Service Manual

Relese 1
DIGITAL HDTV
CHASSIS : SC-110
Model : DSC-30W60N
DSC-30W60N

Specifications

Power Requirement
Power Consumption
Dimensions(W/H/D)
Weight
General
Antenna
RF Band Coverage
Screen Size
Display Format
Horizontal Resolution
Digital Audio
Sound
NTSC Audio
Audio Power
A/V In
S-Video In
HD Component Video In
Number of Inputs / Outputs
HD Component Audio In
Digital Audio In
Digital Audio Out
External Speaker Out
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr
S/M No. : TSC110NEF0
R-V3
AC 120V, 60Hz
250W (1.7W in standby)
890 x 573 x 560 mm
64kg
Two 75 ohm external input terminals for UHF/VHF/Cable
One 75ohm external output terminal for Cable
VHF 2 ~ 13
UHF 14 ~ 69
CATV 1, 14 ~ 125
32 inches Pure Flat 16:9 Aspect ratio
1920
x 1080i (Digital)
Upconversion to 1080i with line doubling (NTSC)
800 Lines
Dolby Digital AC-3 / Pro logic
Multi-CH TV Stereo (MTS) / Second Audio Program (SAP)
8W / ch (Main L/R, Woofer), 5W / ch (Center, SL, SR)
4 each (Video / L / R)
2 each
2 each ( Y/ Pb / Pr, R / G / B )
1 each ( L / R / SL / SR / Center / Woofer )
2 each ( Coaxial / Optical )
2 each ( Coaxial / Optical )
1 each ( SL / SR / Woofer)
Mar. 2000

Advertisement

Table of Contents
loading

Related Manuals for Daewoo DSC-30W60N

Summary of Contents for Daewoo DSC-30W60N

  • Page 1: Service Manual

    S/M No. : TSC110NEF0 Service Manual Relese 1 DIGITAL HDTV CHASSIS : SC-110 Model : DSC-30W60N R-V3 DSC-30W60N Specifications Power Requirement AC 120V, 60Hz Power Consumption 250W (1.7W in standby) Dimensions(W/H/D) 890 x 573 x 560 mm Weight 64kg General...
