MULTIPLE COMPACT DISC PLAYER
CD-224M/DPF-J5010
INSTRUCTION MANUAL
KENWOOD CORPORATION
This unit is designed for home use only. If the unit is
used in a location other than at home, such as in a
shop (for commercial use), in a car or in a ship, etc.,
and is damaged, a service fee may be charged even
during the warranty period.
This instruction manual is used for two models.
Model availability and features (functions) may differ
depending on the country and sales area.
COMPACT
DIGITAL AUDIO
B60-3510-08 00 (K, P, Y, T) AP

Advertisement

Table of Contents
loading

Related Manuals for Kenwood DPF-J5010

Summary of Contents for Kenwood DPF-J5010

  • Page 1 MULTIPLE COMPACT DISC PLAYER CD-224M/DPF-J5010 INSTRUCTION MANUAL KENWOOD CORPORATION This unit is designed for home use only. If the unit is used in a location other than at home, such as in a shop (for commercial use), in a car or in a ship, etc., and is damaged, a service fee may be charged even during the warranty period.

  • Page 2: Introduction

    Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit. Introduction CD-224M/DPF-J5010 (En) AC110– AC220– 120V...

  • Page 3: Table Of Contents

    ...16 (PGM mode) Important items ... 30 In case of difficulty ... 31 Specifications ... 32 Introduction CD-224M/DPF-J5010 (En) ¢ Discs are filed by 26 music genres. Only favorite tracks can be registered from 200 ¶ discs and played..18 (REPEAT mode) ...
  • Page 4 Introduction CD-224M/DPF-J5010 (En) Unpacking Unpack the unit carefully and make sure that all accessories are put aside so they will not be lost. Examine the unit for any possibility of shipping damage. If your unit is damaged or fails to operate, notify your dealer immediately. If your unit was shipped to you directly, notify the shipping company without delay.

  • Page 5: Disc Handling Precautions

    Storage When a disc is not to be played for a long period of time, remove it from the CD player and store it in its case. Disc Type CD (ordinary Compact Disc)

  • Page 6: System Connections

    SL16 XS 8 SL 16/XS8 switch SYSTEM CONTROL Digital amplifier or receiver, etc. System connections CD-224M/DPF-J5010 (En) Malfunction of microcomputer If operation is not possible or erroneous display appears even though all connections have been made properly, reset the microcomputer refer- ⁄...

  • Page 7: Connection To Digital Amplifier Or Md

    2. Do not connect system control cords to any components other than those specified by KENWOOD. It may cause a malfunction and damage your equipment. 3. Be sure the system control plugs are inserted all the way in to the system control terminals.

  • Page 8: Controls And Indicators

    9 Play/Pause key (6) 0 Remote sensor ! Stop key (7) @ Skip keys (4 ¢) Press to skip to the beginning of another track. Characters are selected at the time of title registration. CD-224M/DPF-J5010 (En) • • • • DISC SKIP DISPLAY...

  • Page 9: Operation Of Remote Control Unit

    RANDOM key DISPLAY key 2 Insert batteries. ÷ Insert two AA-size (R6) batteries as indicated by the polarity making. CD-224M/DPF-J5010 (En) 6 Keys related to program and file registration MODE key Used for music type file and title name registration and playback.

  • Page 10: Preparation

    ÷ Do not insert more than one disc in a slot. CD-224M/DPF-J5010 (En) : Keys and controls used in the operations described on this page. The slot No. is displayed when the DISC SKIP knob is turned.

  • Page 11: In Regard To All Data Read Mode

    CD player. ÷ In the case of a non-CD-TEXT disc, the “D001:NO CD TEXT” display will appear for approx. 3 seconds. To quit ALL DATA READ mode Press the 7 key. Preparation CD-224M/DPF-J5010 (En) The display flashes.

  • Page 12: Normal Play (Track Mode)

    “Registration of Title Name” Display when disc No. 123 is selected Lights up. ÷ In the case of a CD-TEXT disc, the track's title is scrolled on the display. To stop playback Normal play (TRACK mode) CD-224M/DPF-J5010 (En)

  • Page 13: Direct Disc Selection

    As this unit requires input of large numeric values, it adopts a different input method from other KENWOOD products. How- ever, the method used with other KENWOOD products can also be used to input numeric values in this unit. ' , : ? !

  • Page 14: Playback From Desired Track

    CD-TEXT, track numbers can be selected while looking at the track titles. Searching ¢ To skip forward ÷ Playback starts from the position where the key is released. Normal play (TRACK mode) CD-224M/DPF-J5010 (En) ¡ Backward search Forward search CURSOR...

  • Page 15: Displays

    3 seconds. To end ALL INFORMATION during display Jump Press the MODE key. CD-224M/DPF-J5010 (En) Track title display (only CD-TEXT) DISC NO., TRACK NO. display Elapsed time of track being played Remaining time of track being played Elapsed time of entire disc (T lights up.)

  • Page 16: Programming Tracks In Desired Order (Pgm Mode)

    32 tracks) from up to 200 discs and program them in the desired order. Preparation ÷ Load discs into the carousel. ÷ Set the CD player to stop mode. Press so that the PGM indicator lights. CHARACTER/ P.MODE Select the disc.

  • Page 17: To Check The Programmed Tracks

    To check the programmed tracks SPACE/ CHECK To add a track to the program 1 Set the CD player to stop mode. 2 Perform steps 2 and 3 of “Program- ming tracks in desired order”. To change a track in the program 1 Set the CD player to stop mode.

  • Page 18: Repeated Playback (Repeat Mode)

    ON status can be set REPEAT to OFF (or vice versa). To cancel repeated playback Press the REPEAT key twice. (REPEAT ON § • Programming tracks in desired order (PGM mode) CD-224M/DPF-J5010 (En) OFF) OFF)

  • Page 19: Playback In A Random Order (Random Mode)

    To cancel random playback ÷ Press the 7 key to stop playback. ÷ Normal playback will be performed when RANDOM OFF is selected. § Programming tracks in desired order (PGM mode) CD-224M/DPF-J5010 (En) < < > < > < >...

  • Page 20: Registration Of Title Name

    It is convenient to register titles while discs are being inserted. Preparation ÷ Load discs into the carousel. ÷ Set the CD player to stop mode. ÷ Check that the unit is in the normal play TRACK mode. Assigning Title Names Switch to title name input mode.

  • Page 21: To Change The Character Type

    ÷ To register the disc names of another disc, repeat the entire procedure from step 2 for it. To quit title name mode Press the MODE key. P.MODE Registration of Title Name CD-224M/DPF-J5010 (En) = > Flashing cursor Each press switches the modes as follows: When capital letters have been selected : A B C A ...

  • Page 22: To Change Or Delete A Title Name

    DELETE/ CLEAR ÷ When a title name is to be deleted, delete all characters one by one. Registration of Title Name CD-224M/DPF-J5010 (En) : Keys and controls used in the operations described on this page. = > = > Flashing cursor...

  • Page 23: To Switch Between Insert And Overwrite Mode

    To quit title name mode Press the MODE key. Each press switches the modes as follows: 1 Insert mode : To insert characters before the cursor 2 Overwrite mode : To replace characters Insert mode Overwrite mode CD-224M/DPF-J5010 (En) = > = >...

  • Page 24: Listening To Music By Genre (Music Type Mode)

    Preparation ÷ Load discs into the carousel. ÷ Close the door panel. ÷ Set the CD player to stop mode. ÷ Check that the unit is in the normal play TRACK mode. Registration of music type files Activate the music type mode.

  • Page 25: To Delete The Registered Music Type

    ÷ To register another music type file, repeat the procedure from step 2. To quit MUSIC TYPE mode Press the MODE key. § CLEAR Listening to music by genre (MUSIC TYPE mode) CD-224M/DPF-J5010 (En) Alternative Rock Children’s Music Contemporary Christian Country Folk...

  • Page 26: Playing The Music Type File

    ÷ Register music type files. ÷ Check that the unit is in the normal play TRACK mode. ÷ Set the CD player to stop mode. Playing the music type file Activate the music type mode. 1 Press the MODE key.

  • Page 27: Listening To Your Favorite Titles (Best Selection Mode)

    : Keys and controls used in the operations described on this page. ÷ Only the track being played can be registered. ÷ Up to 32 tracks can be registered. “FULL” is displayed when no more disc is acceptable. CD-224M/DPF-J5010 (En)

  • Page 28: Playing The Best Selection File

    ÷ Load discs into the carousel. ÷ Register tracks in the best selection file. ÷ Check that the unit is in the normal play TRACK mode. ÷ Set the CD player to stop mode. Playing the best selection file BEST SELECTION To delete the registered best selection This is done during best selection mode.

  • Page 29: Timer Operation

    DISC SKIP keys. Next disc ÷ Read the instruction manual of the timer carefully. ÷ When the set time comes, playback will start automatically. Timer operation CD-224M/DPF-J5010 (En) Audio timer 12:00 To AC outlet Amplifier or receiver...

  • Page 30: Important Items

    1000 hours of use, although this period may vary depending on the installation condition (temperature, humidity, dust, smoke, etc.) of the unit. The unit has inspected, please consult your dealer or a KENWOOD service center in your area. Note related to transportation and movement...

  • Page 31: In Case Of Difficulty

    ÷ The disc is very scratched. ÷ MUSIC TYPE mode is selected. ÷ The TIMER PLAY switch is set to ON. CD-224M/DPF-J5010 (En) Remedy ÷ Replace with new batteries. ÷ Operate the remote control unit within the controllable range.

  • Page 32: Specifications

    Weight (Net) ... 7.4 kg (16.3 lb) 1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. 2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
