- Page 1 INSTRUCTION BOOK Child Booster Seat Series No.: BL4300/2010 IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT Check that this child restraint will fit in your car. Product features and decoration may vary from images & illustrations.
-
Page 2: Table Of Contents
Booster Seat or the child can sit in the car’s seat with their lower leg able to hang over the seat cushion. SHOULDER HEIGHT MARKERS AND A GROWING CHILD Only the Babylove™ EzyGo Harness™ Series BL220/2010, Babylove™Travel™Harness Series SHOULDER HEIGHT MARKERS AND THE NEXT STEP BL217/2010, Safe-n-Sound™Protecta PLUS™Harness Series 220/2010 and Safe-n-Sound™Defenda™... -
Page 3: Warnings
• Use the restraint exactly as shown in the instructions. • Securely stow all heavy objects, feeding bottles, cup holders, etc that could become missiles during an accident and cause injury to any occupant. • Supervision of children is needed because they may be able to undo buckles. •... -
Page 4: Shoulder Height Markers And A Growing Child
SHOULDER HEIGHT MARKERS AND A GROWING CHILD SHOULDER HEIGHT MARKERS AND THE NEXT STEP IMPORTANT: FOLLOW THIS ADVICE. LOWER SHOULDER HEIGHT MARKER : Label A Using the in-built harness, Marker B The child’s shoulders must be in-line with this marker or above this marker. -
Page 5: Special Features
• Do not use on any vehicle seat which faces sideways or rearwards. Car Seat Belt BOOSTER SEATBELT PATH • Only use Babylove™replacement covers for this Booster seat to ensure all safety information is (Red label) provided. Padded Cover for Comfort •... -
Page 6: How To Setup
HOW TO SETUP HOW TO SETUP ADJUSTING THE SASH GUIDE The Sash Guide should be used to correctly position the sash portion of the lap-sash seat belt across the child's To Lengthen POSITION shoulder and chest. A. Unzip the trim at the back of the booster Feed the adjusting strap into the slot on the cover that seat at the top rear of the restraint, then pull Hold the strap,... - Page 7 HOW TO USE HOW TO USE WITH LAP-SASH SEAT BELT 5. Tighten the lap belt and then the sash belt. Sash belt If using an Inertia Reel Retractor seat belt, across the 1. Place the Booster Seat in the desired seating position. adjust lap portion of the seat belt firmly chest and around the child and Child Booster Seat...
-
Page 8: How To Use With A Child Harness
HOW TO USE HOW TO USE WITH A CHILD HARNESS USING THE BOOSTER SEAT WITH A CHILD HARNESS A child harness MUST be used with this Booster seat if the seating position chosen has a Lap only seat belt. A child harness can also be used in a position with a lap-sash seatbelt and is useful if the occupant does not always wear the seat belt correctly. - Page 9 HOW TO USE WITH A CHILD HARNESS HOW TO USE WITH A CHILD HARNESS A. Hold the lap and sash straps together and fold as shown. D. Feed the straps through the Gated Slide to remove any slack. This has now converted the lap-sash seat belt so it will act like a lap Slide the inner strap into the Gated Slide followed by the outer strap.
- Page 10 INSTALLING INTO VEHICLE Hook the Child Harness attachment clip (1) onto anchor fitting in the car. Ensure that none of the The Babylove Travel Harness Series straps are twisted and not passing over any sharp edges. BL217/2010 and Safe-n-Sound Defenda...
- Page 11 HOW TO USE WITH A CHILD HARNESS HOW TO USE WITH A CHILD HARNESS HARNESSING THE CHILD INTO THE BOOSTER SEAT E. Engage the car’s seat belt tongue to the buckle and adjust the seat belt to sit firmly Converted These instructions apply to fitting with a lap only seatbelt or a converted lap-sash seatbelt.
- Page 12 Converted through the harness strap loops as shown. lap-sash The Babylove EzyGo harness Series BL220/2010 and Safe-n-Sound Protecta PLUS harness Series Lower seat belt. 220/2010 child harnesses include an adjuster in the front of the harness. The harness may be used...
- Page 13 HOW TO USE WITH A CHILD HARNESS HOW TO USE WITH A CHILD HARNESS A. Lengthen the shoulder strap by pressing the C. With the child seated, place each of the harness straps Pull Adjuster adjuster button (1) and pulling the strap (2). through the guide on the top of the seat and then over each strap to shoulder.
- Page 14 HOW TO USE WITH A CHILD HARNESS HOW TO USE WITH A CHILD HARNESS F. Engage the seat belt tongue to the buckle USING LAP SASH SEATBELT Child Harness Guide and adjust the seat belt to sit firmly around (if provided) Converted Thread the converted lap-sash seat belt the child’s hips and thighs.
-
Page 15: Care & Maintenance
HOW TO USE WITH A CHILD HARNESS CARE & MAINTENANCE TO REMOVE CHILD FROM HARNESS AND SEAT MAINTENANCE Check that the foam is not broken or the cover damaged. Seek repair or replace the whole booster seat. Disengage seat belt tongue and buckle and remove Child Harness and seatbelt from child. -
Page 16: Accessories
ACCESSORIES IN CASE OF CRASH HEAD PILLOW (IF SUPPLIED) If your restraint has been involved in a severe crash, you should destroy the restraint even if no damage is obvious. Some insurance companies offer vehicle insurance which covers or partially covers the The head pillow (if fitted) is designed to provide replacement of your child restraint. - Page 17 We reserve the right to alter this product without notice in our constant endeavor for improvement. ©2007-2011 Nursery Elegance Pty. Ltd. Babylove, EzyGo, Travel Harness Trademarks and model names are the property of Nursery Elegance Pty Ltd. Safe-n-Sound, Protecta PLUS, Defenda Trademarks are the property of Britax Childcare Pty Ltd.
