STEPS TO CHARGE BATTERY:

The port for the charger is located on the
upper body. It resembles a
simulated"FUEL CAP".
1) Slide the protective cover over to
expose the charger port (Fig 11).
Fig 11
2) Note that the plug has a "groove"
inside (Fig 12). This allows the plug to be
inserted in the proper orientation to the
wires. Plug the charger into the port.
Fig 12
Battery Charger specifications for world-wide standard:
Country
U.S./Canada
Taiwan/Japan
U.K./Hong Kong/
Singapore/Malaysia/
Africa
Europe/Germany/
Israel
Australia/
New Zealand/China
MINIMOTO MAXII BIKE
™
3) Plug in the charger into a standard 120
Volt electrical outlet.
4) When properly charging, THE Green light
flash on and off on the charger will be ON.
MAKE SURE THE ANY SWITCHES CON-
NECTING THE ELECTRICAL OUTLET ARE
SET TO THE ON POSITION.
5) Before using the MINIMOTO
BIKE for the first time, charge the battery
for at least 12 hours. Never charge the
battery for more than 30 hours.
6) When the battery is fully charged. The
Green light on the charger will come on. It
is recommended that you always recharge
the battery for a period of 8 hours.
However, 80% of the power will be charged
into the battery in 4 hours. It is possible
to use the MINIMOTO
this period but the total running time will
be reduced.
Input Output
A.C. 100-120V d.c. 36V 2000mA
60Hz
A.C. 220-240V d.c. 36V 2000mA
50Hz
A.C. 220-230V d.c. 36V 2000mA
50Hz
A.C. 240V 50Hz d.c. 36V 2000mA
TM
MAXII BIKE after
Polarity Shape
Bare
Bare
Bare
Bare
TM
MAXII
