Summary of Contents for Alphacom a300
-
Page 1: User Guide
® Alphacom a300 a RANGE hEAdsEtPhONE USER GUIDE Versatility & Value... -
Page 2: Table Of Contents
14.16 HANDSET MUTE BUTTON 14.17 BASE UNIT LATCHABLE MUTE 14.18 SAVE FUNCTION OpERATING pROCEDURE FOR pBX CONNECTION 15.1 pBX RECALL 15.2 pABX pAUSE FACILITY 15.3 MESSAGE WAITING OpERATION 15.4 GENERAL USE IN CASE OF DIFFICUlTY CARE OF YOUR a300 HEADSETPHONE... -
Page 3: Guarantee
CONDITIONS OF USE Your a300 Headsetphone is approved for use on business or private direct exchange lines and on compatible pBX extensions. When connected to a direct exchange line this must be a standard exclusive (not shared service) line. -
Page 4: Facilities And Features
Facilities and Features This apparatus has been approved for the use of the following facilities Simple telephone facility with headset operation Loop Disconnect or DTMF Signalling (selectable) Mixed Mode signalling 10 + 10 Direct memory locations of 24 digits capacity Memory protection switch Earth Loop and Timed Break Recall. -
Page 5: Locations Of Controls - Front View
Headsetphone - front view a300 Headsetphone - Front View... -
Page 6: Locations Of Controls - Side View
Headsetphone - side view... -
Page 7: Headset Hook Assembly (Optional)
Headset Hook Assembly (Optional) Hi Elevation Lo Elevation position the Headset Hook in the required elevation (Hi or Lo) then slide the cover on to secure in place. -
Page 8: Utilisation Of Controls
Utilisation of Controls The button functions are as follows: 0 - 9 Dialing digits. * - # Dialling codes for MF signalling Recall For use on pBX or for star services Save Used to store the last number in a memory Tone Switches from Loop Disconnect to DTMF during dialling Redial... -
Page 9: Installation
However some telephone exchanges in the U.K. still operate on the pULSE dialling system. Your a300 Headsetphone series telephone allows you to operate on either system and the DIAL MODE SELECTOR SWITCH should be set to the dialling mode required by your exchange. -
Page 10: The Recall Mode Selector Switch
Your a300 Headsetphone provides tone signalling when the Dial Mode selector switch is set to the (TONE) position and the Recall Mode selector switch is in the TBR position. If your system requires pULSE dialling, you can change to TONE dialling once the call has been established by pressing the TONE button.This enables you to access special... -
Page 11: Connecting To Telephone Socket
Set the switch to the Hl, MED or LO position to adjust the pitch of the ringer. Wall Mounting You may wish to mount the a300 Headsetphone on a wall. To do this: Slide the plastic, “wall mount” upwards to remove, turn it around and replace it in the slot. -
Page 12: Operating Procedures
Operating Procedures OPERATING PROCEDURES Three modes of operation are provided; normal handset mode where the handset Three modes of operation are provided; normal handset mode where the handset is is lifted and replaced in the normal manner, headset mode where conversation is lifted and replaced in the normal manner, headset mode where conversation is conducted through the headset and handsfree mode where the caller or called party is conducted through the headset and handsfree mode where the caller or called party is... -
Page 13: Handsfree Operation
TRANSFERRING CALL FROM HANDSFREE TO HEADSET To transfer a call from Handsfree to Headset, press the Headset button, the LED on the Headset button will illuminate. When in headset mode, pressing the speaker button once will transger the call to handsfree mode. TRANSFERRING CALL FROM HANDSET TO HEADSET To transfer a call from Handset to Headset, press the Headset button, the LED on the Headset button will illuminate. -
Page 14: Auto Redial Feature
14.5 AUTO REDIAl FEATURE If the telephone number you have called is engaged and you want to keep on dialling until the call is answered. 1. press Speaker button to get the line, the LED indicator will illuminate. 2. press the Auto Redial button, the dialled telephone number will be automatically dialled out.The dialled number will blink on the display and the line status can be monitor through the Speaker during 30 seconds waiting period. -
Page 15: Storing Numbers Whilst On A Call
14.8 PROGRAMMING CODES FOR CENTREX AND NETwORK SERvICES If you are using the a300 Headsetphone on an exchange line (not a pABX) and subscribe to network services provided by BT, or by another network provider, individual services may be programmed into the memory keys using the procedure outlined in 12.7., thus allowing you to use... -
Page 16: 12.12 Mixed Deal Mode Operation
With some PABX’s, it is necessary after dialling an outside line access digit (often 9) to wait for new dial tone before dialling the outside number. If the PAUSE button is press after the access digit has been dialled, the number may be dialled immediately without 14.12 MIXED DEAl MODE OPERATION waiting for new dial tone as the telephone will introduce the required pause in the... -
Page 17: Auto Call Timer
14.16 HANDSET MUTE BUTTON When using the a300 Headsetphone in handset mode (not other modes), whilst the handset mute button is depressed the other party will not hear the conversation. If specified the a300 Headsetphone can be supplied with this button as ‘push to talk’, and in this instance the telephone will be clearly marked as such. -
Page 18: Operating Procedure For Pbx Connection
OPERATING PROCEDURE FOR PBX CONNECTION The a300 Headsetphone is suitable for connection to a pABX which returns secondary proceed indication. 15.1 PBX RECAll When connected to a pBX, the telephone will send a Recall Signal to the exchange when the RECALL button is pressed.This a300 Headsetphone provides either TIMED LINE BREAK RECALL or EARTH RECALL. -
Page 19: In Case Of Difficulty
NOTE: If BT engineers are called out unnecessarily and the line is not at fault, a charge will be made. If difficulties are still experienced, please contact your supplier. Care of your a300 Headsetphone You have invested in a quality product and simple care and cleaning will keep it in good condition.The plastic parts and cards should be wiped with a cloth dampened with clean... - Page 20 Distributed by: Alphacom ® Incom House, Waterside Trafford park Manchester, M17 1WD Tel: 0161 935 1000 Fax: 0161 935 1015 www.alphacomtelecoms.co.uk email: sales@alphacomtelecoms.co.uk All Alphacom telephones are manufactured to comply with CE standards...
