    Sound Bar Operating Instructions Mode d’emploi HT-ST5...
  • Page 2 Record the serial numbers in the space provided below. Refer to them uninsulated “dangerous voltage” within the product’s enclosure whenever you call upon your Sony dealer regarding this product. that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 12) Use only with the cart, stand, tripod, bracket, or table specified by the Properly shielded and grounded cables and connectors must be used for manufacturer, or sold with the apparatus. When a cart is used, use connection to host computers and/or peripherals in order to meet FCC caution when moving the cart/apparatus combination to avoid injury emission limits.
  • Page 4 For the customers in Canada Properly shielded and grounded cables and connectors must be used for connection to host computers and/or peripherals. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 5: Table Of Contents

    Table of contents Useful functions Modifying the angle of the Bar Speaker ....... 6 Mounting the Bar Speaker on a wall ........7 Enabling the IR repeater function (when you cannot control the TV) ........8 Enabling the Secure Link function ........9 Using the Control for HDMI function ........11 Using “BRAVIA”...

  • Page 6: Useful Functions

    Remove the screws fixing the stands from the bottom of the Bar Speaker. Useful functions The stands are attached to both sides of the bottom of the Bar Speaker. To detach the stands, remove the stand screws with a screwdriver. Screw Modifying the angle of the Bar Speaker You can modify the angle of the Bar Speaker by detaching the stands...

  • Page 7: Mounting The Bar Speaker On A Wall

    11/32 in) contractors and pay special attention to safety during the installation.  Sony shall not be held responsible for accidents or damage caused by Hang the Bar Speaker on the screws. improper installation, insufficient wall strength, improper screw installation or natural calamity, etc.

  • Page 8: Enabling The Ir Repeater Function (When You Cannot Control The Tv)

    Press the MENU button on the remote control of the system. Enabling the IR repeater function (when you cannot control the TV) When the Bar Speaker obstructs the remote control sensor of the TV, the TV remote control may not work. In that case, enable the IR repeater function of the system.

  • Page 9: Enabling The Secure Link Function

    Press the MENU button on the remote control. Enabling the Secure Link function Select “WS” with the   (select) buttons then press the ENTER button. You can specify the wireless connection to be used to link the Bar Select “SEC. ON” with the   (select) buttons then press the Speaker to the subwoofer using the Secure Link function.
  • Page 10 Cancelling the Secure Link function Press the MENU button on the remote control. Select “WS” with the   (select) buttons then press the ENTER button. Select “SEC.OFF” with the   (select) buttons then press the ENTER button. When “OK?” appears, press the ENTER button. “FINISH”...

  • Page 11: Using The Control For Hdmi Function

    One-Touch Play Using the Control for HDMI function When you activate the equipment (Blu-ray Disc™ player, By using the Control for HDMI function, and connecting equipment “PlayStation 4,” etc.) connected to the system with a High Speed ® that is compatible with the Control for HDMI function via a High HDMI cable, the connected TV is turned on automatically and the Speed HDMI cable, operation is simplified with the features below.

  • Page 12: Using "Bravia" Sync Features

     Use an HDMI-authorized cable. Use a Sony High Speed HDMI cable with the Cable Type Logo. We do not recommend using an HDMI-DVI conversion cable.  Check the setup of the connected equipment if an image is poor or ...

  • Page 13: Controlling The System Using A Smartphone Or Tablet Device (Songpal)

    Speaker. The lamp (blue) flashes quickly during BLUETOOTH pairing.  (on/standby) PAIRING Select “SONY:HT-ST5” from the BLUETOOTH device list of the Android device. When the connection has been established, the lamp (blue) of the Bar Speaker lights. Operate the system with the display of the connected Android device.
  • Page 14 When the connection has been established, the lamp (blue) of Set the iPhone/iPod touch to pairing mode and select the Bar Speaker lights. “SONY:HT-ST5” from the BLUETOOTH device list on the iPhone/iPod touch. When the connection has been established, the lamp (blue) of the Bar Speaker lights.

  • Page 15: Adjusting The Settings

    Adjusting the settings You can set the following items with the MENU button on the remote control. Your settings are retained even if you disconnect the AC power cord (mains lead). 1 Press the MENU button on the remote control to display the setting menu on the display of the Bar Speaker. 2 Select the desired setting with the following operation: ...
  • Page 16 Menu Function Default HDMI CTRL To switch the Control for HDMI function on or off. (ON/OFF) (Control for HDMI) Refer to “Using the Control for HDMI function” (page 11) for details. P. THRU To set the power saving mode of the pass-through function for (Pass through) HDMI signals.
  • Page 17 Menu Function Default SYSTEM A. STBY To switch the AUTO POWER OFF function on or off. (ON/OFF) The (Auto standby) system turns off automatically when no operation has been made within a certain period (about 20 minutes) and the system is not receiving an input signal.

  • Page 18: Miscellaneous

    If you have any question or problem concerning your system, please On heat buildup consult your nearest Sony dealer. Although the system heats up during operation, this is not a malfunction. If you continuously use this system at high volume, the system temperature at the rear and bottom rises considerably.
  • Page 19 The BLUETOOTH® word mark and logos are registered trademarks owned device or its compliance with safety and regulatory standards. Please by Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is note that the use of this accessory with iPod or iPhone may affect under license.

  • Page 20: Bluetooth Wireless Technology

    BLUETOOTH devices should be used within approximately 10 meters (33 feet) (unobstructed distance) of each other. The effective  Sony shall not be held liable in any way for damages or other loss communication range may become shorter under the following resulting from information leaks during communication using conditions;...

  • Page 21: Troubleshooting

    “4” (page 15). repairs. Should any problem persist, consult your nearest Sony dealer. No sound or only a very low-level sound of the equipment Be sure to bring both your Bar Speaker and subwoofer, even if it connected to the Bar Speaker is heard from the Bar Speaker.
  • Page 22  The on/standby lamp of the Bar Speaker flashes quickly in green. oven. If a device that generates electromagnetic radiation is  Consult your nearest Sony dealer. nearby, move the device away from this system.  The on/standby lamp of the Bar Speaker flashes in red.
  • Page 23  If you connect the audio output of video equipment with the Sound skips or has noise. system, using a cable other than an HDMI cable, no sound may be  If there is a device nearby that generates electromagnetic waves output because of “BRAVIA”...

  • Page 24: Parts And Controls

    Front/Top Parts and controls   (on/standby) button  INPUT button Bar Speaker  PAIRING button  VOL (volume) +/– buttons  Remote control sensor  Lamp  Lit (white): Power is on and the display is “Off.”  Flashes quickly (blue): During BLUETOOTH pairing. ...
  • Page 25  On/standby lamp Subwoofer Lit (red): Power is off.  Lit (green): Power is on.  Lit (yellow): SECURE LINK connection is established.    (on/standby) button  SECURE LINK button  AC power cord (mains lead) continued...
  • Page 26   (on/standby) button Remote control  INPUT button  MUTING button  VOL (volume) +/– buttons  SOUND FIELD button*  VOICE button*  DISPLAY button The display brightness can be switched. Bright  Dark  Off  When the display brightness is set to “Off,” the display is turned off after the display shows operation status for several seconds.

  • Page 27: Specifications

    Maximum communication range Line of sight approx. 10 m (33 ft) Specifications Maximum number of devices to be registered 9 devices Frequency band Bar Speaker (SA-ST5) 2.4 GHz band (2.4000 GHz - 2.4835 GHz) Modulation method FHSS (Freq Hopping Spread Spectrum) Amplifier section Compatible BLUETOOTH profiles U.S.
  • Page 28 General Wireless transmitter/receiver section Power requirements 120 V AC, 60 Hz Communication system Power consumption Wireless Sound Specification version 3.0 On: 55 W Standby mode: 0.5 W or less Frequency band BLUETOOTH Standby mode: 0.5 W or less 5.2 GHz (5.180 GHz - 5.240 GHz) 5.8 GHz (5.736 GHz - 5.814 GHz) Dimensions (approx.) (w/h/d) 1,030 mm ×...
  • Page 29 Video formats supported by the system Input/Output (HDMI Repeater block) Over-Under Format Frame Side-by- (Top-and- packing Side (Half) Bottom)     4096 × 2160p @ 59.94/60 Hz     4096 × 2160p @ 50 Hz  ...
  • Page 30 ©2014 Sony Corporation Printed in Malaysia 4-538-291-11(1)
