SECO-LARM E-931CS22RRCQ Installation Manual

ENFORCER
Retro-Reflective Photoelectric
Sensor Entry Alert System
E-931CS22RRCQ
Range: 22ft. (7m)
Features:
• • Retro-reflective photoelectric sensor.
• • • • Range: Up to 22 feet (7m).
• • Perfect for monitoring an entrance, or for counting
foot traffic with optional counter.
• • Will make "ding-dong" sound or siren sound when
the beam is interrupted.
• • Speaker volume can be adjusted or turned off.
• • When in siren mode, sounding time is adjustable
from 3 to 30 seconds.
• • 9VDC adapter included.
Caution:
• This sensor was not designed to prevent bodily injury or loss of life.
• Use of this sensor in certain security applications may be regulated by local laws or codes.
SECO-LARM is not responsible for compliance with such laws or codes.
Included:
E-931CS22SQ
E-931ACC-R1Q
Transmitter/Receiver
Reflector
Note: Model numbers that ends with "Q" represents RoHS compliant products.
Sensor

INSTALLATION MANUAL

Adapter
®
• All components plug into each other.
No hard wiring required.
• Optional counter available (E-931ACC-CQ).
• • Optional second speaker available (E-931ACC-SQ).
• Includes the following:
— Retro-reflective photoelectric sensor.
— Reflector.
— Speaker/electronic chime.
— 9VDC adapter.
E-931ACC-SQ
Speaker/Electronic Chime
E-931ACC-BLS4Q
E-931ACC-BLR1Q
