This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
Manufacturer disclaims any responsibility to advise purchasers of any specifi c requirements that may be applicable to the use of the Products in such environments. ® -2- FORM NO 71358A American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke...
DANGER: Failure to read the Owner’s Manual prior to operating or servicing your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it.
ENGLISH Introduction & Machine Specifi cations Model EZ Sand-HDTR Code Number 07163A Voltage/Frequency 115V/60 Hz Amperage (A) Motors (3) 1/3 hp each Pad Size (3) 7” O.D. each Power Cable 40’ 12-3 Ga Gray Rubber Jacketed Orbits Per Minute 5000 ea. motor Orbit Dia.
fi rm grip and proper lifting technique. Get assistance if necessary. 6. Secure machine to prevent movement in cargo area. Figure 1A Figure 2 ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR FORM NO 71358A - 5 - Clarke...
Never put yourself or let others be in a position to get injured if the machine should tip or fall while replacing the pad or changing abrasive. Figure 4A ® -6- FORM NO 71358A American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke...
Page 7
NOTE: For best results, empty frequently. Follow all warnings posted in this manual and on the dust bag. Figure 6 ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR FORM NO 71358A - 7 - Clarke...
To prevent damage to the fl ooring and to Figure 8 reduce swirling, keep the machine in motion while the motor is running. NOTE: For sanding cuts and sandpaper, see page 10. ® -8- FORM NO 71358A American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke...
The latches have loosened up. To tighten latches, loosen the lock nut, screw in the latch base machine. hook and then tighten the lock nut. ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR FORM NO 71358A - 9 - Clarke...
A very fi ne grain will close the pores on a wood fl oor making admission of a stain diffi cult. If glazing or burning should occur the abrasive has dulled and must be replaced. ® -10- FORM NO 71358A American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke...
Page 11
ENGLISH ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR FORM NO 71358A - 11 - Clarke...
Page 12
Este manual contiene información importante acerca del uso y la seguridad de la máquina. Si no lee el manual antes de utilizar su máquina Clarke American Sanders o de intentar realizar los procedimientos de reparación o mantenimiento de la misma, usted o el resto del personal podrían sufrir lesiones; asimismo, podrían producirse daños a la máquina o a otras propiedades.
PELIGRO: Si no lee el manual de instrucciones antes de operar, reparar o realizar el mantenimiento de su máquina Clarke American Sanders, el resultado puede ser que usted o el resto del personal sufra lesiones. Asimismo, pueden producirse daños a la máquina o a otras propiedades.
ESPAÑOL Introducción y especifi caciones de la máquina Modelo EZ Sand - HDTR 07163A Número de código 115V/60 Hz Voltaje/frecuencia Intensidad de corriente (A) cv cada uno Motores (3) 7” diámetro exterior cada uno Tamaño de la almohadilla (3) Ga gris 40’...
De ser necesario, solicite ayuda. Figura 1A 6. Asegure la máquina para evitar movimientos en el área de carga. Fgiura 2 ® American Sanders Manual del operador (ES) - EZ Sand - HDTR FORM NO 71358A - 15 - Clarke...
(ni deje que otras personas lo hagan) en una posición en la que pueda lesionarse si la máquina se inclina o cae. Figura 4A ® -16- FORM NO 71358A American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke...
Page 17
NOTA: Para lograr los mejores resultados, vacíe frecuent- Figura 6 emente. Siga todas las advertencias incluidas en el manual y en la bolsa de polvo. ® American Sanders Manual del operador (ES) - EZ Sand - HDTR FORM NO 71358A - 17 - Clarke...
NOTA: para cortes de lija y papel de lija consulte la página 20. ® -18- FORM NO 71358A American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke...
Para ajustar los seguros, afl oje la tuerca de seguridad, la base de la máquina. atornille el gancho del seguro y por ultimo ajuste la tuerca de seguridad. ® American Sanders Manual del operador (ES) - EZ Sand - HDTR FORM NO 71358A - 19 - Clarke...
Si un corte de acabado apareciera inmediatamente glaseado o quemado, aumente el ritmo. Si esto ocurriera durante un corte fi nal, signifi ca que el abrasivo se ha desafi lado y deberá cambiarse. ® -20- FORM NO 71358A American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke...
Page 21
ESPAÑOL ® American Sanders Manual del operador (ES) - EZ Sand - HDTR FORM NO 71358A - 21 - Clarke...
Page 22
Ce Manuel contient des informations importantes concernant l’utilisation et le fonctionnement de cette machine dans des conditions de sécurité optimales. La non-lecture de ce manuel avant d’utiliser ou d’entretenir votre machine Clarke American Sanders risque de provoquer un accident ou d’endommager la machine ou son environnement. Vous devez avoir été formé...
ATTENTION apparaissant sur l’appareil ou dans votre manuel d’utilisation. DANGER: Si vous ne lisez pas le manuel d’utilisation avant d’utiliser ou réparer votre appareil Clarke, vous risquez de vous blesser ainsi que d’autres personnes. Vous risquez également d’endommager l’appareil et de causer divers dommages matériels.
FRANÇAIS Introduction et spécifi cations de l’appareil Modèle EZ Sand - HDTR 07163A Numéro de code 115V/60 Hz Tension/fréquence Instensité (A) 1/3 hp chacun Moteurs (3) 7” de diamétre extérieur chacun Taille du patin 40’ grosseur 12-3 Câble d’alimentation gaine grise en caoutchouc...
Demandez de l’aide si nécessaire. Figure 1A 6. Attachez l’appareil pour éviter qu’il ne bouge sur le véhicule de transport. Figure 2 ® American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR FORM NO 71358A - 25 - Clarke...
à basculer ou se renverser. Figure 4A ® -26- FORM NO 71358A American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke...
Page 27
NOTE: Pour obtenir les meilleurs résultats, vider fréquemment le sac. Respecter toutes les mises en garde indiquées dans le présent manuel et sur le sac à poussières. Figure 6 ® American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR FORM NO 71358A - 27 - Clarke...
REMARQUE : Pour avoir des conseils sur le ponçage et le papier Figure 8 abrasif, voir en page 30. ® -28- FORM NO 71358A American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke...
Le verrou n’est pas enfoncé. Enfoncez le verrou avant d’actionner la manette de commande. Interrupteur défectueux, mauvaise con- Contactez un détaillant Clarke agréé. nexion. Le moteur démarre mal ou fonc- Tension faible à cause d’une rallonge trop Utilisez une rallonge électrique de grosseur 14 ne dé- tionne trop lentement.
Si vous détectez une vitrifi cation ou des traces de brûlure, le papier abrasif s’est émoussé et doit être remplacé. ® -30- FORM NO 71358A American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke...
Page 31
EZ Sand - HDTR Section II Parts Manual (71358A)
1/14 HANDLE ASSY ® - 32 - FORM NO 71358A American Sanders Operator's Manual - EZ Sand - HDTR Clarke...
Page 33
71347A Label CCA Warning 71368A Label Caution EZ-SAND 40540A Cordset 12-3X40FT 5-15P 70175A-FR Tag Warning Eng-Frn = Revised or new since last update ® American Sanders Operator's Manual - EZ Sand - HDTR FORM NO 71358A - 33 - Clarke...
10/12 BASE ASSY ® - 34 - FORM NO 71358A American Sanders Operator's Manual - EZ Sand - HDTR Clarke...
Page 35
NOTE 2: Includes one each of items 2, 11, 33. Includes a quantity of two of item 1. NOTE 3: Includes three pads. ® American Sanders Operator's Manual - EZ Sand - HDTR FORM NO 71358A - 35 - Clarke...
