4
8
Once setup codes have been entered for all components,
hold down the ENT key until the backlight flashes twice.
• Once registered, the display on the receiver shows the component
type instead of the default input name.
Example: if you register a VCR at the VIDEO 1 jacks, "VCR" appears
instead of "VIDEO 1 (VCR1)".
• After initial setup, any VIDEO or TV (TV1, TV2, CABLE) inputs that
have not been programmed with a setup code or Non-IR code are
deleted from the cyclic list. The PHONO input will be deleted if a
Non-IR code was not registered.
• The INPUT SELECTOR on the front panel of the receiver always
cycles through all inputs.
Note
Although each setup code is designed to work with a number of
different models, certain codes may not work with some models.
(Also, certain codes may only operate some of the functions available
on a given model.)
Getting the most from your remote control

Operating other components

This operation lets you operate the registered components.
KENWOOD audio components with system control turn on and off
automatically with the receiver via the system control connections.
POWER
VIDEO, AUDIO, TV
1
Use the VIDEO, AUDIO, or TV keys to select the compo-
nent you desire.
• Pressing the VIDEO or AUDIO key also changes the input selector
on the receiver. If you do not want to change the current input,
press the SHIFT key before step 1.
VIDEO key
1 VIDEO1 (VCR 1)
2 VIDEO2 (VCR 2)
3 VIDEO3 (DVD)
or DVD 6ch
4 Not used by this
remote control.
(<--->)
2
Press the SHIFT key and then press the POWER key
(within 3 seconds).
• Pressing the SHIFT key is only required when turning the selected
component on or off. Pressing the POWER key directy turns the
receiver on and off.
3
Press the operation keys you desire.
• See "Remote operation of other components" at the end of this
manual for a list of keys available with each component.
The remote control mode remains in the set at the component
selected in step 1 mode until you select another component
(etc.).
Note
Be sure to point the remote control at the remote sensor on the receiver
when you want to operate KENWOOD components connected by
system control cords. Otherwise, point the remote control at the
component you want to operate.
RC-R0507 (En/T)
SHIFT
RC5
AUDIO key TV key
1 TV1
1 CD (CD)
2 TV2
2 TAPE or MD
3 CABLE
(TAPE)
3 TUNER
4 PHONO
RC$
