulations.
There must be no combustible material, including fuel, within: Rear 40cm, sides 30cm. If the Hi-Leg unit is fitted hearth temperature
will not exceed 100ºC, and light duty hearth material may be used.
LOAD BEARING Tiger is heavy - take care to ensure that the floor has adequate load-bearing capacity and consider fitting a load
distributing plate if necessary
CAST-IRON MULTI-FUEL STOVE
INSTALLATION AND OPERATING
LEAVE THIS DOCUMENT WITH THE HOUSEHOLDER !
RoI: Irish Nationwide Fireplace Organisation, 162 Capel Street, Dublin 1 Tel:01-801-5959 www.fireplace.ie
EXTREMELY
POISONOUS
www.tiger-stoves.com
TIGER PLUS
INSTRUCTIONS
WHATEVER FOR APPLIANCES NOT SO INSTALLED.
A register of qualified engineers is available from:
Conforms to EN13240
HOT
Independently tested by SGS
GASES.
Arnheim, 2007
Approved Laboratory No 0608
Efficiency
Max. Output
CO Emission
(as if at 13% O2)
Mean Flue
Temperature
Clearance to
combustibles
Smoke Emission
Gas flow
Flue Draught
1
Wood (Beech)
Fuel
77.90%
6.2kW
0.27%vol
313º C
Rear 40cm
Sides 30cm
77 mg/m³
5.4 g/sec
Min 12Pa
Mineral Fuel
(Ancit)
70.30%
6.2kW
0.13%vol
286ºC
Rear 40cm
Sides 30cm
95 mg/m³
6.3 g/sec
Min 12Pa
