If Switch (J4) Pin Connections; Redundant Loop (J7) Pin Connections; Table 2-3. If Switch (J4) Pin Connections; Table 2-4. Redundant Loop (J7) Pin Connections - Comtech EF Data MBT-4000B Installation And Operation Manual

Multi-Band Transceiver System
Installation
2.2.2 IF S
WITCH
2.2.3 R
EDUNDANT
(J4) P C
IN ONNECTIONS

Table 2-3. IF Switch (J4) Pin Connections

Pin
A POS 1 IF
B GND
C POS 2 IF
D POS 1 IND IF
E GND
F POS 2 IND IF
Mating Connectors:
Cannon MS3116J10-6P
CEFD CN/MS3116J10-6P
L (J7) P C
OOP IN

Table 2-4. Redundant Loop (J7) Pin Connections

Pin Redundant Loop (J7)
A SW POS 2 DRIVE OUT
B GND
C SW POS 2 DRIVE OUT
D RF SW IND OUT
E IF SW IND OUT
F SW POS 1 DRIVE IN
G SW POS 2 DRIVE IN
H RF SW IND IN
J IF SW IND IN
K MBT A IND
L MBT B IND
M NC
N BXC 1 FLT OUT
P BXC 2 FLT OUT
R BXC 1 FLT IN
S BXC 2 FLT IN
T NC
U TX
V RX
Mating Connectors:
CEFD CA/WR11224 Redundant Loop Cable
IF Switch (J4)
ONNECTIONS
