LG SP110 Manual

Hide thumbs Also See for SP110:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
Enlarged version

Phone components

This section provides an introduction to the LG-
SP110. It includes illustrations and descriptions of
the important phone parts and instructions for
getting your phone powered up and ready to use.
Handstrap hole
Lamp
Headset Jack
Buzzer
Side keys
Soft key1
MSG key
Alphanumeric
keypad
See page 11 for an overview of your phone.
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS :
Antenna
Earpiece
LCD screen
Soft key2
2. WHAT THIS WARRANTY DOES NOT COVER :
Scroll keys
Microphone
Active Flip
LG offers you a limited warranty that the enclosed subscriber unit and
its enclosed accessories will be free from defects in material and
workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year
beginning on the date of purchase of the product.
(2) The limited warranty extends only to the original purchaser of the
product and is not assignable or transferable to any subsequent
purchaser/end user.
(3) This warranty is good only to the original purchaser of the
product during the warranty period as long as it is in the U.S,
including Alaska, Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall be free of defects at
the time of shipment and, therefore, shall not be covered under
these limited warranty terms.
(5) Upon request from LG, the consumer must provide information
to reasonably prove the date of purchase.
(6) The customer shall bear the cost of shipping the product to the
Customer Service Department of LG. LG shall bear the cost of
shipping the product back to the consumer after the completion
of service under this limited warranty.
(1) Defects or damages resulting from use of the product in other
than its normal and customary manner.
(2) Defects or damages from abnormal use, abnormal conditions,
improper storage, exposure to moisture or dampness,
unauthorized modifications, unauthorized connections,
unauthorized repair, misuse, neglect, abuse, accident, alteration,
improper installation, or other acts which are not the fault of LG,
including damage caused by shipping, blown fuses, spills of food
or liquid.
(3) Breakage or damage to antennas unless caused directly by
defects in material or workmanship.
(4) That the Customer Service Department at LG was not notified by
consumer of the alleged defect or malfunction of the product
during the applicable limited warranty period.
(5) Products which have had the serial number removed or made
illegible.

Advertisement

Table of Contents
loading

Related Manuals for LG SP110

Summary of Contents for LG SP110

  • Page 1: Phone Components

    1. WHAT THIS WARRANTY COVERS : the important phone parts and instructions for LG offers you a limited warranty that the enclosed subscriber unit and getting your phone powered up and ready to use. its enclosed accessories will be free from defects in material and...
  • Page 2 (7) Damage resulting from use of non-LG approved accessories. Your wireless telephone gives you the powerful ability to (8) All plastic surfaces and all other externally exposed parts that are communicate by voice-almost anywhere, anytime.
  • Page 3 The an auto accident crime in progress or other serious emergency LG-SP110 is a PCS phone that can operate on where lives are in danger, call 9-1-1 or other to call emergency digital cellular systems. It is an advanced, compact number, as you would want others to do for you.

  • Page 4: Important Information

    Check Components Exposure to Radio Frequency Each standard unit comes with the LG-SP110 Energy phone, a one-slot desktop charger, and one In 1991, the Institute of Electrical and Electronics rechargeable battery.

  • Page 5: Table Of Contents

    Contents FCC Part 15 Class B Compliance Introduction This equipment has been tested and found to comply with the limits for a Class B digital device, Highlights pursuant to part 15 of the FCC Rules. These are Important Information designed to provide resonable protection against Check Components harmful interference in a residential installation.
  • Page 6 Speed Dialing Chapter 7. Accessories Caller ID Chapter 8. Appendix Phone Book Features Key Lock Menu Tree Chapter 3. Menu Features Chapter 9. Safety Guidelines General Guidelines to MENU Access Safety Information and Settings FDA Consumer Update Sound Display System Call Information Features Utility...

  • Page 7: Chapter 1. Getting Started

    Use only the batteries, antennas, and chargers When turn power on/off. This key disconnects a provided by LG. The warranty will not be applied call. Using this key, you can also exit out of a menu to products provided by other suppliers.

  • Page 8: Lcd Icons

    LCD Icons Using the Battery Pack An image display which shows the function available Charge the battery full before the initial use of the phone. when in use. The phone comes with a rechargeable battery pack. Icons Descriptions On purchasing the phone, one must charge the Digital indicator battery fully.
  • Page 9 Using the Desktop Charger the battery’s performance. 2. Use only LG batteries and chargers. LG’s chargers The LG-SP110 desktop charger has a slot for are designed to maximize the battery life. recharging batteries. The slot accommodates phone and battery pack for charging.

  • Page 10: Chapter 2. Basic Functions

    If the phone is locked, enter the lock code and Chapter 2. Basic Functions press “Call Failed” indicates that the call did not go through. Turning the Phone On and Off 4. Press to disconnect the call. 5. “This phone has been restricted” displayed on Turning the Phone On your screen means that outgoing call restricted 1.

  • Page 11: Using Quick Mode

    In call waiting mode, the active call is put on hold as Call Waiting you answer another incoming call. Your cellular service may offer the call waiting This service is provided by your service provider. function. While you are answering a call, you may When the call waiting function is activated, your hear two beeps indicating another incoming call.

  • Page 12: Adjusting The Volume

    Adjusting the Volume Signal Strength The volume buttons on the left topside of the phone The call quality depends on the signal strength in can be used to adjust earpiece, ringer, key beep your area. The phone displays the current strength volumes and message volume (SMS message as the number of bars next to the signal strength volume).

  • Page 13: Phone Book Features

    Caller ID Personal Phone Book Memory The phone has 198 personal phone book memory This feature enables the phone number of the caller locations where you can store up to 32 digits with an to be displayed when you receive the call. You associated name of up to 16 characters.
  • Page 14 When you have the correct For example, to enter the name LG, either press letter or number in position on the screen, wait (wait) or press...
  • Page 15 Retrieving Numbers The Entry # for telephone number to be retrieved may now be entered. Retrieving by Name Search To search telephone numbers, including special 1. Press Soft Key 2 BOOK numbers, enter a special number in the initial display 2.
  • Page 16 Dialing Numbers from Your Phone Book Edit Phone # 1. Locate telephone # to be edited in the You can make a call using any memory location either by speed dialing from the memory list or by corresponding Entry. pressing while viewing the full contents of the 2.
  • Page 17 3) Select one from the following: 4. Dialing from a Memory List Press [Hard Pause]. 1) From a memory list, press the scroll keys to go to the memory location you want. Press [Time Pause]. Press [Hyphen], and hyphens will not pause a 2) Press number.
  • Page 18 Ring & Vib Volume (MENU Chapter 3. Menu Features Adjust the volume of the ringer. General Guidelines to MENU Key Beep (MENU Access and Settings Set Key beep length and touch tone playback speed. 1. Press Soft Key 1 MENU .
  • Page 19 When you leave a service area, the phone displays Auto Hyphen (MENU “Leaving Service Area” message. Set hyphen option. When on, this automatically inserts 4. Call Connect (MENU hyphens to be consistent with U.S. phone numbers. Alert sound to notify the user when the call is Language (MENU connected.
  • Page 20 You can reset it by pressing Soft Key 1 Auto Answer (MENU Press Soft Key 1 after select [Zero] using the Select the number of rings before the phone ] button. automatically answers a call. This feature is most All Calls (MENU commonly used with the car kit.
  • Page 21 phone numbers in locations 1 to 8. You will still 3) Press in order. receive calls in restrict mode. 4) Select using buttons, then press [SEL] button. Then you will see the result of calculation “2500”. Clear Call (MENU Used to deletes all the phone number saved in the Audio AGC (MENU Call History for which calls have been made.
  • Page 22 Recent Call History List Chapter 4. Book Features The phone keeps a list of the last 30 calls you have made, inclusive of Outgoing, Incoming, Missed, or Call History (BOOK Scratchpad (using the scratch pad feature) calls. You can redial any of these numbers quickly and easily. The phone maintains a list of the last 30 calls made, inclusive of Outgoing, Incoming, Missed calls.
  • Page 23 PC-Sync Find Name (BOOK (BOOK 1. Press Soft Key 2 BOOK Phone's Sync feature will synchronize Your data between your phone and your PC. This 2. Press [Phone Book] [Find Name] feature allows you to save time and effort by 3.

  • Page 24: New Text

    1. The phone displays the message on the screen. Chapter 5. Message Features 2. One of four sounds is heard (if selected). 3. The red light blinks. Text message, page and voice mailbox become 4. The message icon is displayed on the screen available as soon as the power is on.

  • Page 25: Old Text

    % Auto Delete function: In the case of message Out of Memory Warning storage are full, the oldest message is automatically No more messages can be received until enough replaced by new message. But be marked as [Not memory space becomes available. A_Del], the message will be reserved on storage.
  • Page 26 Chapter 6. Functions used during a call Chapter 7. Accessories Mute There are a variety of accessories available for the (In a call state : MENU phone. You can select these options according to Switch microphone on and off while in a call. your personal communication requirements.
  • Page 27 a red light anytime there is power. Chapter 8. Appendix It takes 5 hours to charge a compl- etely discharged battery. Menu Tree Hands-Free Car Kit (Portable) The hands-free car kit, model PHF-30W , enables you to attach the phone to the car providing you with hands-free operation.

  • Page 28: Safety Information

    Extend your antenna fully Chapter 9. Safety Guidelines Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

  • Page 29: Fda Consumer Update

    Persons with pacemakers; atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or Should ALWAYS keep the phone more than six inches from their even death. pacemaker when the phone is turned ON; Should not carry the phone in a breast pocket;...
  • Page 30 Questions have been raised about hand-held mobile phones, the sheath). No statistically significant association was found between kind that have a built-in antenna that is positioned close to the mobile phone use and acoustic neuroma. There was also no user’s head during normal telephone conversation. These types of association between mobile phone use and gliomas when all types mobile phones are of concern because of the short distance of types of gliomas were considered together.
  • Page 31 Two groups of 18 people were exposed to simulated mobile phone begin to generate this type of information. signals under laboratory conditions while they performed cognitive What is FDA’s role concerning the safety of mobile phones? function tests. There were no changes in the subjects’ ability to Under the law, FDA does not review the safety of radiation-emitting recall words, numbers, or pictures, or in their spatial memory, but consumer products such as mobile phones before marketing, as it...
  • Page 32 3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey, A. Effect of a 915-MHz simulated mobile phone LG Kang-Nam Tower, 679, Yoksam-dong, Kangnam-gu, Seoul, signal on cognitive function in man. Int. J. Radiat. Biol., April 8, 135-080, Korea 1999.
