CIRCULAR SAWS

C 6SF, C 7SF
C 6MF, C 7MF
LIST Nos. C 6SF: 0597
C 6MF: 0599
C 7SF: 0598
C 7MF: E501
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
MODELS
C 6SF, C 6MF
C 7SF, C 7MF
Hitachi
Power Tools
Feb. 2004
TECHNICAL DATA
AND
SERVICE MANUAL
C

Advertisement

loading

Related Manuals for Hitachi C 6SF

Summary of Contents for Hitachi C 6SF

  • Page 1: Circular Saws

    Power Tools CIRCULAR SAWS TECHNICAL DATA C 6SF, C 7SF SERVICE MANUAL C 6MF, C 7MF LIST Nos. C 6SF: 0597 C 6MF: 0599 Feb. 2004 C 7SF: 0598 C 7MF: E501 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...

  • Page 2: Circular Saw

    Hitachi Power Tools LIST NO. 0597 ELECTRIC TOOL PARTS LIST CIRCULAR SAW 2003 • • Model C 6SF (E1)
  • Page 3 PARTS C 6SF ITEM CODE NO. DESCRIPTION REMARKS USED 963-803 METAL 322-088 SPINDLE AND GEAR SET 308-361 BEARING HOLDER 305-568 SEAL LOCK FLAT HD. SCREW M5X12 322-506 PROTECTIVE COVER 317-203 RETURN SPRING 600-2VV BALL BEARING 6002VVCMPS2L 308-362 BEARING COVER 308-773 SEAL LOCK FLAT HD.
  • Page 4 PARTS C 6SF ITEM CODE NO. DESCRIPTION REMARKS USED 307-898 WING BOLT M6X18 315-253 SLEEVE 308-364 WING BOLT (A) M6X15 322-007 BASE ASS’Y 1 INCLUD. 43, 48, 49, 51 315-183 ADJUSTING SCREW (A) 12 -- 03 * ALTERNATIVE PARTS --- 3 -- -...

  • Page 5: Standard Accessories

    C 6SF STANDARD ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 302-756 GUIDE 990-666 HEX. BAR WRENCH 2.5MM 940-543 BOX WRENCH 10MM OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 954-619 CORD HANGER --- 4 --- 12 -- 03 Printed in Japan...
  • Page 6 Hitachi Power Tools LIST NO. 0599 ELECTRIC TOOL PARTS LIST CIRCULAR SAW 2003 • • Model C 6MF (E1)
  • Page 7 BALL BEARING 6000VVCMPS2L 957-754 RUBBER RING 962-782 HEX. SOCKET SET SCREW M5X6 322-004 GEAR COVER ASS’Y 1 INCLUD. 27, 41, 42 HITACHI LABEL 938-477 HEX. SOCKET SET SCREW M5X8 957-051 BRUSH HOLDER 999-043 CARBON BRUSH (1 PAIR) 935-829 BRUSH CAP...
  • Page 8 PARTS C 6MF ITEM CODE NO. DESCRIPTION REMARKS USED 307-898 WING BOLT M6X18 315-253 SLEEVE 307-937 WING BOLT (A) 322-021 BASE ASS’Y 1 INCLUD. 43, 48, 49, 51 315-183 ADJUSTING SCREW (A) 12 -- 03 * ALTERNATIVE PARTS --- 3 -- -...
  • Page 9 C 6MF STANDARD ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 302-756 GUIDE 990-666 HEX. BAR WRENCH 2.5MM 940-543 BOX WRENCH 10MM OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 954-619 CORD HANGER --- 4 --- 12 -- 03 Printed in Japan * ALTERNATIVE PARTS (031225N)
  • Page 10 Hitachi Power Tools LIST NO. 0598 ELECTRIC TOOL PARTS LIST CIRCULAR SAW 2003 • • Model C 7SF (E1)
  • Page 11 600-0VV BALL BEARING 6000VVCMPS2L 957-754 RUBBER RING 962-782 HEX. SOCKET SET SCREW M5X6 322-015 GEAR COVER ASS’Y INCLUD. 27, 41, 42 HITACHI LABEL 938-477 HEX. SOCKET SET SCREW M5X8 957-051 BRUSH HOLDER 999-043 CARBON BRUSH (1 PAIR) 935-829 BRUSH CAP...
  • Page 12 PARTS C 7SF ITEM CODE NO. DESCRIPTION REMARKS USED 307-898 WING BOLT M6X18 315-253 SLEEVE 308-364 WING BOLT (A) M6X15 322-016 BASE ASS’Y INCLUD. 43, 48, 49, 51 315-183 ADJUSTING SCREW (A) 12 -- 03 * ALTERNATIVE PARTS --- 3 -- -...
  • Page 13 C 7SF STANDARD ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 302-756 GUIDE 990-666 HEX. BAR WRENCH 2.5MM 940-543 BOX WRENCH 10MM OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 954-619 CORD HANGER --- 4 --- 12 -- 03 Printed in Japan * ALTERNATIVE PARTS (031225N)
  • Page 14 Hitachi Power Tools LIST NO. E501 ELECTRIC TOOL PARTS LIST CIRCULAR SAW 2003 • • Model C 7MF (E1)
  • Page 15 600-0VV BALL BEARING 6000VVCMPS2L 957-754 RUBBER RING 962-782 HEX. SOCKET SET SCREW M5X6 322-015 GEAR COVER ASS’Y INCLUD. 27, 41, 42 HITACHI LABEL 938-477 HEX. SOCKET SET SCREW M5X8 957-051 BRUSH HOLDER 999-043 CARBON BRUSH (1 PAIR) 935-829 BRUSH CAP...
  • Page 16 PARTS C 7MF ITEM CODE NO. DESCRIPTION REMARKS USED 307-898 WING BOLT M6X18 315-253 SLEEVE 307-937 WING BOLT (A) 322-022 BASE ASS’Y INCLUD. 43, 48, 49, 51 315-183 ADJUSTING SCREW (A) 12 -- 03 * ALTERNATIVE PARTS --- 3 -- -...
  • Page 17 C 7MF STANDARD ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 302-756 GUIDE 990-666 HEX. BAR WRENCH 2.5MM 940-543 BOX WRENCH 10MM OPTIONAL ACCESSORIES ITEM CODE NO. DESCRIPTION REMARKS USED 954-619 CORD HANGER --- 4 --- 12 -- 03 Printed in Japan * ALTERNATIVE PARTS (031225N)
