Samsung SyncMaster 400MX User Manual
Hide thumbs Also See for SyncMaster 400MX:

Advertisement

Quick Links

SyncMaster 400MX,460MX,400MXn,460MXn

LCD Monitor

User Manual

Advertisement

Table of Contents
loading

Summary of Contents for Samsung SyncMaster 400MX

  • Page 1: Lcd Monitor

    SyncMaster 400MX,460MX,400MXn,460MXn LCD Monitor User Manual...
  • Page 2: Safety Instructions

    Safety Instructions Notational Note These safety instructions must be followed to ensure your safety and prevent property dam- age. Make sure to read the instructions carefully and use the product in the correct manner. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.
  • Page 3: Installation

    Safety Instructions Ensure that the power plug is plugged into the power outlet firmly and correctly. • Otherwise, this may result in fire. Do not forcefully bend or pull the power plug and do not place any heavy material on it. •...
  • Page 4 Safety Instructions Keep heating appliances as far away from the power cord or the product as possible. • Otherwise, this may result in electric shock or fire. Do not install it in a badly ventilated location such as a bookcase or closet.
  • Page 5 Safety Instructions When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth. • Otherwise, it may result in fire. When cleaning the product, make sure to disconnect the power cord. • Otherwise, it may result in electric shock or fire. When cleaning the product, disconnect the power cord and clean it softly with a dry cloth.
  • Page 6 Safety Instructions If thunder or lightening is occurring, do not touch the power cord or antenna cable. • Otherwise, this may result in electric shock or fire. Do not try to move the monitor by pulling only the wire or the signal cable.
  • Page 7 Safety Instructions If you continually move closer to the product screen, your eye- sight may be failing. Take a rest for at least five (5) minutes after using the monitor for one (1) hour. This reduces the weariness of your eyes. Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.
  • Page 8 Safety Instructions The batteries (and rechargeable batteries) are not ordinary re- fuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling. • The customer can return used or rechargeable batteries to a nearby public recycling center or to a store selling the same type of the battery or rechargeable battery.
  • Page 9: Package Contents

    Introduction Package Contents Note Please make sure the following items are included with your LCD Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Note This stand is not for the Floor Standing Type. Unpacking LCD Display Manuals...
  • Page 10 Introduction Others Remote Control Batteries (AAA X 2) HDD Cover (Not available in all loca- tions) Sold separately DVI Cable Wall Mount KIT LAN Cable (Applicable to the MXn model only) TV tuner box NetWork Box Semi Stand KIT (Applicable to the MX mod- el only) Note •...
  • Page 11 Introduction Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values. Adjust buttons (Left-Right buttons) / Volume buttons Moves from one menu item to another horizontally or adjusts selected menu values.
  • Page 12 Introduction POWER S/W ON [ │ ] / OFF [O] Switches the LCD Display On/Off. POWER IN The power cord plugs into the LCD Display and the wall plug. RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC / HDMI IN [DVI/PC/HDMI AU- DIO IN] (PC/DVI/HDMI Audio Connection Terminal (Input)) DVI / PC / HDMI IN [HDMI]...
  • Page 13 Introduction Using a DVI Cable (DVI-D to DVI-D) - DVI mode (Digital PC) DC OUT [5V/1.5A] Connect this to the power connector of a TV tuner box or network box. Make sure to use connecting DC-OUT terminal to the authorized TV-Tuner Box [SBB-DT*].
  • Page 14: Remote Control

    Introduction Kensington Lock The Kensington Lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustra- tion depending on the manufacturer.
  • Page 15 Introduction POWER Number Buttons button + VOL - MUTE TV/DTV MENU INFO COLOR BUTTONS TTX/MIX STILL AUTO S.MODE LOCK SOURCE ENTER/PRE-CH CH/P D.MENU GUIDE RETURN Up-Down Left-Right buttons EXIT MagicInfo P.MODE DUAL/MTS SWAP Turns the product On. POWER Turns the product Off. 3.
  • Page 16 Introduction 5. + VOL - Adjusts the audio volume. Pauses (mutes) the audio output temporarily. This is dis- MUTE played on the lower left corner of the screen. The audio resumes if MUTE or - VOL + is pressed in the Mute mode. 7.
  • Page 17 Introduction Returns to the previous menu. RETURN 24. Up-Down Left-Right but- Moves from one menu item to another horizontally, vertically tons or adjusts selected menu values. Exits from the menu screen. EXIT SRS TS XT 27.MagicInfo MagicInfo Quick Launch Button. 28.
  • Page 18 Introduction Mechanical Layout (400MX, 400MXn) Mechanical Layout LCD Display Head...
  • Page 19: Installation Vesa Bracket

    • At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion.
  • Page 20: Wall Bracket Installation

    • Contact a technician for installing the wall bracket. • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
  • Page 21 Introduction Insert and tighten the Captive Screw in the direction of the arrow. When done, mount the wall bracket on the wall. There are two hinges(left and right). Use the correct one. Captive Screw Wall Bracket Hinge (Left) Hinge (Right) Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct.
  • Page 22: To Mount The Product On The Wall Bracket

    Introduction To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product. Insert the screw B into the plastic hanger.
  • Page 23: Wall Bracket Angle Adjustment

    Introduction Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. LCD Display Wall Bracket Wall...
  • Page 24: Mechanical Layout

    Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle. Mechanical Layout (460MX, 460MXn) Mechanical Layout LCD Display Head...
  • Page 25 • At least 2 persons are needed in order to move the LCD Display. • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion.
  • Page 26 • Contact a technician for installing the wall bracket. • SAMSUNG Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. • This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
  • Page 27 Introduction There are two hinges(left and right). Use the correct one. Captive Screw Wall Bracket Hinge (Left) Hinge (Right) Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct. If the length is too short or long, loosen all or some of the 4screws on the wall bracket to adjust the length.
  • Page 28 Introduction To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product. Insert the screw B into the plastic hanger.
  • Page 29 Introduction Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. LCD Display Wall Bracket Wall...
  • Page 30 Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle.
  • Page 31: Connecting A Computer

    Connections Connecting a Computer Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance.
  • Page 32: Connecting To Other Devices

    Turn on both your computer and the LCD Display. • The DVI cable is optional. • Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power.
  • Page 33: Connecting To A Camcorder

    Connections Connecting to a Camcorder Locate the AV output jacks on the camcorder. They are usually found on the side or back of the camcorder. Connect a set of audio cables between the AUDIO OUTPUT jacks on the camcorder and the AV AUDIO IN [L-AUDIO-R] on the LCD Display . Connect a video cable between the VIDEO OUTPUT jack on the camcorder and the AV IN [VIDEO] on the LCD Display .
  • Page 34: Connecting Using A Dvi To Hdmi Cable

    Connections Connecting Using a DVI to HDMI Cable Note • Connect the DVI output terminal of a digital output device to the HDMI terminal of the LCD Display using a DVI to HDMI cable. • Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored audio output terminals of the digital output device, and connect the opposite jack to the DVI / PC / HDMI AUDIO IN terminal of the LCD Display.
  • Page 35: Connecting A Usb Device

    Connections Note Connect the LAN cable. (Applicable to the MXn model only) Connecting a USB device Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance.
  • Page 36: Using The Software

    Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung.com/ (Worldwide) Installing the Monitor Driver (Automatic) Insert CD into the CD-ROM drive. Click "Windows".
  • Page 37: Installing The Monitor Driver (Manual)

    Using the Software Note This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Installing the Monitor Driver (Manual) ® Microsoft Windows Vista™‚ Operating System Insert your Manual CD into your CD-ROM drive.
  • Page 38 This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage. Click "Update Driver..." in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
  • Page 39 Using the Software Select the model that matches your monitor from the list of monitor models on the screen, and click "Next". 10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System...
  • Page 40 Using the Software Insert CD into the CD-ROM drive. Click "Start" → "Control Panel" then click the "Appearance and Themes" icon. Click "Display" icon and choose the "Settings" tab then click "Advanced...". Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver..."...
  • Page 41 If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button. Note This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Click the "Close" button then click "OK" button continually.
  • Page 42 Using the Software 10. Monitor driver installation is completed. ® ® Microsoft Windows 2000 Operating System When you can see "Digital Signature Not Found" on your monitor, follow these steps. Choose "OK" button on the "Insert disk" window. Click the "Browse" button on the "File Needed" window. Choose A:(D:\Driver) then click the "Open"...
  • Page 43 Using the Software Select the "Monitor" tab. Click the "Change" button in the "Monitor Type" area. Choose "Specify the location of the driver". Choose "Display a list of all the driver in a specific location..." then click "Next" button. Click the "Have Disk" button. Specify A:\(D:\driver) then click "OK"...
  • Page 44 Using the Software 10. You have finished setting up your monitor. Execute X-Window after setting other re- quested hardware.
  • Page 45: Main Screen

    Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.
  • Page 46: Port Selection

    Main Icons Select Button Remocon Info Grid Safety Lock Display Selection Port Selection Control Tools 1. Use the main icons to switch into each screen. 2. Allows you to enable or disable the remote control signal receiving function of the display unit. 3.
  • Page 47: Power Control

    1. The Multiple Display Control is originally set to COM1. 2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu. 3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.
  • Page 48 Info Grid shows some basic information necessary to Power Control. (Power Status) 2) Input 3) Image Size 4) On Timer 5) Off Timer 2. Use the Select All button or Check Box to choose a display to control. Power Control allows controlling some of the functions of the selected display. 1) Power On/Off...
  • Page 49: Input Source

    - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider. (When you cancel the selection or choose Select All, the value returns to the default value 10) (Mute On/Off) - Turns on/off the Mute function of the selected display.
  • Page 50: Image Size

    Info Grid shows some basic information necessary to Input Source Control. - Changes the Input Source of the selected display to PC. - Changes the Input Source of the selected display to BNC. - Changes the Input Source of the selected display to DVI. - Changes the Input Source of the selected display to TV.
  • Page 51 Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display. 2) Image Size - Shows the current Image Size of the display in use. 3) Input - Shows the current Input Source of the display in use. 4) Info Grid displays only the displays whose Input Source is PC, BNC, DVI.
  • Page 52 Info Grid shows some basic information necessary to Image Size Control. 1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV. Click Select All or use Check Box to select a display to control. 2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.
  • Page 53: Pip Size

    Info Grid shows some basic information necessary to Time Control. 1) Current Time - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) On Time Setup - Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display. 3) Off Time Setup - Set the Hour, Minute, and AM/PM, Status for Off Time Setup of the selected display.
  • Page 54: Pip Source

    Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use. 2) OFF - Turns off the PIP of the selected display. 3) Large - Turns on the PIP of the selected display and changes the size to Large. 4) Small - Turns on the PIP of the selected display and changes the size to Small.
  • Page 55 Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC. 3) BNC - Changes the source of the PIP of the selected display to BNC.
  • Page 56: Picture Pc

    Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide.When selected, each function fetches the value for the set and displays it on the slide bar. When "Select All" is chosen, the default value is displayed.
  • Page 57 1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide. When selected, each function fetches the value for the set and displays it on the slide bar.
  • Page 58: Image Lock

    Settings Audio 1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide. When selected, each function fetches the value for the set and displays it on the slide bar.
  • Page 59: Maintenance

    Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display. 4) Position - Adjusts Position of the selected display. 5) Auto Adjustment - Self-Adjust to the incoming PC signal.
  • Page 60 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Auto Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. 3) Manual Lamp Control - Allows you to adjust the backlight of the selected display regardless of the time.
  • Page 61: Video Wall

    1) Scroll - This function is used to remove the afterimages that occur when a still screen is displayed on the selected display for a long time. 2) Pixel Shift - This allows the screen to be moved finely at the specified time interval. 3) Safety Screen - The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the monitor for a long time.
  • Page 62: Troubleshooting

    Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The MDC program supplied by Samsung supports up to 5x5 LCD Displayes. 3) On / Off - Turns on/off the Video Wall function of the selected display.
  • Page 63: Settings Value Display In Multiple Display Mode

    - Check the displays to see if any of the other displays connected have the same ID. If more than one displays have the same ID, those displays are not properly detected by the program due to data conflict. - Check if the Display Set ID is a number between 0 and 25. (Adjust using the Display menu) Note : A Display Set ID must be a value between 0 and 25 .
  • Page 64: Adjusting The Lcd Display

    Adjusting the LCD Display Input Available Modes • PC / DVI • • HDMI • MagicInfo • Note • The TV menu is available when a TV tuner box is installed. • MX model can use MagicInfo menu when mounted Network box. Source List MENU →...
  • Page 65 Adjusting the LCD Display → ENTER → Name the input device connected to the input jacks to make your input source selection easier. HDMI Note • When connecting a PC to the HDMI or DVI terminal, set Edit Name to PC. In other cases, set Edit Name to AV.
  • Page 66 Adjusting the LCD Display → ENTER → MagicBright is a feature providing the optimum viewing environment depending on the con- tents of the image you are watching. Currently four different modes are available: Entertain, Internet, Text and Custom. Each mode has its own pre-configured brightness value. You can easily select one of the four settings by simply pressing the MagicBright control button.
  • Page 67 Adjusting the LCD Display → ENTER → , Adjusts the Contrast. Brightness MENU → → ENTER → → ENTER → → ENTER → → → → ENTER → , Adjusts the Brightness. Sharpness MENU → → ENTER → → ENTER → →...
  • Page 68 Adjusting the LCD Display If you set the Color Tone to Off, the Color Control function is disabled Color Control Adjusts individual Red, Green, Blue color balance. MENU → → ENTER → → → ENTER → → → (Not available in Dynamic Contrast mode of On.) Note If you adjust the picture by using the Color Control function, Color Tone will turn to the Cus- tom mode.
  • Page 69 Adjusting the LCD Display Image Lock Image Lock is used to fine-tune and get the best image by removing noise that creates un- stable images with jitters and shakiness. If satisfactory results are not obtained using the Fine adjustment, use the Coarse adjustment and then use Fine again. (Available in PC mode only) MENU →...
  • Page 70 Adjusting the LCD Display Auto Adjustment MENU → → ENTER → → ENTER → → → → → → The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution in the control panel, the auto function is performed. (Available in PC mode only) Note The direct button on the remote control is the 'AUTO' button.
  • Page 71 Adjusting the LCD Display MENU → → ENTER → → ENTER → → → → → → → → ENTER → → → ENTER→ → EN- → → ENTER → , B-Gain MENU → → ENTER → → ENTER → →...
  • Page 72 Adjusting the LCD Display → ENTER → The Size can be switched. 16:9 Dynamic Contrast MENU → → ENTER → → → → → → → ENTER → → → → → ENTER → Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast.
  • Page 73 Adjusting the LCD Display • MX model can use MagicInfo menu when mounted Network box. Mode MENU → → ENTER → → ENTER → → ENTER → The LCD Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and "Custom") that are preset at the factory. Dynamic, Standard, Movie, or Custom can be activated.
  • Page 74 Adjusting the LCD Display → ENTER → , Adjusts the Brightness. Sharpness MENU → → ENTER → → ENTER → → ENTER → → → → → ENTER → , Adjusts the picture Sharpness. Color MENU → → ENTER → →...
  • Page 75: Color Temp

    Adjusting the LCD Display (Not available in Dynamic Contrast mode of On.) Cool2 Cool1 Normal Warm1 Warm2 Note If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp function is disabled. Color Temp MENU → →...
  • Page 76 Adjusting the LCD Display Just Scan: Displays the input scenes as they are without any cutoff when HDMI 720p, 1080i, 1080p signals are input. (Not available in Dynamic Contrast mode of On.) Note Certain external devices may feed the display an out of spec signal that may cause cutoff even when using the Just Scan feature.
  • Page 77 Adjusting the LCD Display Dynamic Contrast MENU → → ENTER → → ENTER → → → → → → → → → ENTER → Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast. Brightness Sensor MENU →...
  • Page 78 Adjusting the LCD Display Note • The TV menu is available when a TV tuner box is installed. • MX model can use MagicInfo menu when mounted Network box. Mode MENU → → → ENTER → → ENTER → → ENTER →...
  • Page 79 Adjusting the LCD Display → ENTER → , Emphasizes low frequency audio. Treble MENU → → → ENTER → → → ENTER → → ENTER → → → ENTER → , Emphasizes high frequency audio. Balance MENU → → → ENTER → →...
  • Page 80 Adjusting the LCD Display → ENTER → SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround delivers a compelling, virtual surround sound ex- perience through any two-speaker playback system, including internal television speakers. It is fully compatible with all multichannel formats.
  • Page 81 Adjusting the LCD Display Time Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer. MENU → → → → ENTER → → ENTER → → Clock Set MENU → → ENTER → → ENTER → →...
  • Page 82 Adjusting the LCD Display → ENTER → Turns the LCD Display on automatically at a preset time. Controls the mode and the volume level at the time the LCD Display turns on automatically. Off Timer MENU → → → → ENTER → →...
  • Page 83 Adjusting the LCD Display Safety Lock PIN MENU → → → → ENTER → → ENTER → → → → → [0∼9, 0∼9, 0∼9, 0∼9] → [0∼9, 0∼9, 0∼9, 0∼9] → [0∼9, 0∼9, 0∼9, 0∼9] The password can be changed. Note The preset password for the LCD Display is "0000".
  • Page 84 Adjusting the LCD Display etc., depending on the external device connected. In this case, adjust the screen quality of your TV by configuring the HDMI black level. Normal Video Wall A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen.
  • Page 85 Adjusting the LCD Display The Format can be selected to see a divided screen. Full Provides a full screen without any margins. Natural Displays a natural image with the original aspect ratio intact. Horizontal MENU → → → → ENTER → →...
  • Page 86 Adjusting the LCD Display The screen can be divided into several images. A number of screens can be selected with a different layout when dividing. • Select a mode in Screen Divider. • Select a display in Display Selection. • The selection will be set up by pressing a number in the selected mode.
  • Page 87 Adjusting the LCD Display Horizontal Dot MENU → → → → ENTER → → ENTER → → → → → → → → → ENTER → → → ENTER → → , → EN- Sets how many pixels the screen moves horizontally. Five adjustment levels: 0, 1, 2, 3, and 4.
  • Page 88 Adjusting the LCD Display Timer Timer MENU → → → → ENTER → → ENTER → → → → → → → → → ENTER → → ENTER → → ENTER → → You can set the timer for Screen Burn Protection. If you start the operation to erase any residual image, the operation will be performed for the set period of time and then automatically finish.
  • Page 89 Adjusting the LCD Display Use this function to set the execution period for each mode set in the timer. Time MENU → → → → ENTER → → ENTER → → → → → → → → → → ENTER → →...
  • Page 90 Adjusting the LCD Display Eraser MENU → → → → ENTER → → ENTER → → → → → → → → → → → → →ENTER → This function prevents after-images on the screen by moving a rectangular pattern. Resolution Select MENU →...
  • Page 91 Adjusting the LCD Display → ENTER → Adjusts the Power On time for the screen. Caution: Set the Power On time to be longer to avoid overvoltage. Side Gray MENU → → → → ENTER → → → → → →...
  • Page 92 Adjusting the LCD Display Note Available in PC mode only Note The Reset function is not available when Video Wall is On. Color Reset MENU → → → → ENTER → → → → → → → → → → → → →...
  • Page 93: Available Modes

    Adjusting the LCD Display → → [0~9] • ID Setup Assigns distinctive IDs to the SET. • ID Input Use to select the transmitter functions of the individual SET. Only a SET where the ID corresponds to the transmitter setting becomes activated. MagicInfo Available Modes •...
  • Page 94 Adjusting the LCD Display • The server program's Power-On option works only if the LCD Display's power is com- pletely shut off. Please make sure not to use the Power-On option when the LCD Display is in the process of shutting down since this may cause system errors on the LCD Display. •...
  • Page 95 Adjusting the LCD Display 1. Select MagicInfo in the Source List menu. 2. The MUISetup screen appears. Select the language you want to use. 3. Press the Install button. If you select Do not show again and click the Install button, the Scheduler screen is displayed after rebooting.
  • Page 96 Adjusting the LCD Display 7. The Player screen of MagicInfo Pro is displayed. Note To finish the MagicInfo, press ALT + F12. Photo The JPEG, BMP file format are supported.
  • Page 97: Slide Show

    Adjusting the LCD Display Auto Automatically fits the image to the window. Original Shows the properties of the original file. Slide Show Displays the properties of the original file as they are.
  • Page 98 Adjusting the LCD Display Interval Controls the time intervals between image files for a slide show. (5 Sec, 10 Sec, 20 Sec, 30 Sec, 60 Sec) Rotation Displays an image file by turning it clockwise by 90 degrees.
  • Page 99 Adjusting the LCD Display Zoom Displays a reduced picture. Close Closes the image control Menu.
  • Page 100 Adjusting the LCD Display Music The MP3 file format is supported. Movie The MPEG1, WMV file format are supported. Play Plays a movie file.
  • Page 101 Adjusting the LCD Display Full Size Plays a movie file in full screen. OFFICE / HTML PPT(Power Point), DOC(MS Word), XLS(MS Excel), PDF, HTML, HTM files are displayed. Note • Install the proper viewer(freeware) program to see the MS Office(Word, Excel, Power Point) or PDF doucuments.
  • Page 102 Adjusting the LCD Display Internet Connects to the Internet Setup Sets various functions in MagicInfo mode. A password must be entered to access Setup mode. Schedule View Displays a schedule.
  • Page 103 Adjusting the LCD Display TCP/IP Changes the TCP/IP settings. Connection Modifies the network settings.
  • Page 104 Adjusting the LCD Display Password The password can be changed. • The password should be between 6 and 12 characters in numeric format. (You should enter a password between 6 and 12 characters in numeric format) • If you enter the wrong password three times, the setup configuration is reset and a warning message appears from the server.
  • Page 105 Adjusting the LCD Display Play Option You can set the repeat play and screen settings. Repeat : Determines the repeat option for playing movies and music. • None - Select No Repeat to play a movie or tune in the list only once. •...
  • Page 106: Troubleshooting

    Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display.
  • Page 107: Symptoms And Recommended Actions

    Do not use benzene, thinner or other flammable sub- stances, or a wet cloth. • We recommend that a SAMSUNG cleansing agent is used to prevent damage to the screen. 2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly.
  • Page 108: Problems Related To The Screen

    Troubleshooting Check if the signal cable between the computer and the LCD Display is securely con- nected. (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the LCD Display screen and their solutions are listed. The screen is blank and the power indicator is off.
  • Page 109: Problems Related To Audio

    Troubleshooting The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. The color white is poor. Adjust color using Custom under OSD Color Adjustment menu. The Power Indicator blinks.
  • Page 110: Problems Related To Magicinfo

    Troubleshooting Check the polarities (+/-) of the batteries. Check if the batteries are empty. Check if the power is on. Check if the power cord is securely connected. Check if a special fluorescent or neon lamp is on in the vicinity. Problems related to MagicInfo Note Making a Bootable USB Flash Disk.
  • Page 111 Troubleshooting Set the resolution in the Control Panel → Appearance and Themes → Display → Screen Saver. Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Manual). Windows ME/2000: Set the resolution at the Control Panel → Display → Screen Saver. Set the function in the BIOS-SETUP of the computer.
  • Page 112: Specifications

    Specifications General General Model Name SyncMaster 400MX(n) SyncMaster 460MX(n) LCD Panel Size SyncMaster 40 " Diagonal (101 cm) 400MX(n) SyncMaster 46 " Diagonal (116 cm) 460MX(n) Display area SyncMaster 885.17 mm (H) X 497.7 mm (V) 400MX(n) SyncMaster 1018.08 mm (H) X 572.7 mm (V)
  • Page 113 Specifications Maximum Pixel Clock 165MHz (Analog,Digital) Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz Signal Cable 15pin-to-15pin D-sub cable, Detachable DVI-D to DVI-D connector, Detachable Dimensions (W x H x D) / Weight SyncMaster 400MX 971.0 x 582.0 x 119.0 mm / 38.2 x 22.9 x 4.7 inch (Without...
  • Page 114 Specifications Note Design and specifications are subject to change without prior notice. Class B Equipment (Information Communication equipment for residential use) This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.) MagicInfo - Client Note...
  • Page 115: Preset Timing Modes

    Specifications PowerSaver This LCD Display has a built-in power management system called PowerSaver. This system saves energy by switching your LCD Display to low-power mode when it has not been used for a certain amount of time. The LCD Display automatically returns to normal operation when you press a key on the keyboard.
  • Page 116 Specifications Display Mode Horizontal Vertical Fre- Pixel Clock Sync Polarity Frequency quency (Hz) (MHz) (H/V) (kHz) VESA, 800 x 600 37.879 60.317 40.000 VESA, 800 x 600 48.077 72.188 50.000 VESA, 800 x 600 46.875 75.000 49.500 VESA, 848 x 480 31.020 60.000 33.750...
  • Page 117: For Better Display

    Information For Better Display Adjust the computer resolution and screen injection rate (refresh rate) on the computer as described below to enjoy the best picture quality. You can have an uneven picture quality on screen if the best picture quality is not provided for TFT- LCD.
  • Page 118 Information Power Off, Screen Saver, or Power Save Mode • Turn the power off for 4 hours after 20 hours in use • Turn the power off for 2 hours after 12 hours in use • Set the Monitor to power off with the PC Display Properties Power Scheme. •...
  • Page 119: Select Method

    Information • Avoid using a combination of characters and background color with large dif- ference in luminance. Avoid using Grey colors, which can cause Image retention easily. Avoid: Colors with big difference in luminance (Black & White, Grey) Change the characters color periodically •...
  • Page 120 Information Note ( Please check CD's User Guide at "OSD Function", some model's will not availa- ble ) Apply the Screen Pixel function on Product • Apply the Screen Pixel function - Symptom: Dot with Black Color move up and down. - Select method •...
  • Page 121 Information - Select method • Instruction Guide : OSD Menu -> Set Up -> Safety Screen -> Eraser • Time Interval : 1 ~ 10 hours ( Recommend : 1 ) • Time Period : 10 ~ 50 second ( Recommend : 50 ) Note ( Please check CD's User Guide at "OSD Function", some model's will not availa- ble )
  • Page 122 Appendix Contact SAMSUNG WORLDWIDE Note If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. North America U.S.A 1-800-SAMSUNG(726-7864) http://www.samsung.com/us CANADA 1-800-SAMSUNG(726-7864) http://www.samsung.com/ca MEXICO 01-800-SAMSUNG http://www.samsung.com/mx (726-7864) Latin America ARGENTINA 0800-333-3733 http://www.samsung.com/ar...
  • Page 123 022 - 607 - 93 - 33 PORTUGAL SAMSUNG http://www.samsung.com/pt (7267864) SLOVAKIA 0800-SAMSUNG (726-7864) http://www.samsung.com/sk SPAIN 902 - 1 - SAMSUNG(902 172 http://www.samsung.com/es 678) SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com/se SWITZERLAND 0848 - SAMSUNG (7267864, http://www.samsung.com/ch CHF 0.08/min) 0845 SAMSUNG (7267864) http://www.samsung.com/uk...
  • Page 124 INDIA 3030 8282 http://www.samsung.com/in 1-800-3000-8282 1800 110011 INDONESIA 0800-112-8888 http://www.samsung.com/id JAPAN 0120-327-527 http://www.samsung.com/jp MALAYSIA 1800-88-9999 http://www.samsung.com/my NEW ZEALAND 0800 SAMSUNG(0800 726 http://www.samsung.com/nz 786) PHILIPPINES 1-800-10-SAMSUNG http://www.samsung.com/ph (726-7864) 1-800-3-SAMSUNG (726-7864) 1-800-8-SAMSUNG (726-7864) 02-5805777 SINGAPORE 1800-SAMSUNG(726-7864) http://www.samsung.com/sg THAILAND 1800-29-3232, 02-689-3232 http://www.samsung.com/th...
  • Page 125 Appendix Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The dis- tance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Vertical Frequency The screen must be redrawn several times per second in order to create and display an image for the user.
  • Page 126: Correct Disposal

    Appendix Interlace and Non-Interlace Showing the horizontal lines of the screen from the top to Methods the bottom sequentially is called the Non-Interlace method while showing odd lines and then even lines in turn is called the Interlace method. The Non-Interlace method is used for the majority of monitors to ensure a clear image.
  • Page 127 Reproduction in any manner whatsoever without the written permission of Samsung Elec- tronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this ma- terial.

This manual is also suitable for:

Syncmaster 460mxSyncmaster 400mxnSyncmaster 460mxn
