Page 1: Table Of Contents
Navigation system based climate control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Adaptive cruise control Moon roof 2010 MKS (mks) Owners Guide (own2002), 1st Printing USA (fus)
Page 2 Table of Contents Locks and Security Keys Locks Anti-theft system Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac...
Page 3 Table of Contents Customer Assistance Reporting safety defects (U.S. only) Reporting safety defects (Canada only) Cleaning Maintenance and Specifications Engine compartment Engine oil Battery Engine coolant Fuel information Air filter(s) Part numbers Maintenance product specifications and capacities Engine data Accessories Ford Extended Service Plan Index All rights reserved.
Page 4: Introduction
Introduction CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it. For more information on Ford Motor Company and its products visit the following website: •...
Page 5 Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
Page 6 Introduction SPECIAL NOTICES New Vehicle Limited Warranty For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide/Customer Information Guide that is provided to you along with your Owner’s Guide.
Page 7 Introduction Event Data Recording Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as: •...
Page 8 Introduction information”) only to help provide you with the directions, traffic reports, or business searches you request. If you do not want Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information.
Page 9 Introduction EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this Owner’s Guide. A market unique supplement may be supplied that complements this book.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 13 Instrument Cluster Engine coolant temperature (RTT): Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Refer to Engine coolant in the Maintenance and Specifications chapter. Low fuel (RTT): Illuminates when the fuel level in the fuel tank is at or near empty.
Page 14 Instrument Cluster Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter.
Page 15 Instrument Cluster Airbag readiness: If this light fails to illuminate when the ignition is turned on, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will sound if there is a malfunction in the indicator light. Safety belt: Reminds you to fasten your safety belt.
Page 16 Instrument Cluster Speed control: Illuminates when the speed control is engaged or when the ACC is engaged without following a vehicle. Turns off when the speed control system is disengaged or when the ACC is activated. Anti-theft system: Flashes when the SecuriLock Passive Anti-theft System has been activated.
Page 17: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If the needle moves close to the “H” range, the engine is overheating.
Page 18: Message Center
Instrument Cluster Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is on). The fuel gauge may vary slightly when the vehicle is in motion or on a grade. The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located.
Page 19 Instrument Cluster Info Press the INFO button repeatedly to cycle through the following features: TRIP A/B Registers the distance of individual journeys. Press and release INFO until the A or B trip appears in the display (this represents the trip mode).
Page 20 Instrument Cluster • Variations in top-off procedure from one fill-up to another • Rounding of the displayed values to the nearest 0.1 gallon (liter) To determine your average highway fuel economy, do the following: 1. Drive the vehicle at least 5 miles (8 km) with the speed control system engaged to display a stabilized average.
Page 21 Instrument Cluster 1. OIL LIFE 2. WASHER FLUID LEVEL 3. DOOR AJAR STATUS 4. TRUNK AJAR/CLOSED 5. BRAKE SYSTEM 6. TIRE PRESSURE 7. FUEL LEVEL 8. MYKEY DISTANCE (If MyKey™ is programmed) 9. MYKEY(S) PROGRAMMED 10. ADMIN KEYS PROGRAMMED Note: Some systems show a message only if a condition is present. OIL LIFE This displays the remaining oil life.
Page 22 Instrument Cluster AUTO HIGH BEAM (if equipped) This feature automatically turns on your high beams if it is dark enough and no other traffic is present. Press RESET to turn it off or on. AUTOLAMP This feature keeps your headlights on for up to three minutes after the ignition is switched off.
Page 23: System Warnings
Instrument Cluster EASY ENTRY This feature automatically moves the driver’s seat backwards for easy exit/entry from the vehicle. Press RESET to turn it off or on. REAR PARK AID (if equipped) This feature sounds a tone to warn the driver of obstacles near the rear bumper, and functions only when R (Reverse) gear is selected.
Page 24 Instrument Cluster • Some messages will reappear after clearing or being reset if a problem or condition is still present and needs your attention. • Some messages can be acknowledged and reset by pressing RESET. This allows you to use the full message center functionality by clearing the message.
Page 25 Instrument Cluster LOW TIRE PRESSURE — Displayed when one or more tires on your vehicle have low tire pressure. Refer to Inflating your tires in the Tires, Wheels and Loading chapter. TIRE PRESSURE MONITOR FAULT — Displayed when the Tire Pressure Monitoring System is malfunctioning.
Page 26 Instrument Cluster INTKEY COULD NOT PROGRAM — Displayed when an attempt is made to program a fifth integrated key to the Remote keyless entry system. For more information on integrated key, refer to the Locks and Security chapter. CRUISE ON RADAR READY (if equipped) — Displayed when the driver pressed the cruise On/Off control and ACC was off.
Page 27 Instrument Cluster SHIFT TO PARK (if equipped) — Displayed when the start/stop button is pressed to shut off the engine with the shift select lever in any position other than P (Park). Refer to Fast restart feature in Push button start system in the Driving chapter for more information. NO KEY DETECTED (if equipped) —...
Page 28 Instrument Cluster VEHICLE SPEED 80 MPH MAX — Displayed when a MyKey™ is in use and the Admin has enabled the MyKey speed limit and the vehicle speed is 80 mph (130 km/h). Refer to MyKey™ in the Locks and Security chapter for more information.
Page 29 Instrument Cluster CANCELLED BY ADV TRAC EVENT (if equipped) — Displayed when the active park feature has been canceled due to the AdvanceTrac system activating. Refer to Active park assist in the Driving chapter for more information. CANCELLED BY ABS EVENT (if equipped) — Displayed when the active park feature has been canceled due to the ABS activating.
Page 30 Instrument Cluster TO STOP ALARM START VEHICLE — Displayed when the perimeter alarm system is armed and the vehicle is entered using the key on the driver’s side door. In order to prevent the perimeter alarm system from triggering, the ignition must be turned to start before the 12 second chime expires.
Page 31: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS Note: If your volume is muted and MYKEY VOLUME LIMITED is displayed, refer to MyKey™ in the Locks and Security chapter for more information. Premium/Premium plus AM/FM in-dash CD6/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury.
Page 32 Entertainment Systems Setting the clock CLOCK: Press to set the clock. The display will read SET TIME. Use the memory preset numbers (0–9) to enter in the desired time– hours and minutes. The clock will then begin from that time. AM/FM Radio / VOL (Power/Volume): Press to turn the radio on/off.
Page 33 Entertainment Systems To activate: Press MENU repeatedly until RDS (ON/OFF) appears in the display. Use SEEK to toggle RDS ON/OFF. When RDS is OFF, you will not be able to search for RDS equipped stations or view the station name or type. CAT/FLD (Category/Folder): This feature allows you to select from various music categories.
Page 34 Entertainment Systems When the system has ejected the CD, the display will read REMOVE CD #. If you do not remove the CD the system will reload the disc. To auto eject all loaded discs– Press and hold . The system will eject all discs and prompt you when to remove them.
Page 35 Entertainment Systems TUNE: Turn to go to the next / previous available SIRIUS satellite station. DIRECT: Press DIRECT then enter the desired channel (i.e. 002) using the memory preset buttons (0–9). If you only enter one digit, press OK and the system will go to that satellite channel. If you enter three digits, the system will automatically go to that channel, if available.
Page 36 Entertainment Systems SATELLITE RADIO MENU: Press MENU when satellite radio mode is active to access. Press OK to enter into the satellite radio menu. Press SEEK to cycle through the following options: • CATEGORY MENU- Press OK to enter category mode. Press SEEK to scroll through the list of available SIRIUS...
Page 37 Entertainment Systems d. DISABLE ALERTS/ENABLE ALERTS: Press OK to enable/disable the satellite alert status which alerts you when your selected songs are playing on a satellite radio channel. (The system default is disabled.) SONG ALERTS ENABLED/DISABLED will appear in the display. The menu listing will display the opposite state. For example, if you have chosen to enable the song alerts, the menu listing will read DISABLE as the alerts are currently on, so your other option is to turn them off.
Page 38 Entertainment Systems FADE: Press SEEK to adjust the audio between the back (B) and front (F) speakers. SPEED COMPENSATED VOLUME: With this feature on, radio volume automatically gets louder with increasing vehicle speed to compensate for road and wind noise. The default setting is off.
Page 39: Auxiliary Input Jack (Line In)
Entertainment Systems Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 40 Entertainment Systems 3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable to the AIJ in your vehicle. 4. Turn the radio on, using either a tuned FM station or a CD loaded into the system.
Page 41: Usb Port
Entertainment Systems USB port WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The driver’s primary responsibility is the safe operation of their vehicle.
Page 42 Entertainment Systems Radio reception factors: There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the weaker the signal and the weaker the reception. • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception.
Page 43 Entertainment Systems Do not use any irregular shaped CDs or discs with a scratch protection film attached. CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather...
Page 44: Satellite Radio Information
Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
Page 45 Entertainment Systems • Terrain: Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree foliage and thunderstorms can interfere with your reception. • Station overload: When you pass a ground based broadcast repeating tower, a stronger signal may overtake a weaker one and result in an audio mute.
Page 46 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. This than two seconds to message should disappear produce audio for shortly. the selected channel. SAT FAULT Internal module or If this message does not system failure clear within a short period present.
Page 47: Navigation System
Entertainment Systems Radio Display Condition Action Required NO TEXT Category Category information not information not available at this time on available. this channel. The system is working properly. NO SIGNAL Loss of signal from You are in a location that is the SIRIUS satellite blocking the SIRIUS signal or SIRIUS tower to...
Page 48: Climate Controls
Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH HEATED AND COOLED SEATS Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. : Distributes outside air through the windshield defroster vents and de-mister vents. Can be used to clear the windshield of fog and thin ice.
Page 49 Climate Controls To return to full automatic control, press AUTO. : Distributes air through the instrument panel vents. To return to full automatic control, press AUTO. Passenger heated seat: Press to control the passenger heated seat. Refer to Heated and cooled seats in the Seating and Safety Restraints chapter for more information.
Page 50 Climate Controls 12. MAX A/C: Distributes recirculated air through the instrument panel vents to cool the vehicle. This re-cooling of the interior air is more economical and efficient. Recirculated air may also help reduce undesirable odors from entering the vehicle. Press the MAX A/C button again for normal A/C operation.
Page 51: Navigation System Based Climate Control
Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH HEATED AND COOLED SEATS (NAVIGATION SYSTEM BASED–IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. 1. Climate: Press to control the climate control system through the touch display screen.
Page 52 Climate Controls Rear defroster: Press to activate/deactivate the rear window defroster. Refer to Rear window defroster later in this chapter for more information. This button will also activate the heated mirrors. Defrost: Distributes outside air through the windshield defroster vents and de-mister vents. Can be used to clear the windshield of fog and thin ice.
Page 53 Climate Controls TOUCHSCREEN FUNCTIONS Temperature– Press the up and down arrows on the left side of the screen to increase/decrease the airflow temperature for the driver side of the vehicle. This control also adjusts the passenger side temperature when dual zone operation is disengaged. Press the up and down arrows on the right side of the screen to...
Page 54 Climate Controls VOICE COMMANDS IN CLIMATE MODE Please refer to the Voice commands in climate mode section of the Navigation system supplement for more information on using voice commands with the climate control system. Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position.
Page 55: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice. The ignition must be on to operate the rear window defroster. The rear defroster turns off automatically after 10 minutes or when the ignition is turned off.
Page 56: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the low beam headlamps Adaptive headlamps (if equipped) The headlamp beams move in the same direction as the steering wheel to provide more visibility when driving around curves.
Page 57 Lights The autolamp system also keeps the lights on for a predetermined amount of time after the ignition is turned off. You can change the amount of time the lamps stay on by using the programming procedure that follows: Note: With autolamps, your vehicle has a headlamps on with windshield wipers feature.
Page 58 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Auto high beams During nighttime driving, the automatic high beam system automatically turns on your high beams if it is dark enough and no other traffic is present.
Page 59 Lights Operation - The high beam switch can be used to turn the high beams on and off. Scenario 4: Conditions - The automatic high beam system is set to OFF in the message center. The headlamp switch is in (auto lamps), (off),...
Page 60 Lights Note: Activating the multi-function lever will put the headlamps in manual high beam mode (constant or flash-to-pass) until the lever is returned to the neutral position. To manually override the auto high beam and go to low beam, the headlamp control must be taken out of (autolamp) position.
Page 61 Lights If it appears that automatic control of the high beams is not functioning, check the windshield in front of the camera for blockage. Flash to pass Pull toward you to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) To activate: •...
Page 62 Lights Note: If the battery is disconnected, discharged, or a new battery is installed, the dimmer control requires re-calibration. Press the dimmer control from the full dim position to the full on position to reset. This will ensure that your displays are visible under all lighting conditions. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant.
Page 63: Turn Signal Control
Lights 5. Locate the vertical adjuster on each headlamp. Using a Phillips #2 screwdriver, turn the adjuster either clockwise (to adjust down) or counterclockwise (to adjust up). The horizontal edge of the brighter light should touch the horizontal reference line. 6.
Page 64: Bulb Replacement
Lights Ambient lighting Illuminates footwells, storage bins and cupholders with a choice of several colors. The ambient lighting control is located on the instrument panel, left of the steering wheel. To activate, press and release the top of the control to cycle through the color choices plus the off state.
Page 65 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to ensure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 66 Lights 2. Reach in behind the headlamp assembly to access the bulb sockets and connectors. 3. Locate the parking/turn signal lamp electrical connector and remove it by pulling it straight off. 4. Remove the bulb socket by turning it counterclockwise and pulling it straight out.
Page 67 Lights Note: The turn bulb is a socket/bulb assembly and the bulb cannot be removed separately. Install the new bulb(s) in reverse order. Replacing high-mount brake lamp bulbs Your vehicle is equipped with an LED center high-mount stop lamp. It is designed to last the life of the vehicle.
Page 68: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate toward you to decrease the speed of the wipers. Rain sensing wipers (if equipped): The rain sensing wipers will automatically activate when moisture is present on the windshield and the multi-function...
Page 69: Steering Wheel Adjustment
Driver Controls Courtesy wipe feature: One extra wipe will occur a few seconds after washing the front window to clear any excess washer fluid remaining on the windshield. Note: Do not operate the washer when the washer reservoir is empty. This may cause the washer pump to overheat.
Page 70 Driver Controls ILLUMINATED VISOR MIRROR Lift the mirror cover to turn on the visor mirror lamp. Slide on rod feature Rotate the visor towards the side window and extend it rearward for additional sunlight coverage. Note: To stow the visor back into the headliner, visor must be retracted before moving it back toward the windshield.
Page 71 Driver Controls Double bin compartment ELECTRONIC COMPASS The compass heading is displayed in the Center Integrated Display (CID). The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.
Page 72 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Turn ignition to the on position. 7 8 9 1011 3. Press and hold the 7 and 9 radio preset buttons together for approximately five seconds until ZONE XX appears in the CID.
Page 73 Driver Controls 2. To calibrate, press and hold the 7 and 9 radio preset buttons together for approximately 10 seconds until CAL appears. Release the buttons. 3. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CAL display changes to the direction value (N, S, E, W, etc.).
Page 74: Power Windows
Driver Controls Auxiliary power point can be found in the following location: • On the center console • Inside the utility compartment • On the rear of the center console accessible from the rear seat Do not use the power point for operating the cigarette lighter element (if equipped).
Page 75 Driver Controls Press and pull the switches to open and close windows. • Press down (to the first detent) and hold the switch to open. • Pull up (to the first detent) and hold the switch to close. Rear Window Buffeting: When one or both of the rear windows are open, the vehicle may demonstrate a wind throb or buffeting noise.
Page 76 Driver Controls Note: The ignition must be off and the accessory delay feature must not be activated in order for this feature to operate. Note: This feature can be disabled or enabled by your authorized dealer. Global close windows You can close the vehicle’s windows and moon roof (if equipped) by using the control on the remote transmitter.
Page 77 Driver Controls Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls (except for the driver’s) press the right side of the control. Press the left side to restore the window controls.
Page 78: Mirrors
Driver Controls Automatic dimming interior rear view mirror Your vehicle is equipped with an interior rear view mirror and a driver’s side exterior mirror that have auto-dimming function. The electronic day/night mirrors will change from the normal (high reflective) state to the non-glare (darkened) state when bright lights (glare) reach the interior mirror.
Page 79: Speed Control
Driver Controls Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Note: With the Auto dimming feature, the mirror glass is thicker and will take longer to defrost. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 80 Driver Controls 2. Accelerate to the desired speed. 3. Press and release SET + or SET -. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
Page 81: Adaptive Cruise Control
Driver Controls Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased. ADAPTIVE CRUISE CONTROL (ACC) (IF EQUIPPED) Adaptive cruise control is much like speed control, only this system is designed to automatically adjust your speed to maintain a proper distance between you and the vehicle in front of you in the same lane.
Page 82 Driver Controls Setting adaptive cruise control Note: It is the drivers responsibility to stay alert, drive safely and be in control of the vehicle at all times. The controls for using your cruise control are located on the steering wheel. 1.
Page 83 Driver Controls The yellow ACC indicator light in the instrument cluster will be illuminated and the message center will temporarily display a preset GAP <--->. The vehicle will maintain a constant distance between the vehicle ahead until: • The vehicle in front of you accelerates to a speed above the set speed. •...
Page 84 Driver Controls Setting the gap distance The distance between your vehicle and the vehicle in front of you can be decreased or increased by pressing <---> control. GAP <---> will be displayed in the message center. Three gap distance settings are available: Message Following...
Page 85 Driver Controls center. When the accelerator is released, the ACC function will operate again and vehicle speed will decrease to the set speed, or a lower speed if following a slower vehicle. Changing the set speed There are three ways to change the set speed: •...
Page 86 Driver Controls Hilly condition usage It is recommended that the driver select a lower gear position when ACC is active in situations such as prolonged downhill driving on steep grades (i.e., driving in mountainous areas). In these situations, additional engine braking is needed to reduce the load on the vehicle’s regular brake system to prevent them from overheating.
Page 87 Driver Controls • With vehicles that edge into your lane. These vehicles can only be detected once they have moved fully into your lane. • There may be issues with the detection of vehicles in front when driving into and coming out of a bend or curve in the road. In these cases ACC may brake late or unexpectedly.
Page 88 Driver Controls Blocked sensor If a message regarding a blocked sensor is displayed, the radar signals from the sensor have been obstructed. The sensor is located behind a fascia cover near the driver side of the lower grille. When the radar signals are obstructed, a vehicle ahead cannot be detected and the ACC will not function.
Page 89 Driver Controls WARNING: Do not use tires sizes other than those recommended because this can affect the normal operation of ACC. Failing to do so may result in a loss of vehicle control, which could result in serious injury. STEERING WHEEL CONTROLS Radio control features Press MEDIA to select: •...
Page 90 Driver Controls In any mode: • Press VOL + or VOL - to adjust the volume. SYNC system hands free control feature Press briefly to use the voice command feature. You will hear a tone and LISTENING will appear in the radio display.
Page 91: Moon Roof
Driver Controls For further information on the Navigation system/SYNC system, refer to the Navigation System and SYNC supplements. DUAL PANEL MOON ROOF AND POWER SUNSCREEN (IF EQUIPPED) The dual panel moon roof and power sunscreen controls are located on the overhead console. WARNING: Do not let children play with the moon roof or leave children unattended in the vehicle.
Page 92 Driver Controls To close the dual panel moon roof: Pull down the SLIDE control and release. The moon roof will automatically close. Bounce-back: When an obstacle has been detected in the moon roof opening as the moon roof is closing, the moon roof will automatically open and stop at a prescribed position.
Page 93 Driver Controls Car2U Home Automation System HomeLink Wireless Control System (if equipped) The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most transmitters to operate garage doors, entry gate operators, security systems, entry door locks, and...
Page 94 Driver Controls Note: Your vehicle may require the ignition switch to be turned to the accessory position for programming and/or operation of the HomeLink . It is also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for quicker training and accurate transmission of the radio-frequency signal.
Page 95 Driver Controls HomeLink should now activate your rolling code equipped device. To program additional HomeLink buttons begin with Step 1 in this section. For questions or comments, please contact HomeLink at www.homelink.com or 1–800–355–3515. Gate Operator & Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting —...
Page 96 Driver Controls Erasing HomeLink buttons To erase the three programmed buttons (individual buttons cannot be erased): • Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.
Page 97 Driver Controls WARNING: Make sure that people and objects are clear of the garage door or security device you are programming. Do not program the Car2U system with the vehicle in the garage. Do not use the Car2U system with any garage door opener that lacks safety stop and reverse features as required by U.S.
Page 98 Driver Controls If you do not know if your garage door opener is a rolling code or fixed code device, open your garage door opener’s remote control battery cover. If a panel of DIP switches is present your garage door opener is a fixed code device.
Page 99 Driver Controls 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn” button.
Page 100 Driver Controls Note: The Car2U system allows for three devices to be programmed. If you need to change or replace any of the three devices after it has been initially programmed, it is necessary to erase the current settings using the Erasing the Car2U Home Automation System buttons procedure and then programming all of the devices being used.
Page 101 Driver Controls 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode. The indicator lights will blink slowly. Within 2.5 minutes enter your corresponding DIP switch settings from left to right into your Car2U system by pressing and releasing the buttons corresponding to the settings you circled.
Page 102 Driver Controls To erase programming on the Car2U system (individual buttons cannot be erased), use the following procedure: 1. Firmly press the two outside Car2U system buttons simultaneously for approximately 20 seconds until the indicator lights begin to blink rapidly. The indicator lights are located directly above the buttons.
Page 103 Driver Controls INTERIOR TRUNK CONTROL The trunk release button is located in the glove box. Open the glove box to access it and press the button to open the trunk. CARGO AREA FEATURES Cargo net (if equipped) The cargo net secures lightweight objects in the cargo area.
Page 104: Locks And Security
Locks and Security KEYS Integrated Keyhead Transmitters (IKTs) (If equipped) Your vehicle may be equipped with two Integrated Keyhead Transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter.
Page 105 Locks and Security Intelligent Access Key (IA key) (if equipped) Your vehicle may be equipped with two Intelligent Access keys which operate the power locks and the remote entry system. You have to have the IA key in the vehicle to activate the push button start system.
Page 106: Locks
Locks and Security POWER DOOR LOCKS • Press the control to unlock all doors. • Press the control to lock all doors. Smart unlocks This feature helps to prevent you from locking yourself out of the vehicle if your key is still in the ignition. When you open one of the front doors and you lock the vehicle with the power door lock control (on the driver or passenger door trim panel), all the doors will lock, then all doors will automatically unlock reminding...
Page 107 Locks and Security automatically be released when you attempt to close it, and the horn will chirp, as a reminder that the IA key is inside. If you would like to intentionally lock your IA key in the trunk of your vehicle, first disarm the perimeter alarm by unlocking the vehicle, then place the IA key in the trunk, close the trunk, and rearm your perimeter alarm system by locking the vehicle using your keyless entry keypad or another IA key.
Page 108 Locks and Security The autolock feature repeats when: • any door is opened then closed while the ignition is on and the vehicle speed is 9 mph (15 km/h) or lower, and • the vehicle then attains a speed greater than 12 mph (20 km/h). Deactivating/activating autolock feature Your vehicle comes with the autolock features activated;...
Page 109 Locks and Security Keyless entry keypad autolock enable/disable procedure 1. Turn the ignition off. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
Page 110 Locks and Security Note: The autounlock feature can be activated/deactivated independently of the autolock feature. Power door lock switch autounlock enable/disable procedure Before starting, ensure the ignition is off and all vehicle doors are closed. You must complete Steps 1–5 within 30 seconds or the procedure will have to be repeated.
Page 111 Locks and Security Keyless entry keypad autounlock enable/disable procedure 1. Turn the ignition off. 2. Close all the doors. 3. Enter factory–set 5–digit entry code. 4. Press and hold the 3 • 4. While holding the 3 • 4, press and release the 7 •...
Page 112 Locks and Security INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.
Page 113 Locks and Security WARNING: Do not leave children, unreliable adults, or animals unattended in the vehicle. On hot days, the temperature in the trunk or vehicle interior can rise very quickly. Exposure of people or animals to these high temperatures for even a short time can cause death or serious heat-related injuries, including brain damage.
Page 114 Locks and Security Intelligent Access key Refer to Intelligent Access in this section for more features. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The typical operating range for your transmitter is approximately 33 feet (10 meters).
Page 115 Locks and Security Intelligent Access (if equipped) WARNING: Radio waves from the Intelligent Access system transmitters in the vehicle may affect certain implanted medical devices such as pacemakers or cardiac defibrillators. People having such implanted medical devices should ask the medical device manufacturer or their physician whether the Intelligent Access system may affect the equipment before coming into close proximity with a vehicle equipped with Intelligent Access.
Page 116 Locks and Security Push button start: Your vehicle is equipped with a push button start system, which allows you to start your vehicle without using a key. To operate the push button start system and start your vehicle, your IA key must be present inside the vehicle, either in the passenger compartment or in the trunk.
Page 117 Locks and Security Sounding a panic alarm Press to activate the alarm. The horn will sound and the turn lamps will flash for a maximum of three minutes. Press again or turn the ignition on to deactivate, or wait for the alarm to time out in three minutes.
Page 118 Locks and Security 2. Press and hold either the 1 or 2 control on the driver’s door for five seconds. (A tone will be heard after ⁄ seconds when the memory store is done) continue to hold until a second tone is heard after five seconds.
Page 119 Locks and Security 2. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 3. Insert the new battery. Refer to the instructions inside the IKT for the correct orientation of the battery. Press the battery down to ensure that the battery is fully seated in the battery housing cavity.
Page 120 Locks and Security Replacing lost Integrated Keyhead Transmitters (IKTs) or Intelligent Access Keys (IA keys) If you would like to have your IKTs or IA keys reprogrammed because you lost one, or would like to buy additional transmitters you can either reprogram them yourself, or take all transmitters to your authorized dealer for reprogramming.
Page 121 Locks and Security Battery saver The battery saver will shut off the lamps 10 minutes after the ignition has been turned off. • If the dome lamps were turned on using the panel dimmer control, the battery saver will shut them off 10 minutes after the ignition has been turned off.
Page 122 Locks and Security SECURICODE™ KEYLESS ENTRY SYSTEM The keypad, located near the driver’s window, is invisible until touched and then it lights up so you can see and touch the appropriate buttons. Note: If you enter your entry code too fast on the keypad, the unlock function may not work.
Page 123 Locks and Security 4. For memory recall feature, enter the sixth digit 1 • 2 to store driver 1 settings or 3 • 4 to store driver 2 settings. Note: Touching 5 • 6, 7 • 8, or 9 • 0 keypad numbers as a sixth digit will not recall a driver memory setting.
Page 124: Anti-Theft System
Locks and Security two-stage unlocking, refer to the Central Unlocking/Two stage unlocking section earlier in this chapter. To unlock all doors, enter the factory set code or your personal code, then press the 3 • 4 control within five seconds. Note: If equipped with Intelligent Access, if the Intelligent Access Key is within 3 feet (1 meter) of the driver door, your keyless entry keypad code will still function the same way, but the driver’s door will also...
Page 125 Locks and Security engine. If a problem occurs, turn the ignition off, remove all objects on the key chain away from the coded key and restart the engine. Note: Do not leave a duplicate coded key in the vehicle. Always take your keys and lock all doors when leaving the vehicle.
Page 126 Locks and Security Replacement Integrated Keyhead Transmitters (IKT) and coded keys or Intelligent Access Keys Note: Your vehicle comes equipped with two Integrated Keyhead Transmitters (IKTs) or two Intelligent Access Keys. The Integrated Keyhead Transmitter (IKT) functions as both a programmed ignition key that operates all the locks and starts the vehicle, as well as a remote keyless entry transmitter.
Page 127 Locks and Security • If two previously programmed coded keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed. Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition. 2.
Page 128 Locks and Security You must have two previously programmed Intelligent Access Keys inside the vehicle and the new unprogrammed Intelligent Access Keys readily accessible. If two previously programmed keys are not available, you must take your vehicle to your authorized dealer to have the spare key(s) programmed.
Page 129 Locks and Security Note: To program MyKey™ features, refer to MyKey™ in this chapter. MYKEY™ The MyKey™ feature allows you to program a restricted driving mode to promote good driving habits. All but one of the keys programmed to the vehicle can be activated as a MyKey™.
Page 130 Locks and Security Create a MyKey™ To program MyKey™ on one of the keys programmed to the vehicle, insert it into the ignition. (For vehicles equipped with push button start, put the Intelligent Access Key in the backup slot; see the Driving chapter for the location of the backup slot.) Turn the ignition on.
Page 131 Locks and Security 6. Repeat steps 4 and 5 until you are done changing the optional settings. Disable MyKey™ To reset all MyKeys™ as Admin keys do the following: 1. Turn the vehicle on using the Admin key. 2. Press SETUP until PRESS RESET TO CLEAR MYKEY is displayed. 3.
Page 132 Locks and Security Troubleshooting Condition Potential Causes • Key in the ignition is already a Can’t create a MyKey™ MyKey™ • Key in the ignition is the last remaining Admin key (there always has to be at least one Admin key) •...
Page 133 Locks and Security Arming the system When armed, this system will respond if unauthorized entry is attempted. When unauthorized entry occurs, the system will flash the turn signal lamps and will sound the horn. The system is ready to arm whenever the ignition is off. Any of the following actions will prearm the alarm system: •...
Page 134 Locks and Security Disarming the system You can disarm the system by any of the following actions: • Unlock the doors by using your transmitter. • Unlock the doors by using your keyless entry pad. • Unlock the driver door or all doors using the Intelligent Access (if equipped).
Page 135: Seating And Safety Restraints
Seating and Safety Restraints SEATING WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 136 Seating and Safety Restraints To adjust the head restraint, do the following: 1. Adjust the seatback to an upright driving/riding position. 2. Raise the head restraint by pulling up on the head restraint. 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint.
Page 137 Seating and Safety Restraints To remove the adjustable head restraint, do the following: 1. Pull up the head restraint until it reaches the highest adjustment position. 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint.
Page 138 Seating and Safety Restraints WARNING: To minimize the risk of neck injury in the event of a crash, head restraints must be installed properly. Adjusting the front power seat WARNING: Never adjust the driver’s seat or seatback when the vehicle is moving. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 139 Seating and Safety Restraints Press the front portion to tilt the seat. Press the control to move the seat forward, backward, up or down. Press the control to recline the seatback forward or rearward.
Page 140 Seating and Safety Restraints Using the power lumbar support The lumbar control is located on the side of the seat cushion. Press the front of the control to adjust firmness. Press the rear of the control to adjust softness. Press the top of the control to raise the height of the lumbar support.
Page 141 Seating and Safety Restraints To operate the heated seats: Press once to activate the high heat setting (three indicator lights). Continue pressing to scroll through the other settings; medium heat (two indicator lights), low heat (one indicator light) or off. If the engine falls below 350 RPMs while the heated seats are on, the feature will turn itself off and will need to be reactivated.
Page 142 Seating and Safety Restraints To remove an air filter: 1. Remove key from ignition. 2. Push up on the outside rigid edge of the filter until the tabs are released, then rotate the air filter toward the front of the vehicle. 3.
Page 143 Seating and Safety Restraints Memory seats/power mirrors/steering column This system allows automatic positioning of the driver seat, power mirrors, and steering column to two programmable positions. The memory seat control is located on the driver door. • To program position 1, move the driver seat, mirrors and steering column to the desired position using the associated controls.
Page 144 Seating and Safety Restraints The easy entry feature can be turned off or on through the vehicle message center. Refer to Message center in the Driver controls chapter. REAR SEATS Second-row non-adjustable head restraints Your vehicle is equipped with second row outboard head restraints that are non-adjustable.
Page 145 Seating and Safety Restraints To reinstall the non-adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars. 2. Push the head restraint down until it locks. WARNING: The non-adjustable head restraint is a safety device. It should be installed whenever the seat is occupied.
Page 146 Seating and Safety Restraints Armrest pass-through Pull down the door located in back of the armrest in order to store cargo of a longer length such as skis or lumber. Note: Do not exceed 80 lb (36 kg) of weight on the pass-through door. Rear heated seats WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord...
Page 147: Safety Restraints
Seating and Safety Restraints Note: Do not do the following: • Place heavy objects on the seat • Operate the seat heater if water or any other liquid is spilled on the seat. Allow the seat to dry thoroughly. The heated seat control is on the back of the front center console. To operate the heated seats: •...
Page 148 Seating and Safety Restraints Your vehicle’s Personal Safety System consists of: • Driver and passenger dual-stage airbag supplemental restraints. • Front outboard safety belts with pretensioners, energy management retractors (first row only), and safety belt usage sensors. • Driver’s seat position sensor. •...
Page 149 Seating and Safety Restraints Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Positioned up front, it provides valuable information early in the crash event on the severity of the impact. This allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage airbags and safety belt pretensioners.
Page 150 Seating and Safety Restraints restrain children in the rear seat. The sensor also turns off the passenger front airbag and seat-mounted side airbag when the passenger seat is empty to prevent unnecessary replacement of airbag(s) after a collision. Front safety belt usage sensors The front safety belt usage sensors detect whether or not the driver and front outboard passenger safety belts are fastened.
Page 151 Seating and Safety Restraints If any of these things happen, even intermittently, have the Personal Safety System serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision. Safety belt precautions WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 152 Seating and Safety Restraints WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. WARNING: Front and rear seat occupants, including pregnant women, should wear safety belts for optimum protection in an accident.
Page 153 Seating and Safety Restraints Energy management feature — front outboard • This vehicle has a safety belt system with an energy management feature at the front seats to help further reduce the risk of injury in the event of a head-on collision. •...
Page 154 Seating and Safety Restraints How to use the automatic locking mode • Buckle the combination lap and shoulder belt. • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 155 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments for the front outboard seating positions. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To adjust the shoulder belt height, squeeze the button and slide the height adjuster up or down.
Page 156 Seating and Safety Restraints WARNING: Do not use extensions to change the fit of the shoulder belt across the torso. Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If...
Page 157 Seating and Safety Restraints Note: If you are using MyKey™, the Belt-Minder warning will not expire. Refer to MyKey™ in the Locks and security chapter. If... Then... The driver’s and front The Belt-Minder feature will not passenger’s safety belts are activate.
Page 158 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare events” 36700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
Page 159 Seating and Safety Restraints Reasons given... Consider... “I have an airbag” Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE.
Page 160 Seating and Safety Restraints WARNING: While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident. We recommend you leave the Belt-Minder system activated for yourself and others who may use the vehicle.
Page 161: Airbags
Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) The airbag supplemental restraint system (SRS) is designed to work in conjunction with the safety belts to help protect the driver and front outboard passenger from certain upper body injuries. The term “supplemental restraint”...
Page 162 Seating and Safety Restraints WARNING: When possible, all children 12 years old and under should be properly restrained in a rear seating position. WARNING: National Highway Traffic Safety Administration (NHTSA) recommends a minimum distance of at least 10 inches (25 cm) between an occupant’s chest and the driver airbag module. WARNING: Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries.
Page 163 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 164 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 165 Seating and Safety Restraints • diagnostic module. • the electrical wiring which connects the components. • Front passenger sensing system. Refer to Front passenger sensing system later in this chapter. • “Passenger airbag off” or “pass airbag off” indicator lamp. Refer to Front passenger sensing system later in this chapter.
Page 166 Seating and Safety Restraints The front passenger sensing system uses a passenger airbag off or pass airbag off indicator which will illuminate and stay lit to remind you that the front passenger frontal airbag is disabled. The indicator lamp is located on the instrument panel below the audio controls and above the climate controls.
Page 167 Seating and Safety Restraints • If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat. Pass Airbag Off Occupant Passenger Airbag Indicator Light Empty seat Unlit Disabled Small child in child Disabled safety seat or booster Small child with safety...
Page 168 Seating and Safety Restraints Pass Airbag Off Objects Passenger Airbag Indicator Light Small (i.e. three ring Unlit Disabled binder, small purse, bottled water) Medium (i.e. heavy Disabled briefcase, fully packed luggage) Empty seat, or small Disabled to medium object with safety belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following:...
Page 169 Seating and Safety Restraints In case there is a problem with the front passenger sensing system, the airbag readiness lamp in the instrument cluster will stay lit. If the airbag readiness lamp is lit, do the following: The driver and/or adult passengers should check for any objects that may be lodged underneath the front passenger seat or cargo interfering with the seat.
Page 170 Seating and Safety Restraints A difficulty with the system is indicated by one or more of the following: • The readiness light (same light for front and side airbag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is switched on.
Page 171 Seating and Safety Restraints How does the side airbag system work? The design and development of the side airbag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
Page 172 Seating and Safety Restraints WARNING: If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 173 Seating and Safety Restraints WARNING: All occupants of the vehicle including the driver should always wear their safety belts even when an airbag SRS and Safety Canopy system is provided. WARNING: To reduce risk of injury, do not obstruct or place objects in the deployment path of the inflatable Safety Canopy .
Page 174 Seating and Safety Restraints The Safety Canopy system, in combination with safety belts, can help reduce the risk of severe injuries in the event of a significant side impact collision or rollover event. Children 12 years old and under should always be properly restrained in the second row seats.
Page 175 Seating and Safety Restraints WARNING: If the Safety Canopy system has deployed, the Safety Canopy will not function again unless replaced. The Safety Canopy system (including the A, B, C, and D pillar trim and headliner) must be inspected and serviced by an authorized dealer. If the Safety Canopy is not replaced, it will not function again, which will increase the risk of injury in a future collision.
Page 176: Child Restraints
Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Airbag supplemental restraint system (SRS) in this chapter for special instructions about using airbags. Important child restraint precautions WARNING: Always make sure your child is secured properly in a device that is appropriate for their height, age and weight.
Page 177 Seating and Safety Restraints Recommendations for Safety Restraints for Children Recommended Child size, height, weight, or age restraint type Small Children who have outgrown or no Use a children longer properly fit in a child safety belt-positioning seat (generally children who are less booster seat.
Page 178 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether...
Page 179 Seating and Safety Restraints WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision, which may result in serious injury or death.
Page 180 Seating and Safety Restraints If the child is the proper height, age, and weight (as specified by your child safety seat or booster manufacturer), fits the restraint and can be restrained properly, then restrain the child in the child safety seat or with the belt-positioning booster.
Page 181 Seating and Safety Restraints When installing a child safety seat with combination lap/shoulder belts: • Use the correct safety belt buckle for that seating position. • Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 182 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 183 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out. 6. Allow the belt to retract to remove slack. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 184 Seating and Safety Restraints 10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back.
Page 185 Seating and Safety Restraints Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. The LATCH anchors are located at the rear section of the rear seat between the cushion and seatback, below the locator symbols on the seat back.
Page 186 Seating and Safety Restraints WARNING: Never attach two child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death. If you install a child seat with rigid LATCH attachments, and have attached the top tether strap to the proper top tether anchor, do not tighten the tether strap enough to lift the child seat off the vehicle seat...
Page 187 Seating and Safety Restraints Attaching child safety seats with tether straps Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor. Tether straps are available as an accessory for many older safety seats.
Page 188 Seating and Safety Restraints 3. Open the tether anchor cover. 4. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5.
Page 189 Seating and Safety Restraints Although the lap/shoulder belt will provide some protection, children who have outgrown a typical child seat are still too small for lap/shoulder belts to fit properly, and wearing an improperly fitted vehicle safety belt could increase the risk of serious injury in a crash. To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster.
Page 190 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
Page 191 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 192 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. WARNING: Never place, or allow a child to place, the shoulder belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a collision.
Page 193: Tires, Wheels And Loading
Tires, Wheels and Loading INFORMATION ABOUT UNIFORM TIRE QUALITY GRADING Tire Quality Grades apply to new pneumatic passenger car tires. The Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: •...
Page 194 Tires, Wheels and Loading WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 195: Tire Inflation
Tires, Wheels and Loading Increasing the inflation pressure beyond this pressure will not increase the tire’s load carrying capability. • kPa: Kilopascal, a metric unit of air pressure. • PSI: Pounds per square inch, a standard unit of air pressure. •...
Page 196 Tires, Wheels and Loading WARNING: Under-inflation is the most common cause of tire failures and may result in severe tire cracking, tread separation or blowout , with unexpected loss of vehicle control and increased risk of injury. Under-inflation increases sidewall flexing and rolling resistance, resulting in heat buildup and internal damage to the tire.
Page 197 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
Page 198 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 199 Tires, Wheels and Loading U.S. DOT Tire Identification Number (TIN) Both U.S. and Canada Federal regulations require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a U.S. DOT Tire Identification Number for safety standard certification and in case of a recall.
Page 200 Tires, Wheels and Loading WARNING: When mounting replacement tires and wheels, you should not exceed the maximum pressure indicated on the sidewall of the tire to set the beads without additional precautions listed below. If the beads do not seat at the maximum pressure indicated, re-lubricate and try again.
Page 201 Tires, Wheels and Loading • Do not run over curbs or hit the tire against a curb when parking WARNING: If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion.
Page 202 Tires, Wheels and Loading • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/All Wheel Drive (AWD) vehicles (front tires at top of diagram)
Page 203 Tires, Wheels and Loading Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel.
Page 204 Tires, Wheels and Loading 3. 65: Indicates the aspect ratio which gives the tire’s ratio of height to width. 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter.
Page 205 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
Page 206 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 207 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 208: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 209 Tires, Wheels and Loading The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 210 Tires, Wheels and Loading Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The Low Tire Pressure Warning Lamp will turn ON if the tire pressure is significantly low.
Page 211 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
Page 212 Tires, Wheels and Loading Low Tire Possible Customer Action Required Pressure cause Warning Light Flashing Warning Spare tire in Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
Page 213 Tires, Wheels and Loading SNOW TIRES AND CHAINS WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 214: Vehicle Loading
Tires, Wheels and Loading VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 215 Tires, Wheels and Loading WARNING: The appropriate loading capacity of your vehicle can be limited either by volume capacity (how much space is available) or by payload capacity (how much weight the vehicle should carry). Once you have reached the maximum payload of your vehicle, do not add more cargo, even if there is space available.
Page 216 Tires, Wheels and Loading Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 217 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
Page 218 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 219 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity.
Page 220: Trailer Towing
Tires, Wheels and Loading 1,400 - (2 x 220) - (9 x 100) = 1,400 - 440 - 900 = 60 lb. Now you have the load capacity to transport the cement and your friend home. In metric units, the calculation would be: 635 kg - (2 x 99 kg) - (9 x 45 kg) = 635 - 198 - 405 = 32 kg.
Page 221 Tires, Wheels and Loading If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 222: Recreational Towing
Tires, Wheels and Loading • It is recommended to select the “M” gear position when additional engine braking is needed. In situations such as prolonged downhill driving on steep grades (i.e., driving in mountainous areas), additional engine braking is needed to reduce the load on the vehicle’s regular brake system to prevent them from overheating.
Page 223 Tires, Wheels and Loading In case of roadside emergency with a disabled vehicle, please refer to Wrecker towing in the Roadside Emergencies chapter. These guidelines are designed to prevent damage to your vehicle. Front Wheel Drive (FWD) vehicles: Tow your Front Wheel Drive vehicle with all four wheels on the ground or with the front wheels off the ground by using a tow dolly.
Page 224: Driving
Driving STARTING Positions of the ignition (if equipped) If your vehicle is equipped with a push button start system, refer to Push button start system in this section for ignition modes. 1. Off— locks the gearshift lever and allows key removal. This position also shuts the engine and all electrical accessories off.
Page 225 Driving WARNING: Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 226 Driving • Make sure the gearshift lever is in P (Park). 3. Turn the key to 3 (on) without turning the key to 4 (start). If your vehicle is equipped with a push button start system, refer to Push button start system in this section for ignition modes.
Page 227 Driving 1. Turn the key to 3 (on) without turning the key to 4 (start). 2. Turn the key to 4 (start), then release the key as soon as the engine begins cranking. Your vehicle has a computer assisted cranking system that assists in starting the engine.
Page 228 Driving 2. Accessory — press and release the START/STOP button without applying the brake pedal. This allows electrical accessories such as the radio to operate while the engine is not running. ACCESSORY POWER ACTIVE and PRESS BRAKE TO START will be displayed in the message center.
Page 229 Driving into the backup slot, use the START/STOP button and brake pedal to start your vehicle as usual. The vehicle should respond normally as long as the IA key is in the backup slot in the glove box. Once the vehicle is started, the IA key can be removed from the backup slot, if desired.
Page 230 Driving WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least one inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air.
Page 231 Driving • Make certain that the extension cord is in excellent condition (not patched or spliced). Store your extension cord indoors at temperatures above 32°F (0°C). Outdoor conditions can deteriorate extension cords over a period of time. • To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two pronged (cheater) adapters.
Page 232: Brakes
Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by an authorized dealer. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by an authorized dealer.
Page 233 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is switched on. If the light does not illuminate during start up, remains on or flashes, the ABS is disabled due to a malfunction and needs to be serviced. Even when the ABS is disabled, normal braking is still effective.
Page 234: Advancetrac
Driving Press the parking brake pedal downward again to release the parking brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. Note: If the vehicle is driven with the parking brake applied, a chime will sound.
Page 235 Driving WARNING: If a failure has been detected within the AdvanceTrac system, the sliding car icon will illuminate steadily, and you may hear a chime. If equipped with a message center, the vehicle will also indicate a failure with the Brake system, have the system serviced by an authorized dealer immediately.
Page 236 Driving When an event occurs that activates AdvanceTrac you may experience the following: • A slight deceleration of the vehicle • The “sliding car” indicator light will flash. • If your foot is on the brake pedal, a vibration in the pedal •...
Page 237 Driving During Electronic Stability Control events the “sliding car” icon in the instrument cluster will flash. Certain adverse driving maneuvers may activate the Electronic Stability Control system, which include but are not limited to: • Taking a turn too fast •...
Page 238 Driving AdvanceTrac Features “Sliding Control Message Traction car off” switch Mode Center Display Control functions (if equipped) icon Turns on Default at System during Nothing Enabled Enabled start-up Initialization bulb Displayed check Control switch Traction TRACTION pressed CONTROL OFF Enabled Disabled Control OFF once momentarily...
Page 239 Driving WARNING: The EPS system has diagnostics checks that continuously monitor the EPS system to ensure proper operation of the electronic system. When an electronic error is detected, the message POWER STEERING ASSIST FAULT will be displayed in the message center. If this happens, stop the vehicle in a safe place, and turn off the engine.
Page 240: Transmission Operation
Driving • uneven tire wear • loose or worn suspension components • loose or worn steering components • improper vehicle alignment A high crown in the road or high crosswinds may also make the steering seem to wander/pull. BRAKE-SHIFT INTERLOCK This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the on position unless the brake pedal is applied.
Page 241 Driving P (Park) This position locks the transmission and prevents the front wheels from turning. To put your vehicle in gear: • Press the brake pedal • Move the gearshift lever into the desired gear To put your vehicle in P (Park): •...
Page 242 Driving M (Manual) With the gearshift lever in M (manual), the driver can change gears up or down as desired. This is called SelectShift Automatic™ transmission (SST) mode. By moving the gearshift lever from drive position D (Drive) to M (Manual) you now have control of selecting the gear you desire using the paddle shifters on the steering...
Page 243 Driving Paddle shifters The paddle shifters allow you to shift gears quickly, without taking your hands off the steering wheel. 1. To manually downshift the transmission with the gearshift lever in M (Manual), press the paddle shifters forward. 2. To manually upshift the transmission with the gearshift lever in M (Manual), press the paddle shifters rearward.
Page 244: Forward And Reverse Sensing System
Driving FORWARD (IF EQUIPPED) AND REVERSE SENSING SYSTEMS The forward and reverse sensing system will warn the driver of obstacles within a certain range of the front and rear bumpers. The front sensors will be active when the gearshift is in any position other than P (Park) or N (Neutral) and the vehicle speed is below 8 mph (13 km/h).
Page 245 Driving The reverse sensing portion of the system detects obstacles up to 6 ft. (2 m) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the illustration for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.
Page 246 Driving WARNING: This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground.
Page 247: Rear-View Camera System
Driving Note: If the system cannot be turned off, refer to MyKey™ in the Locks and Security chapter for more information. The system defaults to enabled every time the ignition is switched on. Press the control to disable or enable the system Keep the sensors (located on the front and rear bumper/fascia) free from snow, ice and large accumulations of dirt (do not clean the sensors with sharp objects).
Page 248 Driving Use the side mirrors and rearview mirror to get better coverage on both sides and rear of the vehicle. After shifting out of R (Reverse) and into any gear other than P (Park), the image will remain until the vehicle speed reaches five mph (8 km/h), only if the rear camera delay feature is on, or until any navigation radio button is pressed.
Page 249 Driving Night time and dark area use At night time or in dark areas, the camera system relies on the reverse lamp lighting to produce an image. Therefore it is necessary that both reverse lamps are operating in order to get a clear image in the dark. If either of the lamps are not operating, stop using the camera system, at least in the dark, until the lamp(s) are replaced and functioning.
Page 250 Driving Operation The radar sensor detects vehicles ahead that are moving in the same direction as your vehicle. If the radar detects that your vehicle is rapidly closing on another vehicle a red warning light will illuminate and an audible warning chime will sound.
Page 251 Driving WARNING: The collision warning system’s brake support can only help reduce the speed at which a collision occurs if the driver applies the vehicle’s brakes. The brake pedal must be pressed just like for any typical braking situation. Blocked sensor If a message regarding a blocked sensor is displayed, the radar signals from the sensor, located behind a...
Page 252 Driving Note: If the system cannot be turned off in a MyKey™ equipped vehicle, refer to MyKey™ in the Locks and Security chapter for more information. Note: If collision warnings are perceived as being too frequent or disturbing then the warning sensitivity can be reduced, though the manufacturer recommends using the highest sensitivity setting where possible.
Page 253 Driving For best performance, the driver should drive the vehicle as parallel as possible while passing a parking space. If driven too fast (above 18 mph [30 km/h]) for the system to measure parking spaces, the message center will display ACTIVE PARK REDUCE SPEED. When the system has found a space, the message center will display SPACE FOUND PULL FORWARD followed by a chime.
Page 254 Driving When you determine the vehicle is back far enough or you hear a solid tone from Reverse Sensing System, bring the vehicle to a complete stop and move the gearshift to D (Drive). The message center will now display PULL FORWARD USE CAUTION followed by a chime. When you determine the vehicle is far enough forward or a solid tone from Forward Sensing System (if equipped) is heard, bring the vehicle to a complete stop and move the gearshift to R (Reverse).
Page 255 Driving • Exceeding a vehicle speed of 6 mph (10 km/h) during automatic steering. • Deactivating the AdvanceTrac System or the system has activated on a slippery or loose surface. • ABS activation or failure. • Any door (except the driver’s door) opens. •...
Page 256 Driving • There may be an irregular curb along the parking space. APA might not be able to align the vehicle to curbs that are damaged, very shallow or covered with material such as debris, leaves, snow, or tarps. • The vehicles or objects bordering the space may not be positioned appropriately.
Page 257: All Wheel Drive
Driving Driving with blind spot mirrors Before a lane change, check the main mirror first, then check the blind spot mirror. If no vehicles are present in the blind spot mirror and the traffic in the adjacent lane is at a safe distance, signal that you are going to change lanes.
Page 258 Driving If your vehicle is equipped with AWD, a spare tire of a different size other than the tire provided should never be used. If the spare tire is installed, the AWD system may disable automatically and enter front wheel drive only mode to protect driveline components. This condition may be indicated by an AWD OFF message in the message center (see Message center section in the Instrument Cluster chapter for more information).
Page 259 Driving • Be extremely careful when driving on pavement made slippery by loose sand, water, gravel, snow or ice. If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the pavement only after reducing your speed.
Page 260 Driving WARNING: Do not spin the wheels at over 35 mph (56 km/h). The tires may fail and injure a passenger or bystander. Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle (i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency).
Page 261 Driving Mud and water If you must drive through high water, drive slowly. Traction or brake capability may be limited. When driving through water, determine the depth; avoid water higher than the bottom of the wheel rims (if possible) and proceed slowly. If the ignition system gets wet, the vehicle may stall.
Page 262 Driving Driving on hilly or sloping terrain Although natural obstacles may make it necessary to travel diagonally up or down a hill or steep incline, you should always try to drive straight up or straight down. Avoid driving crosswise or turning on steep slopes or hills.
Page 263 Driving Avoid sudden braking as well. Although an AWD vehicle may accelerate better than a two-wheel drive vehicle in snow and ice, it won’t stop any faster, because as in other vehicles, braking occurs at all four wheels. Do not become overconfident as to road conditions. Make sure you allow sufficient distance between you and other vehicles for stopping.
Page 264 Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 265: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 266: Hazard Flasher Control
Roadside Emergencies • towing of your disabled vehicle • emergency travel expense reimbursement • travel planning benefits In Canada, for uninterrupted Roadside Assistance coverage, you may purchase extended coverage prior to your Basic Warranty’s Roadside Assistance expiring. For more information and enrollment, contact 1–877–294–2582 or visit our website at www.ford.ca.
Page 267: Fuses And Relays
Roadside Emergencies FUEL PUMP SHUT-OFF In the event of a moderate to severe collision, this vehicle is equipped with a fuel pump shut-off feature that stops the flow of fuel to the engine. Not every impact will cause a shut-off. Note: If your vehicle has the push button start system, press the stop/start button twice to reactivate the fuel system.
Page 268 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 269 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located under the instrument panel to the left of the steering wheel. The fuses are coded as follows. Fuse/Relay Fuse Amp Protected Components Location Rating Right rear window Not used (spare) Driver seat control/lumbar Right front window Brake-shift interlock (BSI),...
Page 270 Roadside Emergencies Fuse/Relay Fuse Amp Protected Components Location Rating Courtesy lamps Illumination switch, Puddle lamps All wheel d rive (AWD) 7.5A Passive entry/passive start (PEPS) module Memory/seats/mirrors/steering column, keypad, Driver zone module Center information display, SYNC , GPS Climate control Electronic finish panel (EFP), Ambient lighting Global windows, door locks and...
Page 271 Roadside Emergencies Fuse/Relay Fuse Amp Protected Components Location Rating Restraint control module Adaptive Lighting AdvanceTrac, Adaptive cruise control module, Electronic power assist steering AWD, DHRSM, Absolute steering angle switch, Park aid (run/start) Passive anti-theft system (PATS) module Not used (spare) Amplifier (THX or 6 channel) Radio/Navigation Amplifier (THX or 2 channel)
Page 272 Roadside Emergencies WARNING: To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp...
Page 273 Roadside Emergencies Fuse/Relay Fuse Amp Protected Components Location Rating 40A** Anti-lock brake system (ABS) pump 30A** Starter relay 30A** Powertrain control module (PCM) relay 20A** ABS valve 15A* Adapt cruise 10A* Brake on/off switch 15A* Auto high beam 20A* Left high intensity discharge (HID) headlamp 10A* Alternator sense...
Page 274 Roadside Emergencies Fuse/Relay Fuse Amp Protected Components Location Rating 40A** Front A/C blower motor 20A* Passenger compartment fuse panel run/start 10A* PCM run/start Delayed accessory Diode Fuel pump diode Diode One-touch integrated start (OTIS) diode G8VA relay A/C clutch G8VA relay Fuel pump G8VA relay Backup...
Page 275: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Protected Components Location Rating Half ISO relay Run/start relay Half ISO relay PCM relay — Not used — Not used * Mini Fuse **Cartridge Fuse CHANGING THE TIRES If you get a flat tire while driving: •...
Page 276 Roadside Emergencies If you have a dissimilar spare tire/wheel, then it is intended for temporary use only. This means that if you need to use it, you should replace it as soon as possible with a road tire/wheel that is the same size and type as the road tires and wheels that were originally provided by Ford.
Page 277 Roadside Emergencies • Use commercial car washing equipment • Use snow chains on the end of the vehicle with the dissimilar spare tire/wheel The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance •...
Page 278 Roadside Emergencies Removing the spare tire and jack 1. Lift the trunk cargo cover, and remove the wing nut that secures the spare tire by turning it counterclockwise. 2. Lift and remove the spare tire from the trunk. 3. Remove the second wing nut that secures the jack retention bracket by turning it counterclockwise, remove the jack kit from the...
Page 279 Roadside Emergencies WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 280 Roadside Emergencies 3. Align the slot on top of the jack with the sheet metal flange indicated by the jack locator triangle next to the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground.
Page 281: Stowing The Tire And Jack
Roadside Emergencies Stowing the tire and jack 1. Fully collapse the jack, fold the lug wrench socket into the handle and place the jack and wrench into the felt bag as shown. Place the extension bolt into the external pocket of the felt bag. Take care to position the jack as shown to ensure that the locating holes in the jack base can be placed on the locating...
Page 282: Wheel Lug Nut Torque
Roadside Emergencies If you are stowing the flat tire: 1. Remove the extension bolt from the exterior pocket of the felt bag. 2. Install the jack as shown in Step 4 under Stowing the tire and jack. 3. Screw the extension bolt onto the threaded stud of the jack retention bracket.
Page 283: Jump Starting
Roadside Emergencies Note: Inspect the wheel pilot hole prior to installation. If there is visible corrosion in wheel pilot hole, remove loose particles by wiping with clean rag and apply grease. Apply grease only to the wheel pilot hole surface by smearing a “dime” (1 square cm) sized glob of grease around the wheel pilot surface (1) with end of finger.
Page 284 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the automatic transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 285 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 286 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Note: Do not attach the negative (-) cable to fuel lines, engine rocker covers, the intake manifold or electrical components as grounding points.
Page 287 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 288 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 289: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment.
Page 290 Roadside Emergencies If the vehicle is towed by other means or incorrectly, vehicle damage may occur. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle. Emergency towing In case of a roadside emergency with a disabled vehicle (without access to wheel dollies, car hauling trailer, or flatbed transport vehicle) your...
Page 291: Customer Assistance
Customer Assistance GETTING THE SERVICES YOU NEED Warranty repairs to your vehicle must be performed by an authorized Ford, Lincoln, or Mercury dealer. While any authorized dealer handling your vehicle line will provide warranty service, we recommend you return to your selling authorized dealer who wants to ensure your continued satisfaction.
Page 292 Customer Assistance In Canada: Mailing address (Ford vehicles) Customer Relationship Centre Ford Motor Company of Canada, Limited P.O. Box 2000 Oakville, Ontario L6J 5E4 Telephone 1-800-565-3673 (FORD) Online www.ford.ca Mailing address (Lincoln vehicles) Lincoln Centre Ford Motor Company of Canada, Limited P.O.
Page 293 Customer Assistance In the United States, a warranty dispute must be submitted to the BBB AUTO LINE before taking action under the Magnuson-Moss Warranty Act, or to the extent allowed by state law, before pursuing replacement or repurchase remedies provided by certain state laws. This dispute handling procedure is not required prior to enforcing state created rights or other rights which are independent of the Magnuson-Moss Warranty Act or state replacement or repurchase laws.
Page 294 Customer Assistance THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
Page 295 Customer Assistance UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 296 Customer Assistance If your vehicle must be serviced while you are traveling or living in Central America, the Caribbean, or the Middle East, contact the nearest authorized dealer. If the authorized dealer cannot help you, contact: FORD MOTOR COMPANY FORD EXPORT OPERATIONS 1555 Fairlane Drive Fairlane Business Park #3 Allen Park, Michigan 48101...
Page 297: Reporting Safety Defects (U.s. Only)
Customer Assistance Obtaining a French Owner’s Guide French Owner’s Guides can be obtained from your authorized dealer or by writing to: Ford Motor Company of Canada, Limited Service Publications CHQ202 The Canadian Road P.O. Box 2000 Oakville, ON, Canada L6J 5E4 REPORTING SAFETY DEFECTS (U.S.
Page 298: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 299 Cleaning WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
Page 300 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 301 Cleaning 3.5L V6 ECOBOOST ENGINE PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 302 Cleaning • The wiper blades can be cleaned with isopropyl (rubbing) alcohol or Motorcraft Premium Windshield Washer Concentrate (ZC-32-A), available from your authorized dealer. This washer fluid contains special solution in addition to alcohol which helps to remove the hot wax deposited on the wiper blade and windshield from automated car wash facilities.
Page 303 Cleaning If a staining liquid like coffee/juice has been spilled on the instrument panel or on interior trim surfaces, clean as follows: 1. Wipe up spilled liquid using a clean, white, cotton cloth. 2. Wipe the surface with a damp, clean, white cotton cloth. For more thorough cleaning, use a mild soap and water solution.
Page 304 Cleaning LEATHER SEATS Your leather seating surfaces have a clear, protective coating over the leather. • For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a mild soap and water solution.
Page 305 Cleaning Motorcraft Premium Glass Cleaner (Canada only) (CXC-100) Motorcraft Premium Liquid Wax (ZC-53-A) Motorcraft Premium Windshield Washer Concentrate (U.S. only) (ZC-32-A) Motorcraft Professional Strength Carpet & Upholstery Cleaner (ZC-54) Motorcraft Spot and Stain Remover (U.S. only) (ZC-14) Motorcraft Tire Clean and Shine (ZC-28) Motorcraft Ultra-Clear Spray Glass Cleaner (ZC-23) Motorcraft Vinyl Cleaner (Canada only) (CXC-93) Motorcraft Wheel and Tire Cleaner (ZC-37-A)
Page 306: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Customer Information Guide to find out which parts and services are covered.
Page 307 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located at the bottom of the instrument panel near the steering column. 2. Go to the front of the vehicle and release the auxiliary latch using the handle that is located under the front passenger side of the hood.
Page 308: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.7L V6 Duratec engine 1. Power steering fluid reservoir 2. Engine coolant reservoir 3. Brake fluid reservoir 4. Battery 5. Power distribution box 6. Air filter assembly 7. Automatic transmission fluid dipstick 8.
Page 309 Maintenance and Specifications 3.5L V6 EcoBoost engine 1. Engine coolant reservoir 2. Brake fluid reservoir 3. Battery 4. Power distribution box 5. Air filter assembly 6. Automatic transmission fluid dipstick (out of view) 7. Engine oil dipstick 8. Engine oil filler cap 9.
Page 310 Maintenance and Specifications Engine shield Some vehicles may be equipped with an aero-shield under the engine. This shield needs to be removed for service, including oil and filter changes. It is secured with four screws. WINDSHIELD WASHER FLUID Add fluid to fill the reservoir if the level is low.
Page 311: Engine Oil
Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper blade and arm away from the glass. 2. Squeeze the locking tabs to release the blade from the arm and pull the blade away from the arm to remove it. 3.
Page 312 Maintenance and Specifications 5. Locate and carefully remove the engine oil level dipstick. 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is within this range, the oil level is acceptable. DO NOT ADD OIL.
Page 313 Maintenance and Specifications • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by an authorized dealer. 7. Put the dipstick back in and ensure it is fully seated. Adding engine oil 1.
Page 314: Battery
Maintenance and Specifications Use SAE 5W-20 engine oil Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). An oil with this trademark symbol conforms to the current engine and emission system protection standards and fuel economy requirements of the International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S.
Page 315 Maintenance and Specifications For longer, trouble-free operation, keep the top of the battery clean and dry. Also, make certain the battery cables are always tightly fastened to the battery terminals. If you see any corrosion on the battery or terminals, remove the cables from the terminals and clean with a wire brush.
Page 316: Engine Coolant
Maintenance and Specifications the battery is disconnected or a new battery is installed, the engine must relearn its idle and fuel trim strategy for optimum driveability and performance. To begin this process: 1. With the vehicle at a complete stop, set the parking brake. 2.
Page 317 Maintenance and Specifications which equates to a freeze point of -34°F (-36°C). Coolant concentration testing is possible with a hydrometer or antifreeze tester. The level of coolant should be maintained at the FULL COLD level or within the COLD FILL RANGE in the coolant reservoir. If the level falls below, add coolant per the instructions in the Adding engine coolant section.
Page 318 Maintenance and Specifications Adding engine coolant When adding coolant, make sure it is a 50/50 mixture of engine coolant and distilled water. Add the mixture to the coolant reservoir, when the engine is cool, until the appropriate fill level is obtained. WARNING: Do not add engine coolant when the engine is hot.
Page 319 Maintenance and Specifications WARNING: To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Add the proper mixture of coolant and water to the cooling system by following these steps: 1.
Page 320 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Maintenance product specifications and capacities in this chapter.
Page 321 Maintenance and Specifications What you should know about fail-safe cooling (if equipped) If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 322: Fuel Information
Maintenance and Specifications WARNING: Never remove the coolant reservoir cap while the engine is running or hot. 5. Re-start the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible.
Page 323 Maintenance and Specifications • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent.
Page 324 Maintenance and Specifications Refueling WARNING: Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 325 Maintenance and Specifications Note: A fuel spillage concern may occur if overfilling the fuel tank. Do not overfill the tank to the point that the fuel is able to bypass the fuel filler nozzle. The overfilled fuel may run down the drain located within the fuel filler housing and to the ground.
Page 326 Maintenance and Specifications 3.5L V6 EcoBoost engine Your vehicle is designed to run on regular fuel with an octane rating of 87 or higher. For best overall performance, premium fuel with an octane rating of 91 or higher is recommended. The performance gained by using premium fuel will be most noticeable in hot weather or in severe duty applications such as towing a trailer.
Page 327 Maintenance and Specifications If you have run out of fuel: • You may need to cycle the ignition from off to on several times after refueling to allow the fuel system to pump the fuel from the tank to the engine. On restarting, cranking time will take a few seconds longer than normal.
Page 328 Maintenance and Specifications 2. Slowly insert the funnel into the Easy Fuel™ system. 3. Fill the vehicle with fuel from the portable fuel container. 4. When done, clean the funnel or properly dispose of it. Extra funnels can be purchased from your authorized dealer if you choose to dispose of the funnel.
Page 329 Maintenance and Specifications The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range. When refueling your vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank.
Page 330 Maintenance and Specifications Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. Habits • Smooth, moderate operation can yield up to 10% savings in fuel. •...
Page 331 Maintenance and Specifications • Carrying unnecessary weight may reduce fuel economy (approximately 1 mpg [0.4 km/L] is lost for every 400 lb [180 kg] of weight carried). • Adding certain accessories to your vehicle (for example bug deflectors, rollbars/light bars, running boards, ski racks) may reduce fuel economy.
Page 332 Maintenance and Specifications emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability. WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
Page 333 Maintenance and Specifications 3. The fuel fill inlet may not have been properly closed. See Easy Fuel™ “no cap” fuel system in this chapter. 4. Driving through deep water—the electrical system may be wet. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly closing the fuel fill inlet or letting the electrical system dry out.
Page 334 Maintenance and Specifications The OBD-II system is designed to check the emission control system during normal driving. A complete check may take several days. If the vehicle is not ready for I/M testing, the following driving cycle consisting of mixed city and highway driving may be performed: 15 minutes of steady driving on an expressway/highway followed by 20 minutes of stop-and-go driving with at least four 30-second idle periods.
Page 335 Maintenance and Specifications BRAKE FLUID The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the MIN and MAX lines are within the normal operating range; there is no need to add fluid.
Page 336 Maintenance and Specifications 6. Install the dipstick making sure it is fully seated in the filler tube. 7. Remove the dipstick and inspect the fluid level. The fluid should be in the designated areas for normal operating temperature. Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick.
Page 337: Air Filter(S)
Maintenance and Specifications If an overfill occurs, excess fluid should be removed by an authorized dealer. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. Do not use supplemental transmission fluid additives, treatments or cleaning agents.
Page 338 Maintenance and Specifications Changing the air filter element 3.7L V6 engine 3.5L V6 EcoBoost engine 1. Release the clamps that secure the air filter housing cover. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the air filter housing. 4.
Page 339: Part Numbers
Maintenance and Specifications 6. Replace the air filter housing cover and secure the clamps. Be sure that the air cleaner cover tabs are engaged into the slots of the air cleaner housing. Note: Failure to use the correct air filter element may result in severe engine damage.
Page 340: Maintenance Product Specifications And Capacities
Maintenance and Specifications...
Page 341 Maintenance and Specifications...
Page 342 Maintenance and Specifications...
Page 343: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.7L V6 engine 3.5L V6 EcoBoost engine Cubic inches See Octane See Octane Fuel recommendations earlier recommendations earlier in this chapter. in this chapter. Firing order 1–4–2–5–3–6 1–4–2–5–3–6 0.052–0.056 inch 0.033–0.037 inch (.838– Spark plug gap (1.32–1.42 mm) .939 mm) Ignition system...
Page 344 Maintenance and Specifications 3.5L V6 EcoBoost engine IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located.
Page 345 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is located on the driver side instrument panel. XXXXXXXXXXXXXXXXX Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 346 Maintenance and Specifications TRANSMISSION CODE DESIGNATIONS You can find a transmission code on the Safety Compliance Certification Label. The following table tells you which transmission each code represents. Description Code 6F 6-Speed Automatic Transmission 6F55 6-Speed Automatic Transmission (with EcoBoost)
Page 347: Accessories
Accessories GENUINE LINCOLN ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Lincoln Accessories are available for your vehicle through your local Lincoln or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 348 Accessories Peace of mind Remote start Wheel locks Locking gas plug For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 349: Ford Extended Service Plan
Ford Extended Service Plan FORD ESP EXTENDED SERVICE PLANS More than 30 million Ford, Lincoln, and Mercury owners have discovered the powerful protection of Ford ESP. It is the only extended service plan backed by Ford Motor Company, and provides “peace of mind” protection beyond the New Vehicle Limited Warranty coverage.
Page 350 Ford Extended Service Plan Ford ESP Can Quickly Pay for Itself One service bill – the cost of parts and labor – can easily exceed the price of your Ford ESP Service Contract. With Ford ESP, you minimize your risk for unexpected repair bills and rising repair costs. Avoid the rising cost of properly maintaining your vehicle! Ford ESP also offers a Premium Maintenance Plan that covers items that routinely wear out, like brakes and shocks.
Page 351 Ford Extended Service Plan...
Page 352: Index
Index fluid, adding ......335 fluid, checking ......335 Selectshift (SST) ....242 Accessory delay ......77 Auxiliary input jack (Line in) ..39 Active Park Assist .....252 Adaptive Cruise Control .....81 AdvanceTrac ......234 Battery ........314 Air cleaner filter ....337–339 acid, treating emergencies ..314 Air conditioning ....48, 51 jumping a disabled battery ..283 maintenance-free ....314 Airbag supplemental restraint...
