Buckeye Smart Cart Instruction Manual

INTRODUCTION
The Buckeye "Smart Cart" is the perfect dispensing system for cleaning large areas and where portability and mobility
are required. The "Smart Cart" system is an economical system designed for controlling cleaning costs. The "Smart
Cart" is ideal for foaming down large areas in a short amount of time. Chemicals are mixed accurately and
consistently using a dual pick-up in-line venturi valve with general and heavy cleaning modes. The "Smart Cart" is
set-up ready to use with the product Terminator. Cart comes with side mounting clips for easy and portable storage of
squeegee or scrubbing brush. Flow-Thru Brush Kit available separately.
PREPARATION
(1) Remove the "Smart Cart" from the shipping carton.
(2) Lift off top of product holding box and open the door.
(3) Attach the Action cap to a Terminator Action Pac.
(4) Invert the Terminator Action Pac so the product cap is on the bottom and slide into the Stainless Steel container
box. Make sure that the chemical pick-up line is not kinked or crimped. Close door and replace the cover.
(5) Connect to a water supply using the 10 ft water hose attached to the unit.
Water pressure should be 30 to 80 PSI. Water temperature should not exceed 140 degrees (F).
(6) If using a product other than Terminator, remove the (2) water valve t-handles and the cover of the dispenser.
Locate the (2) metering tips inserted into the barb fittings located on each side of the general and heavy cleaning
selector. Remove the chemical pick-up lines and replace the metering tips with those for the selected product as
noted in the metering tip chart below. Replace the chemical pick-up lines and secure with zip-ties. Replace
dispenser cover.
Product
Gel Scrub
Liberate
Convoy
Terminator

IMPORTANT NOTES

•
ONLY USE A HOSE AND SPRAY NOZZLE SUPPLIED BY BUCKEYE.
•
DO NOT ADJUST THE KNOB ON THE SPRAY NOZZLE FROM THE FULL SPRAY POSITION.
•
DO NOT OPERATE MORE THAN ONE PRODUCT VALVE AT A TIME, AS PRODUCT DILUTION RATES WILL
NOT BE ACCURATE.
•
UNIT SUPPLIED WITHOUT A BACKFLOW PREVENTION DEVICE. TO PREVENT POSSIBLE CHEMICAL
BACKUP INTO THE WATER SUPPLY, COMPLY WITH ALL LOCAL PLUMBING CODES AND INSTALL AN
APPROPRIATE BACKFLOW PREVENTION DEVICE.
CAUTION: Wear protective clothing and eyewear when dispensing chemicals or
other materials. Observe safety handling instructions (MSDS) for chemicals.
CAUTION: When installing any equipment, ensure that all national and local
safety, electrical, and plumbing codes are met.
0900462 Rev: A (03/05)
General Cleaning (tip color)
N/A
N/A
Peach
Red
S M A R T C A R T
I N S T R U C T I O N M A N U A L
Heavy Cleaning (tip color)
NO Tip
Black
Brown
Pink
Page 1 of 4
