Contents Safety precautions WARNING CAUTION NOTE Notes About Cassette tape Notes on playing MP3/WMA About CDs General features Power Selecting the Source Volume Attenuator Audio Control Subwoofer Output TEL Mute SRS WOW Select SRS WOW Control Equalizer Control Adjustment of Equalizer type at EASY Adjustment of Equalizer type at PRO Memory preset of adjustment of Equalizer type Movie Select...
• If the unit starts to emit smoke or strange smells, turn off the power immediately and consult your Kenwood dealer. • Make sure not to get your fingers caught between the faceplate and the unit. • Be careful not to drop the unit or subject it to strong shock.
KENWOOD disc changers/ CD players released in 1998 or later can be connected to this unit. Refer to the catalog or consult your Kenwood dealer for connectable models of disc changers/ CD players. Note that any KENWOOD disc changers/ CD players released in 1997 or earlier and disc changers made by other makers cannot be connected to this unit.
Notes Cleaning the Unit If the faceplate of this unit is stained, wipe it with a dry soft cloth such as a silicon cloth. If the faceplate is stained badly, wipe the stain off with a cloth moistened with neutral cleaner, then wipe neutral detergent off.
Notes on playing MP3/WMA (DPX-MP4070/DPX-MP4070B) Note, however, that the MP3/WMA recording media and formats acceptable are limited. When writing MP3/WMA, pay attention to the following restrictions. Acceptable media The MP3/WMA recording media acceptable to this unit are CD-ROM, CD-R, and CD-RW. When using CD-RW, do full format not quick format to prevent malfunction.
Page 7
MP3/WMA playing order When selected for play, Folder Search, File Search, or for Folder Select, files and folders are accessed in the order in which they were written by the CD writer. Because of this, the order in which they are expected to be played may not match the order in which they are actually played.
About CDs Handling CDs • Don’t touch the recording surface of the CD. • CD-R and CD-RW are easier to damage than a normal music CD. Use a CD-R or a CD-RW after reading the caution items on the package etc. •...
General features � � � � ����������� ��������� ��� ATT indicator Power Turning ON the Power Press the [SRC] button. Turning OFF the Power Press the [SRC] button for at least 1 second. Selecting the Source Press the [SRC] button. Source required Source required Tuner...
General features Audio Control Enter the Audio Control mode Press the [AUD] button for at least 1 second. "AUD mode" is displayed. Select the Audio item for adjustment Press the [FM+] or [AM–] button. Each time the button is pressed, the items that can be adjusted switch as shown below.
SRS WOW Control Adjusts each function of SRS WOW individually. Enter the WOW Control mode Press the [WOW] button for at least 1 second. "WOW CTRL" is displayed. Select the WOW item for adjustment Press the [FM+] or [AM–] button. Each time the button is pressed, the items that can be adjusted switch as shown below.
General features Adjustment of Equalizer type at PRO Adjusting the effect of an Equalizer type selected in 'Equalizer Control' when 'Equalizer mode' is "PRO". Refer to 'Equalizer Control' (page 11) to select the Equalizer type. Select the item for adjustment Press the [FM+] or [AM–] button.
Exit the Movie Select mode Press the [MOVIE] button for at least 1 second. When operation stops for 10 seconds, Movie at that time is registered and the Movie Select mode automatically closes. Switching Display Switching the information displayed. Press the [DISP] button. Each time the button is pressed the display switches as shown below.
General features Illumination Color Select Setting the color of the display. Enter the Illumination Color Select mode Press the [COL] button. "Illumi" is displayed. Select the Illumination Color Press the [COL] button. Each time the button is pressed, the Illumination Color switches as shown below: Illumination Color Display...
Station/Disc Naming (SNPS/DNPS) Attaching a title to a Station or CD. Receive/play the station/disc you want to attach a title to • Refer to the 'Switching Display' (page 13) and select either "DNPS" or "SNPS". No name can be attached to the source if "DNPS"...
Tuner features � � � ��� Preset station number Preset station number AUTO indicator ST indicator Tuning Selecting the station. Select tuner source Press the [SRC] button. Select the "TUNER" display. Select the band Press the [FM+] or [AM–] button. Each time the [FM+] button is pressed it switches between the FM1, FM2, and FM3 bands.
Station Preset Memory Putting the station in the memory. Select the band Press the [FM+] or [AM–] button. Select the frequency to put in the memory Press the [4] or [¢] button. Put the frequency in the memory Press the desired [1] — [6] button for at least 2 seconds.
Cassette player features � �� ��� ��� ��� ��� ��� Tape counter display Playing Cassette Tapes When the Cassette Tape is inserted Press the [SRC] button. Select the "TAPE" display. • When there’s a Cassette Tape inserted, the indicator is ON. When you want to listen to the reverse side Press the [38] button.
DPSS (Direct Program Search System) Indicating the songs to skip, and Fast Forwarding or Rewinding. Skipping to a later song Press the [¢] button. Each time the button is pressed the number of songs skipped increases. Skipping to a previous song Press the [4] button.
CD/ MP3/ WMA/ External disc control features � ���� ��� ����� ��� ����� ����� ��� Track time Track time Track number CH indicator Disc number Playing CD & MP3/WMA When a CD is inserted Press the [SRC] button. Select the "CD" display. •...
Pause and play Press the [38] button. Each time the button is pressed it pauses and plays. • Disc 10 is displayed as "0". • The functions that can be used and the information that can be displayed will differ depending on the external disc players being connected.
During Select mode the folder information is displayed as shown below. Folder name display Displays the current folder name. KENWOOD Select the folder level Press the [FM+] or [AM–] button. With the [FM+] button you move 1 level down and with the [AM–] button 1 level up.
Function Set � � � ��� ��� Function Set Setting during operation beep sound etc. functions. The Function Set basic operation method is explained here. The reference for the Function items and their setting content is after this operation explanation. Enter Function Set mode Press the [FNC] button for at least 1 second.
Function Set In Standby mode Illumination Color Mode Setting the Illumination Color Mode of your display. Display Display Display Setting Setting The color of your display changes from one "COL Sync" color to another during volume adjustment and during Attenuator being ON. "COL Fix"...
In Standby mode Security Code Because authorization by the Security Code is required when it’s removed from the vehicle, personalizing this unit is by using the Security Code is a help in preventing theft. • When the Security Code function is activated, the code can’t be changed and the function can’t be released.
Function Set In Standby mode Security Indicator A red indicator will blink on the unit after the ACC is set to OFF, warning potential thieves. Display Display Display Setting Setting "S.I Off" LED OFF. "S.I On" LED flashes. Function of DPX-MP4070/DPX-MP4070B In Standby mode CD Read Setting When there is a problem on playing a CD with...
Basic Operations of remote ���� � ���������� ����� Not Used ��� � ��� Loading and Replacing the battery Use two "AA"-size batteries. Slide the cover while pressing downwards to remove it as illustrated. Insert the batteries with the + and – poles aligned properly, following the illustration inside the case.
Basic Operations of remote In Tuner source [FM]/ [AM] buttons Select the band. Each time the [FM] button is pressed it switches between the FM1, FM2, and FM3 bands. [4]/ [¢] buttons Tune up or down band. [0] — [9] buttons Press buttons [1] —...
Accessories/ Installation Procedure Accessories Installation Procedure 1. To prevent a short circuit, remove the key from the ignition and disconnect the - battery. 2. Make the proper input and output wire connections for each unit..1 3. Connect the speaker wires of the wiring harness. 4.
Connect to the terminal that is grounded when either the telephone rings or during conversation. To connect the MUTE KENWOOD navigation system, consult your navigation manual. To car light control switch ILLUMI To "EXT.AMP.CONT. " terminal of the amplifier having the EXT.CONT.
Installation When performing a check of the CD operation prior to installation, place this unit in a horizontal position and perform a loading/eject of the CD. Installation Install onto the car bracket using the supplied screws (M5 × 6 mm, M5 × 7 mm). The holes of the car bracket to use will differ depending on the car model.
Troubleshooting Guide What might seem to be a malfunction in your unit may just be the result of slight misoperation or miswiring. Before calling service, first check the following table for possible problems. General The power does not turn ON. ...
Page 33
Cassette tape source Can’t remove tape. The cause is that more than 10 minutes has elapsed since the vehicle ACC switch was turned OFF. The tape can only be removed within 10 minutes of the ACC switch being turned OFF. If more than 10 minutes has elapsed, turn the ACC switch ON again and press the Eject button.
Page 34
Troubleshooting Guide MP3/WMA source Cannot play an MP3/WMA. The media is scratched or dirty. Clean the media, referring to the CD cleaning of the section on 'About CDs' (page 8). The sound skips when an MP3/WMA is being played.
Page 35
No Name: Attempted to display DNPS during the CD play having no disc names preset. Load: Discs are being exchanged in the Disc changer. Reading: The unit is reading the data on the disc. (Blink): The CD player section is not operating properly.
Page 74
차례 안전상의�주의 경고 주의 주 주 카세트�테이프 MP3/WMA�재생의�주의점� CD 에�관해서 일반�기능 전원 소스의�선택 볼륨 소음기 오디오�컨트롤 서브�우퍼�출력 TEL�뮤트 SRS�WOW 선택 SRS�WOW�컨트롤 이퀼라이저�컨트롤 EASY 에서�이퀼라이저�타입의�변경 PRO 에서�이퀄라이저�타입의�변경 이퀄라이저�타입�변경의�메모리�사전�설 정 영화�선택 디스플레이의�변환 일류미네이션�컬러�선택 이용자�일류미네이션�컬러�설정 시간�조정 방송국�/�디스크의�이름�붙이기�(SNPS�/� DNPS) 보조입력원�설정 튜너�기능 튜닝 다이렉트�액세스�튜닝 방송국�사전�설정�메모리 자동�메모리�등록...
영화�선택�모드에서�나옵니다 [MOVIE]�버튼을�1 초�이상�누르십시오 . 조작을� 10 초동안� 중단하면 ,� 그� 때의� 영화가� 등 록되고�영화�선택�모드가�자동으로�닫힙니다 . 디스플레이의�변환 표시되어지는�정보의�변환 . [DISP]�버튼을�누르십시오 . 버튼을�누를�때마다�디스플레이는�다음과�같이�변 환되어집니다 . 튜너�소스에서 정보 주파수 방송국�이름�혹은�주파수 문자 시간 CD�&�외부�디스크�소스에서 정보 트랙�번호�&�트랙�시간 디스크�이름 디스크�타이틀 트랙�타이틀 문자 시간 MP3/WMA�소스에서�(DPX-MP4070/ DPX-MP4070B) 정보 트랙�번호�&�트랙�시간...
