Series GR Infrared Heater
Installation, Operation and Service Instructions
WARNING: If the information in these instructions are not followed
exactly, a fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Don't touch any electrical switch; do not use any telephone in your building.
Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Note: Not For Installation in Mobile Homes or Recreational Vehicle.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for the future reference.
563 Barton Street, Stoney Creek, Ontario, L8E 5S1
www.superiorradiant.com
02/14 LT094
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Superior Series GR
Summary of Contents for Superior Series GR
- Page 1 Series GR Infrared Heater Installation, Operation and Service Instructions WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 CAUTION: FIRE OR EXPLOSION HAZARD Maintain clearance to combustible constructions as further specified in this manual. Failure to do so could result in a serious fire hazard. Heaters should not be located in hazardous atmospheres containing flammable vapors or combustible dusts. Signs should be provided in storage areas specifying maximum safe stacking height.
-
Page 3: Table Of Contents
Table of Content Introduction ............................ 4 Installation Codes............................ 4 General Installation and Gas Codes ............................ 4 Aircraft Hangar Installation .............................. 4 Public Garage Installation .............................. 4 Parking Structures ................................ 4 Electrical .................................... 5 Venting .................................... 5 High Altitude .................................. 5 Safety Features .................................. 5 General Specifications ........................... 6 Gas Supply .............................. 6 Inlet Pressure .................................. 6 Manifold Pressure ................................. 6 Inlet Connection ................................... 6 Electric Supply .............................. 6 Heater Specifications ............................. 6 ... -
Page 4: Introduction
Introduction Superior Radiant Products is a company in the infrared heating industry founded on the principles of product quality and customer commitment. Quality commitments are evidenced by superior design, a regard for design detail and an upgrade of materials wherever justifiable. -
Page 5: Electrical
If this system fails to operate DO NOT ATTEMPT ADJUSTMENTS. Disconnect power to the appliance and contact a qualified service person. Series GR Page 5 February 10, 2014... -
Page 6: General Specifications
A vertical vent kit is available as an alternate venting method. This Kit Part # RS022 is available through SRP distributors and contains the appropriate adapters to allow the connection of B-vent material. See roof-venting page 13. 113.0 15.1 Figure 1: Overall Dimensional Information Series GR Page 6 February 10, 2014... -
Page 7: Clearance To Combustibles
Signs should be posted identifying any possible violation of the clearance distances from the heater in vehicle areas. Also maximum allowable stacking height in storage areas should be identified with signs or appropriate markings. Figure 2 shows minimum clearance to combustible materials. Series GR Page 7 February 10, 2014... -
Page 8: Clearance To Combustibles
Table 1: Clearance to Combustible Table 45° Figure 2: Clearance to Combustible Diagram CAUTION In all cases, the minimum hanging height from the floor shall be: In Canada: 7' feet In USA: 8' feet Series GR Page 8 February 10, 2014... -
Page 9: Installation Detail
SRP recommends and make available “quick links” for connecting chain. If any open ended “S” hooks and turnbuckles are used, the open ends must be closed to avoid unhooking chain with inadvertent contact. Series GR Page 9 February 10, 2014... -
Page 10: Outdoor Installation
The side dimension gives us a maximum Top dimension of (36/3)" = 12" The back dimension gives us a maximum Top dimension of (48/3)" = 16" The new Top dimension is 12", the lesser of the two. Series GR Page 10 February 10, 2014... - Page 11 NOTE: These dimensions are only for satisfying outdoor heater positioning. Clearance to combustible must also be satisfied. Series GR Page 11 February 10, 2014...
- Page 12 Back Note: Front Install 45° Close all open ended "S" hooks, chain links, Extension and turnbuckles or any open connection. Covers Side As Shown Figure 8: Cover Installation Sequence Steps 3 to 5 Series GR Page 12 February 10, 2014...
- Page 13 Installation Detail Note: Close all open ended "S" hooks, chain links, and turnbuckles or any open connection. Extension Cover Figure 9: Extension Cover for 45° Outdoor Installations Series GR Page 13 February 10, 2014...
-
Page 14: Venting / Combustion Air Ducting
2" inch flue extend just beyond the eave to prevent the possibility of frost. (Adhere to any code requirements for clearances to opening in the building). An optional “Horizontal Elbow Vent Terminal” kit for horizontal venting is also available, refer to Figure 12 and Figure 13 Series GR Page 14 February 10, 2014... - Page 15 2" Flue Pipe Should be Optional Horizontal Concentric with the 4" 2" Flue Pipe "Elbow Vent Terminal" Combustion Air Inlet Duct (Flue Vent) Seal Joints With RTV Silicone Figure 12: Venting / Combustion Air Ducting Series GR Page 15 February 10, 2014...
-
Page 16: Optional" Horizontal Elbow Vent Terminal
Wall Terminal P/N RS006 Ø2" Flue Pipe "Optional" Horizontal Elbow Vent Terminal Seal Joint with RTV Silicone Secure Vent Elbow using sheet metal screws Figure 13: Optional Horizontal Elbow Vent Terminal / Installation. Series GR Page 16 February 10, 2014... -
Page 17: Roof Venting
(included in vertical vent kit) Figure 14: Roof Venting / Combustion Air Ducting The B-vent adapter must be secured with screws and sealed with high temperature silicone sealant. Install B-vent as per local code requirements. Series GR Page 17 February 10, 2014... -
Page 18: Gas Piping
3" (7.62 cm) Max. (As Shown Below) Displacement Alternate Positions Okay 12" (30 cm) INCORRECT POSITIONS Heater Movement Heater Movement WRONG WRONG Heater Movement Heater WRONG WRONG Movement Figure 15: Flexible Gas Connection Series GR Page 18 February 10, 2014... -
Page 19: Electrical Wiring
120 Vac circuit. This Pink option only works if the heater is wired with the thermostat on the IGNITER BURNER 24 Vac circuit above. Figure 16: Internal Wiring Series GR Page 19 February 10, 2014... -
Page 20: Operation / Maintenance
Be sure vent terminal and fresh air inlet are free from obstructions. If either pipe is restricted, the safety air switch will not operate properly, and the heater could fail to operate. Series GR Page 20 February 10, 2014... -
Page 21: Trouble Shooting
Burner Does Not Stay Lit Check ground wire continuity. Check insulation on the igniter leads. Measure flame signal current; it should be above 0.8 micro amps DC. Replace module if necessary. Series GR Page 21 February 10, 2014... -
Page 22: Troubleshooting Chart
Trouble Shooting Troubleshooting Chart Series GR Page 22 February 10, 2014... -
Page 23: Replacement Parts
30,000 BTU Pressure Switch CE003 CE160 Flame Sensor RE019 Ignitor CG001 Gas Valve - Natural - Honeywell Gas Valve - Propane - Honeywell CG009 Not Shown CE008 Transformer CE015 CE006 Ignition Module Not Shown Ignition Wire Series GR Page 23 February 10, 2014... -
Page 24: Warranty
Warranty SERIES GR INFRARED HEATERS WARRANTY The Manufacturer warrants to the original owner that the product will be free of defects in material and workmanship. This warranty is limited to 36 months from the date of installation for all components.
